Wire-wound Chip Inductors - Open
ctparts.com
CTLQ1206NF
Series
From 0.15 µH to 100 µH
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CTLQ1206NF-R15_
J = ±5%, K = ±10%, M = ±20%
* = K or M only,
Part
Number
CTLQ1206NF-R15_*
CTLQ1206NF-R22_*
CTLQ1206NF-R33_*
CTLQ1206NF-R47_*
CTLQ1206NF-R56_*
CTLQ1206NF-R68_*
CTLQ1206NF-R82_*
CTLQ1206NF-1R0_*
CTLQ1206NF-1R2_*
CTLQ1206NF-1R5_
CTLQ1206NF-1R8_
CTLQ1206NF-2R2_
CTLQ1206NF-2R7_
CTLQ1206NF-3R3_
CTLQ1206NF-3R9_
CTLQ1206NF-4R7_
CTLQ1206NF-5R6_
CTLQ1206NF-6R8_
CTLQ1206NF-8R2_
CTLQ1206NF-100_
CTLQ1206NF-120_
CTLQ1206NF-150_
CTLQ1206NF-180_
CTLQ1206NF-220_
CTLQ1206NF-270_
CTLQ1206NF-330_
CTLQ1206NF-390_
CTLQ1206NF-470_
CTLQ1206NF-560_
CTLQ1206NF-680_
CTLQ1206NF-820_
CTLQ1206NF-101_
Inductance
(µH)
0.15
0.22
0.33
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
L Test
Freq.
(MHz)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Q
Fact.
Min.
20
20
30
30
30
30
30
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
40
40
40
40
40
40
40
40
40
Q Test
Freq.
(MHz)
25.0
25.0
25.0
25.0
25.0
25.0
25.0
10.0
10.0
10.0
10.0
10.0
10.0
8.0
8.0
8.0
8.0
8.0
8.0
5.0
5.0
5.0
5.0
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
DCR
Max.
Ω
(Ω)
0.54
0.60
0.63
1.16
0.85
0.93
1.02
0.63
1.17
1.30
2.08
0.91
0.71
1.82
1.95
2.21
2.34
2.60
2.86
3.25
3.51
3.90
4.42
4.03
4.42
4.94
9.36
10.4
11.57
12.87
14.30
15.60
SRF
Min.
(MHz)
250
250
250
200
180
160
120
100
90
75
60
50
43
38
35
31
28
25
23
20
18
16
15
14
13
12
11
10
9.0
8.5
7.5
7.0
Allowable
Current
(mA)
250
240
230
215
200
190
185
175
165
155
150
140
135
130
125
120
115
110
105
100
95
90
85
85
85
80
55
55
50
50
45
45
Compliant
RoHS
CHARACTERISTICS
Description:
SMD wire-wound chip inductor.
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-25°C to +85°C
Inductance Tolerance:
J = ±5%, K = ±10%, M = ±20%
Packaging:
Tape & Reel
Testing:
Tested on a HP4285A @ specified frequency
Pads:
Soft copper and pre-tinned
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
3.2±0.3
0.13±0.01
B
1.8±0.2
0.07±0.008
C
2.3±0.2
D
1.6±0.2
E
1.6±0.2
0.06±0.008
F
Min.
0.7
0.03
G
Min.
0.7
0.03
0.09±0.008 0.06±0.008
C
E
B
A
D
F
G
F
03.09.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
