DC-AC INVERTER UNIT
CXA-0379(R)
(30 W SIXFOLD OUTPUTS WITH DIMMING FUNCTION)
DESCRIPTION :
This low profile DC to AC Inverter is developed for Sixfold lamps,
low power LCD back-light.
APPLICABLE LCD:
6.4 to 15 inches Sixfold lamp type
Lamp Voltage 790 Vrms
Lamp Current 6.5 mArms
Lamp Start Up Voltage 1.300 Vrms (Vin : 12.0 Vdc)
FEATURES :
Dimming function
Remote ON/OFF
Open Lamp Detection
RoHS compliant (R)
TEMPERATURE & HUMDITY :
Operating Temperature Range
Storage Temperature Range
Humidity
DIMENSIONS :
LxWxH
(PRELIMINARY INFORMATION)
0°C ~ +70°C
-30°C ~ +85°C
95 %RH max
220 x 79 x 9,2 mm
220±0.5
210±0.2
(5)
105±0.2
19.5±0.2
CN2
CN3
CN1
CN6
78.5±0.5
CN4
49±0.2
CN7
CN5
CN8
Unit : mm
Weight :50 (g) typ.
(1.2)
(5)
8max.
Note: Please use plastic screw in case of a non-insulating mounting base!
Components
No.
1
2
3
4
Part Discription
PWB
Connector CN1
Connector CN2
Connector CN3~CN8
Qty.
1
1
1
6
Material
Conpos ite (CEM-3)
DF3-8P-2H
IL-Z9PL-SMTY
SM02B-BHSS-1-TB
Note
t=1m m
HRS or equal
JAE or equal
JST or equal
Power Systems – The Power Solution
Web:
Email:
www.Power-Systems.de
Info@Power-Systems.de
Page (1)
Address: Hauptstr. 48 ; 74360 Ilsfeld-Auenstein / Germany
Tel. :
+ 49 / 70 62 / 67 59 - 6
Fax:
+ 49 / 70 62 / 67 59 - 800
Version 1.1.1, 23th October 2006
All specification are subject to change without notice.
DC-AC INVERTER UNIT
CXA-0379(R)
(30 W SIXFOLD OUTPUTS WITH DIMMING FUNCTION)
(PRELIMINARY INFORMATION)
Input side CN2:
Pin No. Symbols
GND
CN 2-1~2
Vs t
CN 2-3
CN 2-4
CN 2-5
CN 2-6
CN 2-7
CN 2-8
CN 2-9
BRTC
BRTH
BRTL
BRTP
Hi/Lo
PWSEL
Input side CN1:
Ratings
0 / 5.0 Vdc
0 / 5.0 Vdc
0 Vdc
*
1
0 ~ 1.0 Vdc or 0 ~ 10 k
0 / 5.0 Vdc
*
3
0 / 5.0 Vdc
0 / 5.0 Vdc
*
4
Pin No.
CN 1-1~4
CN 1-5~8
Symbols
GND
Vin
Ratings
11.4 ~ 12.6 Vdc
*
2
Output side CN3~CN8
Pin No.
CN x-1
CN x-2
Symbols
Vhigh
Vlow
Ratings
790 Vrm s (6.5 m Arm s )
(GND)
Note:
*1 = Dimming pin –
*2 = Dimming pin +
*3 = PWM-Signal
*4 = PWM Signal Selection int. / ext.
ELECTRICAL CHARACTERISTICS :
Parameters
Output Current 1
Output Current 2
Output Current 3
Output Current 4
Input Current
Input Current
Frequency
Frequency (Duty)
Alarm Signal
Symbols
Iout1~6
Iout1~6
Iout1~6
Iout1~6
Iin1
Iin2
F1
F2
Vs t
Conditions
Vrmt
Vbr (V)
(V)
5±0.05
0
5±0.05 5±0.05
5±0.05
0
5±0.05 5±0.05
5±0.05
0
0
0
5±0.05
0
5±0.05
0
5±0.05
0
5±0.05
0
Specification
Tu (°C)
0
0
0
0
0
0
0
0
0
0
~ +60
~ +60
~ +60
~ +60
~ +60
~ +60
~ +60
~ +60
~ +60
~ +60
Min.
6.0
5.5
2.3
2.0
-
-
54
241
0.0
4.5
Typ.
6.5
6.0
3.3
3.0
3.5
0.1
59
255
0.1
5.1
Max.
7.0
6.5
4.3
4.0
5.3
1
64
269
0.5
5.5
Unit
m Arm s
m Arm s
m Arm s
m Arm s
Adc
m Adc
kHz
Hz
Vdc
Vdc
Note
Hi M ax
Lo M ax
Hi M in
Lo M in
Hi M ax
Remo te Of f
Vin (V)
12.0±0.6
12.0±0.6
12.0±0.6
12.0±0.6
12.0±0.6
12.0±0.6
12.0±0.6
12.0±0.6
12.0±0.6
12.0±0.6
One lamp open
Note 1 :
Please keep minimum of 2mm clearance (all directions) between inverter high voltage area as marked
on mechanical drawing and any conductors.
Power Systems – The Power Solution
Web:
Email:
www.Power-Systems.de
Info@Power-Systems.de
Page (2)
Address: Hauptstr. 48 ; 74360 Ilsfeld-Auenstein / Germany
Tel. :
+ 49 / 70 62 / 67 59 - 6
Fax:
+ 49 / 70 62 / 67 59 - 800
Version 1.1.1, 23th October 2006
All specification are subject to change without notice.
DC-AC INVERTER UNIT
CXA-0379(R)
(30 W SIXFOLD OUTPUTS WITH DIMMING FUNCTION)
TEST CIRCUIT :
Vin
11.4~12.6V
Iin
T01
(PRELIMINARY INFORMATION)
SW1
7
CN203-1
V
HIGH
1
RL1
Operation of unit
Operation
Non operation
Operation
Operation of unit
Lo mode
Hi mode
Lo mode
A
V
CN201-5,6,7,8
Vin
FL
2
3
4
1
5
a
A
~
b
Open
SW2
CN201-1,2,3,4
GND
6
CN203-2
VLOW1
CN204-1
V
HIGH
1
SW3
Iout1
RL2
CN202-1,2
GND
A
~
CN202-3
Vst
CN204-2
VLOW1
SW4
Iout2
RL1
a
b
Open
V
ON/OFF
5V
a
b SW1
CN205-1
V
HIGH
1
CN202-4
BRTC
CN205-2
VLOW1
CN206-1
V
HIGH
1
SW5
A
~
1
14
IC
7
8
Iout3
RL2
Vbr
0~1V
CN202-5
BRTH
A
~
Hi/Lo
5V
a
b
SW2
CN202-8
Hi/Lo
CN206-2
VLOW1
SW6
Iout4
RL1
CN207-1
V
HIGH
1
A
~
CN207-2
VLOW1
CN208-1
V
HIGH
1
SW7
Iout5
RL2
A
~
CN208-2
VLOW1
SW8
Iout6
F
F
1000:1
V
~
Power Systems – The Power Solution
Web:
Email:
www.Power-Systems.de
Info@Power-Systems.de
Page (3)
Address: Hauptstr. 48 ; 74360 Ilsfeld-Auenstein / Germany
Tel. :
+ 49 / 70 62 / 67 59 - 6
Fax:
+ 49 / 70 62 / 67 59 - 800
Version 1.1.1, 23th October 2006
All specification are subject to change without notice.
