BAS125W datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BAS125W

BAS125W: Description0.1 A, SILICON, SIGNAL DIODE; CategoryDiscrete semiconductor diode; File Size57KB，5 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric View All

BAS125W Overview

0.1 A, SILICON, SIGNAL DIODE

BAS125W Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Infineon
Reach Compliance Code	unknow
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.9 V
JESD-30 code	R-PDSO-G3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Maximum output current	0.1 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.25 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	25 V
surface mount	YES
technology	SCHOTTKY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

BAS125W

Silicon Schottky Diodes

For low-loss, fast-recovery, meter protection,

bias isolation and clamping applications

Integrated diffused guard ring

Low forward voltage

BAS125W

BAS125-04W

EHA07002

VSO05561

BAS125-05W

BAS125-06W

EHA07005

EHA07004

EHA07006

ESD

lectro

tatic

ischarge sensitive device, observe handling precaution!

Type

Marking

Pin Configuration

Package

BAS125W

BAS125-04W

BAS125-05W

BAS125-06W

13s

14s

15s

16s

1=A

1 = A1

1 = C1

2 n.c.

2 = C2

2 = A2

2 = C2

3=C

3 = C1/A2

3 = C1/2

3 = A1/2

SOT323

Maximum Ratings

Parameter

Diode reverse voltage

Forward current

Surge forward current (t 100 s)

Total power dissipation BAS125W,

= 93 °C

BAS 125-04W...06W

= 84 °C

Junction temperature

Operating temperature range

Storage temperature

Symbol

FSM

tot

stg

Value

100

500

250

150

-55 ... 150

°C

Unit

Thermal Resistance

Junction - soldering point

BAS125W

BAS125-04W...06W

1For calculation of

thJA

please refer to Application Note Thermal Resistance

thJS

230

265

K/W

Nov-15-2001
