Power Inductors - Molded High Current
ctparts.com
CTIHSM5832F Series
From 1.0 µH to 18,000 µH
Part
Number
CTIHSM5832F-1R0K
CTIHSM5832F-1R2K
CTIHSM5832F-1R5K
CTIHSM5832F-1R8K
CTIHSM5832F-2R2K
CTIHSM5832F-2R7K
CTIHSM5832F-3R3K
CTIHSM5832F-3R9K
CTIHSM5832F-4R7K
CTIHSM5832F-5R6K
CTIHMS5832F-6R8K
CTIHSM5832F-8R2K
CTIHSM5832F-100K
CTIHSM5832F-120K
CTIHSM5832F-150K
CTIHSM5832F-180K
CTIHSM5832F-220K
CTIHSM5832F-270K
CTIHSM5832F-330K
CTIHSM5832F-390K
CTIHSM5832F-470K
CTIHSM5832F-560K
CTIHSM5832F-680K
CTIHSM5832F-820K
CTIHSM5832F-101K
CTIHSM5832F-121K
CTIHSM5832F-151K
CTIHSM5832F-181K
CTIHSM5832F-221K
CTIHSM5832F-271K
CTIHSM5832F-331K
CTIHSM5832F-391K
CTIHSM5832F-471K
CTIHSM5832F-561K
CTIHSM5832F-681K
CTIHSM5832F-821K
CTIHSM5832F-102K
CTIHSM5832F-122K
CTIHSM5832F-152K
CTIHSM5832F-182K
CTIHSM5832F-222K
CTIHSM5832F-272K
CTIHSM5832F-332K
CTIHSM5832F-392K
CTIHSM5832F-472K
CTIHSM5832F-562K
CTIHSM5832F-682K
CTIHSM5832F-822K
CTIHSM5832F-103K
CTIHSM5832F-123K
CTIHSM5832F-153K
CTIHSM5832F-183K
Not shown at actual size.
SPECIFICATIONS
Part numbers indicate tolerance available.
K = ±10%
Inductance
(µH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
Test
Freq.
(KHz)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
DCR
Max.
Ω
(Ω)
0.010
0.011
0.012
0.013
0.015
0.017
0.020
0.021
0.023
0.024
0.038
0.047
0.053
0.068
0.078
0.083
0.120
0.140
0.170
0.190
0.215
0.236
0.305
0.357
0.452
0.530
0.609
0.809
1.100
1.270
1.420
1.890
2.210
2.200
2.730
3.780
4.200
5.510
7.350
8.660
9.710
11.29
15.60
20.74
23.10
26.40
29.90
32.20
38.10
45.20
48.30
52.50
Saturation
Suggested Rated
Current DC (Max.)
Current AC
(A)
(A)
9.0
8.8
8.7
8.6
8.5
8.4
8.3
7.9
7.4
7.0
6.1
5.1
4.3
3.9
3.5
3.2
2.8
2.3
1.9
1.8
1.77
1.71
1.43
1.14
0.95
0.88
0.82
0.75
0.69
0.64
0.59
0.54
0.49
0.46
0.43
0.4
0.37
0.32
0.29
0.25
0.22
0.2
0.18
0.16
0.14
0.12
0.10
0.08
0.06
0.04
0.04
0.04
6.2
5.6
5.0
4.4
4.0
3.7
3.4
3.1
2.8
2.6
2.3
2.0
1.8
1.7
1.6
1.5
1.3
1.2
1.1
1.0
.93
.90
.82
.75
.68
.63
.58
.54
.48
.43
.38
.34
.31
.28
.25
.23
.21
.19
.17
.16
.14
.13
.12
.11
.10
.082
.082
.065
.050
.050
.039
.039
Compliant
RoHS
CHARACTERISTICS
Description:
SMD Molded High Current Inductors
Applications:
Excellent power line noise filters, filters for
switching regulated power supplies, DC/DC converters, SCR and
Triac controls and RFI suppression.
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±10%
Rated Current:
Based on the inductance change within 10% of
initial value and temperature rise of initial value less than 30ºC
within coil body
Testing:
Tested on a HP4284A at 1KHz
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant.
Marking:
Parts are marked with inductance code & tolerance
Additional Information: Additional electrical & physical information
available upon request
Samples available. See website for ordering information.
PAD LAYOUT
Size
mm
inches
A
16.2±0.5
0.64±0.02
PHYSICAL DIMENSIONS
B
Max.
8.13
0.32
C
Max.
7.24
0.285
D
2.29±0.5
0.09±0.02
E
5.08±0.64
0.20±0.025
06.02.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
