Power Splitter/Combiner
16 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
1W max.
0.87W max.
Coaxial
ZFSC-16-1-75+
75Ω
1 to 150 MHz
Features
• low insertion loss, 0.7 dB typ.
• high isolation, 30 dB typ.
• excellent amplitude unbalance, 0.2 dB typ.
• rugged shielded case
CASE STYLE: R30
Connectors Model
BNC
ZFSC-16-1-75+
Price
$182.95
Qty.
(1-9)
Permanent damage may occur if any of these limits are exceeded.
Applications
Coaxial Connections
SUM PORT
PORT 1,2,3,.....,16
S(COM)
1,2,3,.....,16
• HF/VHF
• communication systems
• instrumentation
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Electrical Specifications
Outline Drawing
FREQ.
RANGE
(MHz)
f
L
-f
U
1-150
L
Typ.
30
Min
25
Typ.
30
ISOLATION
(dB)
M
Min
25
Typ.
25
U
Min
20
INSERTION LOSS (dB)
ABOVE 12 dB
L
M
U
Typ. Max. Typ. Max. Typ. Max.
0.8
1.1
0.7
1.1
1.0
1.3
PHASE
UNBALANCE
(Degrees)
L
Max.
3
M
Max.
6
U
Max.
10
AMPLITUDE
UNBALANCE
(dB)
L
Max.
0.4
M
Max.
0.2
U
Max.
0.4
L = low range [f
L
to 10 f
L
]
M = mid range [10 f
L
to f
U
/2]
U= upper range [f
U
/2 to f
U
]
Typical Performance Data
Freq.
(MHz)
Total Loss
1
(dB)
S-1
1.00
3.00
5.00
8.00
13.00
22.00
31.00
40.00
61.00
78.00
12.48
12.40
12.37
12.36
12.36
12.41
12.45
12.49
12.56
12.62
12.63
12.69
12.73
12.76
12.80
ZFSC-16-1-75+
TOTAL LOSS
15
TOTAL LOSS (dB)
14
13
12
11
10
0
30
60
90
FREQUENCY (MHz)
120
150
Amplitude
Unbalance
(dB)
0.26
0.18
0.15
0.14
0.13
0.11
0.07
0.07
0.08
0.07
0.10
0.10
0.11
0.13
0.14
Isolation
(dB)
Adjacent
39.02
42.46
44.14
45.18
45.36
45.22
44.91
45.16
46.17
47.21
48.26
50.55
51.55
52.04
50.80
Opposite
35.90
39.97
41.72
43.00
43.42
42.83
41.43
40.14
37.07
35.06
34.15
32.42
31.15
30.00
28.97
Phase
Unbalance
(deg.)
1.42
0.90
0.75
0.65
0.66
0.75
0.84
0.85
0.95
0.98
0.94
0.99
0.96
1.07
1.18
ZFSC-16-1-75+
ISOLATION
1-2(dB)
1-3(dB)
VSWR
S
VSWR
1
1.31
1.28
1.29
1.30
1.30
1.29
1.29
1.28
1.25
1.22
1.20
1.17
1.15
1.13
1.13
1.22
1.14
1.10
1.08
1.07
1.06
1.07
1.08
1.11
1.13
1.14
1.15
1.17
1.19
1.21
Outline Dimensions (
inch
)
mm
A
6.69
169.93
J
.40
10.16
B
1.60
40.64
K
.69
17.53
C
D
1.50
6.22
38.10 157.99
L
.55
13.97
E
.24
6.10
F
.88
22.35
P
.81
20.57
G
.36
9.14
H
.160
4.06
87.00
105.00
120.00
135.00
150.00
1. Total Loss = Insertion Loss +12dB splitter loss.
70
60
50
40
30
20
0
30
M
N
.66
5.72
16.76 145.29
Q
wt.
.06 grams
1.52
320
ISOLATION (dB)
60
90
120
150
FREQUENCY (MHz)
ZFSC-16-1-75+
VSWR
1.5
1.4
VSWR
1.3
1.2
1.1
1.0
0
30
60
90
FREQUENCY (MHz)
120
150
#S-VSWR
#1-VSWR
electrical schematic
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. C
M127604
ZFSC-16-1-75+
HY/TD/CP/AM
100602
