Guard Lock Safety-door Switch
D4NL
Lead-free,
Environment-friendly Design
• Contains no harmful substances, such as lead or cad-
mium, reducing the burden on the environment.
• Models with 4-contact and 5-contact built-in switches
are available.
• Key holding force of 1,300 N min.
• Can be used for either standard loads or microloads.
• Lineup includes models with a conduit size of M20.
• IP67 degree of protection.
• Operation key compatible to D4DS, D4NS and D4GL.
Model Number Structure
Model Number Legend
Switch
4. Door Lock and Release
A:
Mechanical lock/24-VDC solenoid release
B:
Mechanical lock/110-VAC solenoid release
C:
Mechanical lock/230-VAC solenoid release
G:
24-VDC solenoid lock/mechanical release
H:
110-VAC solenoid lock/mechanical release
J:
230-VAC solenoid lock/mechanical release
5. Indicator
B:
10 to 115 VAC/VDC (orange LED indicator)
E:
100 - 230V VAC (orange neon lamp indicator)
6. Release Key Type
Blank:Standard
4:
Special release key
7. Release Key Position
Blank:Bottom
S:
Front
D4NL-@@@@-@@@
1 2 3 4
5 6 7
1. Conduit Size
1:
Pg13.5
2:
G1/2
4:
M20
2. Built-in Switch (with Door Open/Closed Detection Switch and
Lock Monitor Switch Contacts)
A:
1NC/1NO slow-action contacts plus 1NC/1NO slow-action
contacts
B:
1NC/1NO slow-action contacts plus 2NC slow-action con-
tacts
C:
2NC slow-action contacts plus 1NC/1NO slow-action con-
tacts
D:
2NC slow-action contacts plus 2NC slow-action contacts
E:
2NC/1NO slow-action contacts plus 1NC/1NO slow-action
contacts
F:
2NC/1NO slow-action contacts plus 2NC slow-action con-
tacts
G:
3NC slow-action contacts plus 1NC/1NO slow-action con-
tacts
H:
3NC slow-action contacts plus 2NC slow-action contacts
3. Head Mounting Direction and Material
F:
Four mounting directions possible (Front-side mounting at
time of delivery)/plastic
D:
Four mounting directions possible (Front-side mounting at
time of delivery)/metal
Operation Key
\
D4DS-K@
1
1. Operation Key Type
1:
Horizontal mounting
2:
Vertical mounting
3:
Adjustable mounting (horizontal)
5:
Adjustable mounting (horizontal/vertical)
D4NL
G-153
D4NL
Ordering Information
List of Models
For 110V and 230V version ask your local OMRON Representative
Switches (Operation Keys are sold separately.)
: Models with approved direct opening contacts.
Head
material
Release
key
position
Release
key type
Solenoid voltage/
indicator
Prefered stock item*
Contact configuration
(door open/closed
detection switch and lock
monitor switch contacts)
(slow-action)
Approved direct opening
NC contact
1NC/1NO+1NC/1NO
Conduit opening
Model
Lock and release types
Plastic
Bottom
Standard Solenoid: 24 VDC
Orange LED: 10 to 115
VAC/VDC
Mechanical lock
Solenoid release
Pg13.5
G1/2
M20
D4NL-1AFA-B*
D4NL-2AFA-B
D4NL-4AFA-B*
D4NL-1BFA-B
D4NL-2BFA-B
D4NL-4BFA-B
D4NL-1CFA-B*
D4NL-2CFA-B
D4NL-4CFA-B*
D4NL-1DFA-B
D4NL-2DFA-B
D4NL-4DFA-B
D4NL-1EFA-B
D4NL-2EFA-B
D4NL-4EFA-B*
D4NL-1FFA-B
D4NL-2FFA-B
D4NL-4FFA-B
D4NL-1GFA-B
D4NL-2GFA-B
D4NL-4GFA-B
D4NL-1HFA-B
D4NL-2HFA-B
D4NL-4HFA-B
D4NL-1AFG-B*
D4NL-2AFG-B
D4NL-4AFG-B*
D4NL-1BFG-B
D4NL-2BFG-B
D4NL-4BFG-B
D4NL-1CFG-B*
D4NL-2CFG-B
D4NL-4CFG-B*
D4NL-1DFG-B
D4NL-2DFG-B
D4NL-4DFG-B
D4NL-1EFG-B
D4NL-2EFG-B
D4NL-4EFG-B*
D4NL-1FFG-B
D4NL-2FFG-B
D4NL-4FFG-B
D4NL-1GFG-B
D4NL-2GFG-B
D4NL-4GFG-B
D4NL-1HFG-B
D4NL-2HFG-B
D4NL-4HFG-B
1NC/1NO+2NC
Pg13.5
G1/2
M20
2NC+1NC/1NO
Pg13.5
G1/2
M20
2NC+2NC
Pg13.5
G1/2
M20
2NC/1NO+1NC/1NO
Pg13.5
G1/2
M20
2NC/1NO+2NC
Pg13.5
G1/2
M20
3NC+1NC/1NO
Pg13.5
G1/2
M20
3NC+2NC
Pg13.5
G1/2
M20
Solenoid lock
Mechanical release
1NC/1NO+1NC/1NO
Pg13.5
G1/2
M20
1NC/1NO+2NC
Pg13.5
G1/2
M20
2NC+1NC/1NO
Pg13.5
G1/2
M20
2NC+2NC
Pg13.5
G1/2
M20
2NC/1NO+1NC/1NO
Pg13.5
G1/2
M20
2NC/1NO+2NC
Pg13.5
G1/2
M20
3NC+1NC/1NO
Pg13.5
G1/2
M20
3NC+2NC
Pg13.5
G1/2
M20
G-154
Safety Sensors / Components
Operation Keys
Type
Model
D4DS-K1
Horizontal mounting
Vertical mounting
D4DS-K2
Adjustable mounting
(Horizontal)
D4DS-K3
Adjustable mounting
(Horizontal/Vertical)
D4DS-K5
Specifications
Standards and EC Directives
Applicable EC Directives and Standards
•
•
•
•
•
Machinery Directive
Low Voltage Directive
EN1088
EN60204-1
GS-ET-19
Approved Standard Ratings
TÜV (EN60947-5-1)
Item
Utilization
category
3A
AC-15
DC-13
0.27 A
250 V
Rated operating current (I
e
)
Rated operating voltage (U
e
)
240 V
Approved Standards
Agency
TÜV Product
Service
UL (See note 2.)
Standard
EN60947-5-1 (approved
direct opening)
UL508, CSA C22.2 No.14
File No.
(See note 1.)
E76675
Note: Use a 10-A fuse type
gI
or
gG
that conforms to IEC269 as a short-circuit
protection device. This fuse is not built into the Switch.
UL/CSA (UL508, CSA C22.2 No. 14)
A300
Rated
voltage
120 VAC
240 VAC
Carry current
10 A
60 A
30 A
Current
Make
Break
6A
3A
Volt-amperes
Make
Break
7,200 VA 720 VA
Note: 1.
Consult your OMRON representative for details.
2.
Approval for CSA C22.2 No. 14 is authorized by the UL
mark.
Solenoid Coil Characteristics
Item
24 VDC
110 VAC
230 VAC
Rated operating
24 VDC +10%/ 110 VAC
±10%
230 VAC
±10%
voltage (100% ED)
−
15%
Current consump- Approx.
tion
200 mA
Insulation
Approx. 50 mA Approx. 30 mA
Indicator Characteristics
Item
Rated voltage
Current leakage
Color (LED)
Approx. 1 mA
Orange
LED
10 to 115 VAC/VDC
D4NL
G-155
D4NL
Class F (130° C max.)
Characteristics
Degree of protection (see note 2)
Durability
(see note 3)
Operating speed
Operating frequency
Rated frequency
Contact gap
Direct opening force (see note 5)
Direct opening travel (see note 5)
Holding force (see note 6)
Insulation resistance
Minimum applicable load (see note 7)
Rated insulation voltage (U
i
)
Rated open thermal current (I
th
)
Impulse withstand voltage (EN60947-5-1)
Mechanical
Electrical
IP67 (EN60947-5-1)
(This applies for the Switch only. The degree of protection for the key hole is IP00.)
1,000,000 operations min.
500,000 operations min. for a resistive load of 3 A at 250 VAC (see note 4)
0.05 to 0.5 m/s
30 operations/minute max.
50/60 Hz
2 x 2 mm min
60 N min. (EN60947-5-1)
10 mm min. (EN60947-5-1)
1,300 N min.
100 MΩ min. (at 500 VDC)
Resistive load of 1 mA at 5 VDC (N-level reference value)
300 V (EN60947-5-1)
10 A (EN60947-5-1)
Between terminals of the same polarity
Between terminals of different polarities
Between other terminals and uncharged metallic parts
Conditional short-circuit current
Pollution degree (operating environment)
Protection against electric shock
Contact resistance
Vibration resis-
tance
Shock resistance
Malfunction
Destruction
Malfunction
Ambient temperature
Ambient humidity
Weight
100 A (EN60947-5-1)
3 (EN60947-5-1)
Class II (double insulation)
25 mΩ max. per contact (initial value)
10 to 55 Hz, 0.75-mm single amplitude
1,000 m/s
2
min.
300 m/s
2
min. (100 m/s
2
min. for the lock monitor switch)
Operating:− C to 55° C with no icing
10°
Operating:95% max.
Approx. 370 g (D4NL-IAFA-B)
2.5 kV
4 kV
6 kV
Note: 1.
The above values are initial values.
2.
The degree of protection is tested using the method specified by the standard (EN60947-5-1). Confirm that sealing properties are suffi-
cient for the operating conditions and environment beforehand. Although the switch box is protected from dust or water penetration, do
not use the D4NL in places where foreign material may penetrate through the key hole on the head, otherwise Switch damage or mal-
functioning may occur.
3.
The durability is for an ambient temperature of 5° C to 35° C and an ambient humidity of 40% to 70%. For more details, consult your OM-
RON representative.
4.
If the ambient temperature is greater than 35° C, do not pass the 3-A, 250-VAC load through more than 2 circuits.
5.
These figures are minimum requirements for safe operation.
6.
This figure is based on the GS-ET-19 evaluation method.
7.
This value will vary with the switching frequency, environment, and reliability level. Confirm that correct operation is possible with the actual
load beforehand.
G-156
Safety Sensors / Components
Connections
Indicator
Internal Circuit Diagram
10 to 115 VAC/VDC
R
Z
D
R
LED
Constant-current diode
Circuit Connection Example
•
Terminals 12 and 41 are connected internally and so connect termi-
nals 11 and 42 for safety-circuit input. (GS-ET-19)
•
Connect terminals 21 and 22 and terminals 51 and 52 in series
when using as safety-circuit input (redundancy circuit for terminals
11 and 12 and terminals 41 and 42 above). Connect the terminals
individually when using as auxiliary-circuit input (e.g., terminals 21
and 22 for safety-door open/closed monitoring and terminals 51
and 52 for monitoring the lock status).
•
In the connection example on the right, terminals 21 and 22 and
terminals 51 and 52 are used as auxiliary-circuit input.
51
12
11
21
41
42
52
22
Safety
circuit
Auxiliary
circuit
Auxiliary
circuit
Auxiliary
circuit
33
E1 (+)
Indicator
(Orange)
34
E2 (−)
O1
O2
•
Direct opening contacts used as safety-circuit input are indicated
with the
mark. Terminals 11 and 12 and terminals 21 and 22
are direct opening contacts.
•
Connect the indicators in parallel to the auxiliary circuits or termi-
nals E1 and E2.
If an indicator is connected in parallel to a direct opening contact,
when the indicator breaks, a short-circuit current will be generated,
possibly resulting in an installation malfunction.
•
Do not switch standard loads for more than 2 circuits at the same
time. Otherwise, the level of insulation may decrease.
•
The 24-VDC solenoid has polarity. Be sure to connect terminals
with the correct polarity.
D4NL
G-157
D4NL
