Silicon NPN Power Transistor
2SC4331
DESCRIPTION
·Available
for high-current control in small dimension
·Low
collector saturation voltage
·Fast
switching speed
·High
DC current gain and excellent linearity
·100%
avalanche tested
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·This
transistor is ideal for use in Switching regulators,
DC/DC converters,motor drivers,Solenoid drivers
and other low-voltage power supply devices,as well
as for high-current switching.
ABSOLUTE MAXIMUM RATINGS(T
a
=25
℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
NOTE1
Collector Power Dissipation
@ T
C
=25℃
Collector Power Dissipation
@T
a
=25℃
NOTE2
Junction Temperature
Storage Temperature Range
VALUE
150
100
7
5
10
15
W
1.0
150
-55~150
℃
UNIT
V
V
V
A
A
I
CM
P
C
T
J
T
stg
℃
NOTE1:PW≤300ms,Duty cycle ≤10%
NOTE2:Printing boarding mounted
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
CE
(sat)-1
NOTE
V
CE
(sat)-2
NOTE
V
BE(sat)-1NOTE
V
BE(sat)-2NOTE
I
CBO
I
EBO
h
FE-1NOTE
h
FE-2NOTE
h
FE-3NOTE
C
OB
f
T
PARAMETER
Collector-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
DC Current Gain
DC Current Gain
Output Capacitance
Current-Gain—Bandwidth Product
CONDITIONS
I
C
= 3A; I
B
= 150mA
I
C
= 4A; I
B
= 200mA
I
C
= 3A; I
B
= 150mA
I
C
= 4A; I
B
= 200mA
V
CB
= 100V; I
E
= 0
V
EB
= 5V; I
C
= 0
I
C
= 0.5A; V
CE
= 2V
I
C
= 1A; V
CE
= 2V
I
C
= 3A; V
CE
= 2V
I
E
= 0; V
CB
= 10V; f= 1.0MHz
I
C
= 500mA; V
CE
= 10V
100
100
60
MIN
2SC4331
TYP.
MAX
0.3
0.5
1.2
1.5
10
10
UNIT
V
V
V
V
μA
μA
400
60
150
pF
MHz
NOTE:Pulse test PW≤350us,duty cycle ≤2%/pulse
h
FE-2
Classifications
M
L
150-300
K
200-400
100-200
isc website
：
www.iscsemi.com
2
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistor
2SC4331
