Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
5W max.
1W max.
Coaxial
ZAPD-900-5W+
50Ω
100 to 900 MHz
Features
• wideband, 100 to 900 MHz
• low insertion loss, 0.3 dB typ.
• good isolation, 26 dB typ.
• up to 5W power input as splitter
• excellent amplitude unbalance, 0.1 dB typ.
• excellent phase unbalance, 1 deg. typ.
• rugged shielded case
N-Type version shown
CASE STYLE: F14
Connectors Model
Price
N-TYPE
ZAPD-900-5W-N+ $64.95
SMA
ZAPD-900-5W-S+ $64.95
Qty.
(1-9)
(1-9)
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
S
1
2
Applications
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
• VHF/UHF
• communication systems
• instrumentation
FREQ.
RANGE
(MHz)
ISOLATION
(dB)
INSERTION LOSS
(dB)
ABOVE 3.0 dB
Typ.
0.3
Max.
1.0
Splitter Electrical Specifications
PHASE
UNBALANCE
(Degrees)
Max.
3
AMPLITUDE
UNBALANCE
(dB)
S
Max.
0.3
Typ.
1.15
VSWR
(:1)
OUT
Max.
1.5
Typ.
1.22
Max.
1.5
Outline Drawing
f
L
-f
U
100-900
Typ. Min.
23
18
Typical Performance Data
Frequency
(MHz)
Total Loss
1
(dB)
S-1
100.00
130.00
160.00
230.00
300.00
3.15
3.14
3.15
3.17
3.19
3.21
3.28
3.30
3.37
3.41
3.49
3.56
3.64
3.74
Amplitude
Unbalance
(dB)
0.01
0.01
0.00
0.01
0.01
0.02
0.03
0.03
0.03
0.04
0.05
0.05
0.07
0.09
Isolation
(dB)
VSWR
S
VSWR
1
VSWR
2
S-2
3.14
3.13
3.14
3.16
3.18
3.19
3.25
3.27
3.34
3.38
3.44
3.50
3.57
3.66
22.80
22.85
22.87
22.70
22.65
22.56
22.84
23.22
24.02
25.31
27.32
29.51
29.70
26.35
1.16
1.14
1.13
1.11
1.11
1.10
1.09
1.08
1.07
1.07
1.07
1.07
1.10
1.15
1.27
1.25
1.24
1.20
1.17
1.14
1.11
1.10
1.11
1.14
1.17
1.21
1.25
1.27
1.27
1.25
1.24
1.20
1.17
1.14
1.11
1.10
1.11
1.14
1.17
1.21
1.25
1.27
Outline Dimensions (
A
2.00
50.80
H
0.39
9.91
B
2.00
50.80
J
1.00
25.40
C
0.75
19.05
K
0.50
12.70
D
1.00
25.40
L
1.00
25.40
E
0.25
6.35
inch
mm
)
G
0.125
3.18
wt
grams
170.0
4.0
TOTAL LOSS (dB)
F
1.500
38.10
370.00
440.00
510.00
580.00
650.00
720.00
790.00
860.00
924.00
1. Total Loss = Insertion Loss + 3dB splitter loss.
ZAPD-900-5W+
TOTAL LOSS
S-1(dB)
S-2(dB)
ZAPD-900-5W+
ISOLATION
40
ISOLATION (dB)
35
30
25
20
15
100
3.8
3.6
3.4
3.2
3.0
100
200
300
400
500
600
700
800
900
200
300
400
500
600
700
800
900
FREQUENCY (MHz)
ZAPD-900-5W+
VSWR
#S-VSWR
1.4
VSWR
1.3
1.2
1.1
1.0
100
#1-VSWR
#2-VSWR
FREQUENCY (MHz)
1.5
electrical schematic
200
300
400
500
600
700
800
900
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. C
M127604
ZAPD-900-5W+
HY/TD/CP
100614
