Low Ohms
Feature
•Under
1 ohms, precision resistance.
•Both
flow and reflow soldering are applicable.
•Owing
to the reduced lead inductance, the high frequency
characteristic is excellent.
The product of lead-free terminal is RoHS compliant.
PhO(lead oxide) is included in the glass of our product which is prescribed
on RoHS appendix as an exception.
Application
•Current
detect.
•Safe
circuit through protecting over-current flow.
•Power
supplying part.
•Motor
controlling, DC power charger, etc.
Structure and Dimensions
•Structure
Glass or Polymer Coating
(Protective Coating)
RuO
2
type Resistor
•Dimensions
I
1
H
Alumina Substrate(96%)
Thick film Elecrtode
(Inner Electrode)
Special Plating
(Ni, Solder)
I
2
L
W
(UNIT: mm)
Type
RC1005
RC1608
RC2012
RC3216
RC3225
RC5025
RC6432
Inch
0402
0603
0805
1206
1210
2010
2512
Power(W)
1/16
1/10
1/8
1/ 4
1/3
2/3
1
L
1.00
±0.05
1.60
±0.10
2.00
±0.20
3.20
±0.20
3.20
±0.20
5.00
±0.20
6.30
±0.20
W
0.50
±0.05
0.80
±0.15
1.25
±0.15
1.60
±0.15
2.55
±0.20
2.50
±0.20
3.20
±0.20
H
0.35
±0.05
0.45
±0.10
0.50
±0.10
0.55
±0.10
0.55
±0.10
0.55
±0.10
0.55
±0.10
I
1
0.20
±0.10
0.30
±0.20
0.40
±0.20
0.45
±0.20
0.45
±0.20
0.60
±0.20
0.60
±0.20
I
2
0.25
±0.10
0.35
±0.10
0.35
±0.20
0.40
±0.20
0.40
±0.20
0.60
±0.20
0.60
±0.20
Average
Weight
0.6㎎
2.1㎎
4.9㎎
9.5㎎
16㎎
26㎎
41㎎
Parts Numbering System
•The
part number system shall be in the following format
RC
Code Designation
6432
Dimension & Size Code
1005: 1.0×0.5(㎜) - 0402(inch)
1608: 1.6×0.8(㎜) - 0603(inch)
2012: 2.0×1.2(㎜) - 0805(inch)
3216: 3.2×1.6(㎜) - 1206(inch)
3225: 3.2×2.5(㎜) - 1210(inch)
5025: 5.0×2.5(㎜) - 2010(inch)
6432: 6.4×3.2(㎜) - 2512(inch)
J
Tolerance
F: ±1%
G: ±2%
J: ±5%
3 or 4 digits coding system
(E-24 series)
R68
Resistance Value
CS
Packaging Code
GS: Bulk Packaging
CS: Tape Packaging 7"
ES: Tape Packaging 10"
FS: Tape Packaging 13"
AS: Tape Packaging 13"
RC: Chip Resistor
Specification
Type
RC1005
RC1608
RC2012
RC3216
RC3225
RC5025
RC6432
Power Working Overload
Rating Voltage Voltage
(W) (V, MAX) (V, MAX)
1/16
1/10
1/8
1/4
1/3
2/3
1
0.25
0.32
0.35
0.50
0.58
0.82
1.00
0.63
0.79
0.88
1.25
1.44
2.04
2.50
TCR (ppm/
℃
)
Resistance Range (
Ω
)
Rated
Rated
Working
Ambient
F(±1%) G(±2%) J(±5%)
E-24
E-24 Temperature Temperature
E-24
0.1Ω≤R
〈
0.15Ω:
400(+300,-200) ppm/
0.15Ω≤R
〈
1.0Ω:
0~250ppm/
0.1~0.98
70℃
-55℃~+125℃
Operation
Notes
•Rated
voltage (V) =
Rated power(W)×Normal resistance value (R)
Rated voltage should be lower than (MAX) working voltage.
√
Example of Land
Pattern Design
Power Derating Curve
The rated power is the maximum continuous loading
power at 70
℃
ambient temperature.
For ambient temperature above 70
℃
, the loading power
follows the below power derating curve.
100
Percentage of the rated
dissipation(%)
80
60
Operation area
40
20
0
-55
-40
0
40
70
80
120
125
Marking
E-24 series
Recommended
Soldering Conditions
3 digits indication
- R means decimal point.
- Other digits represent
significant value.
- Example:
R22
Left 1 digit:
R
Last 2 digits:
22
R22
=
0.22Ω
4 digits indication
- R means decimal point.
- Other digits represent
significant value.
-Example:
R075
Left 1 digit:
R
Last 3 digits:075
R075
=
0.075Ω
General
Purpose
Precision
Low Ohms
R22
Ambient Temperature(℃)
R075
Array
Attenuator
Resistance Value Table
•E-24
series
Code
R039
R043
R047
R051
R056
R062
R068
R075
R082
R091
R-value
0.039Ω
0.043Ω
0.047Ω
0.051Ω
0.056Ω
0.062Ω
0.068Ω
0.075Ω
0.082Ω
0.091Ω
Code
R10
R11
R12
R13
R15
R16
R18
R20
R22
R24
R27
R30
R-value
0.10Ω
0.11Ω
0.12Ω
0.13Ω
0.15Ω
0.16Ω
0.18Ω
0.20Ω
0.22Ω
0.24Ω
0.27Ω
0.30Ω
Code
R33
R36
R39
R43
R47
R51
R56
R62
R68
R75
R82
R91
R-value
0.33Ω
0.36Ω
0.39Ω
0.43Ω
0.47Ω
0.51Ω
0.56Ω
0.62Ω
0.68Ω
0.75Ω
0.82Ω
0.91Ω
Standard
Resistance Value
Packaging
Characteristics
Performance
Design and Specifications are subject to change without prior notice.
Please ask the manufacturer for technical Specifications before you order and/or use.
