SAK-C868-1SRBA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> SAK-C868-1SRBA

SAK-C868-1SRBA: DescriptionMicrocontroller, 8-Bit, 40MHz, CMOS, PDSO38, PLASTIC, TSSOP-38; CategoryThe embedded processor and controller Microcontrollers and processors; File Size788KB，82 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

SAK-C868-1SRBA Overview

Microcontroller, 8-Bit, 40MHz, CMOS, PDSO38, PLASTIC, TSSOP-38

SAK-C868-1SRBA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Infineon
Parts packaging code	TSSOP
package instruction	TSSOP,
Contacts	38
Reach Compliance Code	compli
Has ADC	YES
Address bus width
bit size	8
maximum clock frequency	10.67 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PDSO-G38
JESD-609 code	e3
length	9.7 mm
Humidity sensitivity level	3
Number of I/O lines	16
Number of terminals	38
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1.2 mm
speed	40 MHz
Nominal supply voltage	2.5 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	4.4 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

D a t a S h e e t , V 1 . 0 , Ma y 2 0 0 3

C868

8-Bit Single-Chip Microcontroller

Microcontrollers

N e v e r

s t o p

t h i n k i n g .

SAK-C868-1SRBA Related Products

	SAK-C868-1SRBA	SAK-C868P-1SRBA	SAK-C868-1SGBA
Description	Microcontroller, 8-Bit, 40MHz, CMOS, PDSO38, PLASTIC, TSSOP-38	Microcontroller, 8-Bit, 8051 CPU, 40MHz, CMOS, PDSO38, PLASTIC, TSSOP-38	Microcontroller, 8-Bit, 40MHz, CMOS, PDSO28, PLASTIC, SO-28
Maker	Infineon	Infineon	Infineon
Parts packaging code	TSSOP	TSSOP	SOIC
package instruction	TSSOP,	PLASTIC, TSSOP-38	SOP,
Contacts	38	38	28
Reach Compliance Code	compli	unknown	unknow
Has ADC	YES	YES	YES
bit size	8	8	8
maximum clock frequency	10.67 MHz	10.67 MHz	10.67 MHz
DAC channel	NO	NO	NO
DMA channel	NO	NO	NO
JESD-30 code	R-PDSO-G38	R-PDSO-G38	R-PDSO-G28
length	9.7 mm	9.7 mm	18.1 mm
Number of I/O lines	16	16	16
Number of terminals	38	38	28
Maximum operating temperature	125 °C	125 °C	125 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C
PWM channel	YES	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TSSOP	TSSOP	SOP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.2 mm	1.2 mm	2.65 mm
speed	40 MHz	40 MHz	40 MHz
Nominal supply voltage	2.5 V	2.5 V	2.5 V
surface mount	YES	YES	YES
technology	CMOS	CMOS	CMOS
Temperature level	AUTOMOTIVE	AUTOMOTIVE	AUTOMOTIVE
Terminal form	GULL WING	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.5 mm	1.27 mm
Terminal location	DUAL	DUAL	DUAL
width	4.4 mm	4.4 mm	7.6 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
Is it Rohs certified?	conform to	conform to	-
Humidity sensitivity level	3	3	-
