CTLL2012FH Series
From 1.5 nH to 680 nH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CTLL2012_-FH3N3_
S = ±0.3nH, J = ±5%, K = ±10%
* S, K or M
** J, K or M
CTLL2012F
Please specify “F” for RoHS Compliant
Inductance
(nH)
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
L Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Q
Q Test
Factor Freq.
Typ.
(MHz)
50
51
61
62
64
59
55
51
58
58
58
61
48
58
59
54
54
50
47
45
26
28
27
22
21
22
22
14
14
15
14
15
14
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
100
100
100
50
50
50
50
25
25
25
25
25
25
SRF
Typ.
(MHz)
7000
6800
5700
5350
4300
4000
3600
3500
3000
2800
2600
2250
2250
2000
1800
1600
1400
1300
1150
1050
950
800
700
650
550
500
450
350
350
300
260
230
180
DCR
Max.
Ω
(Ω)
.10
.10
.10
.10
.10
.10
.12
.15
.15
.18
.20
.22
.24
.26
.28
.30
.40
.50
.55
.60
.65
.70
.80
.85
.90
1.0
1.2
1.3
1.5
1.8
4.5
4.5
5.5
Rated
DC
(mA)
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
250
250
250
200
200
150
150
50
50
50
Height
C
(mm)
0.60±0.2
0.60±0.2
0.60±0.2
0.60±0.2
0.60±0.2
0.60±0.2
0.60±0.2
0.60±0.2
0.60±0.2
0.60±0.2
0.85±0.3
0.85±0.3
0.85±0.3
0.85±0.3
0.85±0.3
0.85±0.3
0.85±0.3
0.85±0.3
1.0±0.3
1.0±0.3
1.0±0.3
1.0±0.3
1.0±0.3
1.2±0.3
1.2±0.3
1.2±0.3
1.2±0.3
1.2±0.3
1.2±0.3
1.2±0.3
1.2±0.3
1.2±0.3
1.2±0.3
Compliant
Available
RoHS
CTLL2012_-FH1N5S
CTLL2012_-FH1N8S
CTLL2012_-FH2N2S
CTLL2012_-FH2N7S
CTLL2012_-FH3N3_*
CTLL2012_-FH3N9_*
CTLL2012_-FH4N7_*
CTLL2012_-FH5N6_*
CTLL2012_-FH6N8_**
CTLL2012_-FH8N2_**
CTLL2012_-FH10N_**
CTLL2012_-FH12N_**
CTLL2012_-FH15N_**
CTLL2012_-FH18N_**
CTLL2012_-FH22N_**
CTLL2012_-FH27N_**
CTLL2012_-FH33N_**
CTLL2012_-FH39N_**
CTLL2012_-FH47N_**
CTLL2012_-FH56N_**
CTLL2012_-FH68N_**
CTLL2012_-FH82N_**
CTLL2012_-FHR10_**
CTLL2012_-FHR12_**
CTLL2012_-FHR15_**
CTLL2012_-FHR18_**
CTLL2012_-FHR22_**
CTLL2012_-FHR27_**
CTLL2012_-FHR33_**
CTLL2012_-FHR39_**
CTLL2012_-FHR47_**
CTLL2012_-FHR56_**
CTLL2012_-FHR68_**
CHARACTERISTICS
Description:
Ceramic core, multi-layer chip inductor for high
frequency applications
Applications:
Portable telephones, PMS, pagers and
miscellaneous high frequency circuits
Operating Temperature:
-40°C to +100°C
Inductance Tolerance:
±0.3 nH, ±5% & ±10%
Testing:
Inductance and Q are tested on an HP4286A at
specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
2.0±0.2
0.08±0.008
B
1.25±0.2
0.05±0.008
C
See ordering
info
D
0.51±0.25
0.02±0.01
PAD LAYOUT
04.11.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
