Laser Cut Inductors
ctparts.com
CTLC0603F Series
From 1.0 nH to 220 nH
Part
Number
SPECIFICATIONS
Please specify tolerance code when ordering.
CTLC0603F-1N0_
C = ±0.2nH, S = ±0.3nH, G = ±2%, J = ±5%
* C or S only **C or J only ***G or J only
L Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
SRF
Typ.
(MHz)
16000
15000
13000
12000
10000
10000
9000
8000
7000
6000
6000
6000
5000
5000
4500
4000
4000
3000
3000
2000
2500
2500
2000
2000
1800
1800
1600
1400
1300
DCR
Max.
Ω
(mΩ)
20
25
30
33
35
40
60
65
100
150
150
180
200
350
400
450
500
550
600
800
950
1200
1300
1500
1800
3000
5000
6000
7000
Rated DC
Max.
(mA)
1800
1800
1500
1500
1500
1400
1200
1100
800
700
700
650
600
450
420
400
360
350
300
270
250
230
220
200
160
130
120
110
110
Inductance
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
Q
Q
@100MHz @800MHz
7
8
8
12
14
14
14
14
14
14
14
14
14
14
14
14
14
14
14
14
14
14
14
14
14
5
5
4
4
60
60
50
50
50
40
40
40
40
40
40
40
40
40
40
40
40
35
35
35
35
35
35
35
30
30
30
25
25
Not shown at actual size.
Compliant
RoHS
CTLC0603F-1N0_*
CTLC0603F-1N2_*
CTLC0603F-1N5_*
CTLC0603F-1N8_*
CTLC0603F-2N2_*
CTLC0603F-2N7_*
CTLC0603F-3N3_*
CTLC0603F-3N9_**
CTLC0603F-4N7_**
CTLC0603F-5N6_**
CTLC0603F-6N8_**
CTLC0603F-8N2_**
CTLC0603F-10N_***
CTLC0603F-12N_***
CTLC0603F-15N_***
CTLC0603F-18N_***
CTLC0603F-22N_***
CTLC0603F-27N_***
CTLC0603F-33N_***
CTLC0603F-39N_***
CTLC0603F-47N_***
CTLC0603F-56N_***
CTLC0603F-68N_***
CTLC0603F-82N_***
CHARACTERISTICS
Description:
SMD laser cut inductors
Applications:
Computer products, hard disks, floppy disks, etc.
Communication products, cordless phones, etc. Modems, OA
products, TV sets, etc. Countermeasures for complying with CE,
FCC, VDE or VCCI radiated emissions
Operating Temperature:
-40°C to +125°C
Inductance Tolerances:
±0.2nH, ±0.3nH, ±2%, ±5%
Testing:
Tested on a HP4287A at specified frequency
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant.
Marking:
Reels are marked with inductance code and tolerance
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CTLC0603F-R10_***
CTLC0603F-R12_***
CTLC0603F-R15_***
CTLC0603F-R18_***
CTLC0603F-R22_***
PHYSICAL DIMENSIONS
Size
mm
inches
A
1.6±0.15
0.06±0.006
B
0.8±0.15
0.03±0.006
C
0.8±0.15
0.03±0.006
D
0.3±0.2
0.012±0.008
PAD LAYOUT
01.27.09
CENTRAL
Manufacturer of Passive Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2009 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
TECHNOLOGIES
