K4B4G0446A-HYF80 datasheet, PDF

Datasheet> All Categories > storage> storage> K4B4G0446A-HYF80

K4B4G0446A-HYF80: DescriptionDDR DRAM, 1GX4, 0.3ns, CMOS, PBGA78, HALOGEN FREE AND ROHS COMPLIANT, FBGA-78; Categorystorage storage; File Size2MB，64 Pages; ManufacturerSAMSUNG; Websitehttp://www.samsung.com/Products/Semiconductor/; Environmental Compliance

Download Datasheet Parametric Compare View All

K4B4G0446A-HYF80 Overview

DDR DRAM, 1GX4, 0.3ns, CMOS, PBGA78, HALOGEN FREE AND ROHS COMPLIANT, FBGA-78

K4B4G0446A-HYF80 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	SAMSUNG
package instruction	TFBGA, BGA78,9X13,32
Reach Compliance Code	unknow
ECCN code	EAR99
access mode	MULTI BANK PAGE BURST
Maximum access time	0.3 ns
Other features	AUTO/SELF REFRESH; ALSO OPERATES AT 1.5V NOMINAL SUPPLY
Maximum clock frequency (fCLK)	533 MHz
I/O type	COMMON
interleaved burst length	8
JESD-30 code	R-PBGA-B78
length	12.5 mm
memory density	4294967296 bi
Memory IC Type	DDR DRAM
memory width	4
Number of functions	1
Number of ports	1
Number of terminals	78
word count	1073741824 words
character code	1000000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature
organize	1GX4
Output characteristics	3-STATE
Package body material	PLASTIC/EPOXY
encapsulated code	TFBGA
Encapsulate equivalent code	BGA78,9X13,32
Package shape	RECTANGULAR
Package form	GRID ARRAY, THIN PROFILE, FINE PITCH
power supply	1.35 V
Certification status	Not Qualified
refresh cycle	8192
Maximum seat height	1.2 mm
self refresh	YES
Continuous burst length	8
Maximum standby current	0.015 A
Maximum slew rate	0.145 mA
Maximum supply voltage (Vsup)	1.45 V
Minimum supply voltage (Vsup)	1.283 V
Nominal supply voltage (Vsup)	1.35 V
surface mount	YES
technology	CMOS
Temperature level	OTHER
Terminal form	BALL
Terminal pitch	0.8 mm
Terminal location	BOTTOM
width	10 mm

Preview

Download Datasheet

View All

Rev. 1.11, Jan. 2011

K4B4G0446A

K4B4G0846A

4Gb A-die DDR3L SDRAM

78FBGA with Lead-Free & Halogen-Free

(RoHS compliant)

1.35V

datasheet

SAMSUNG ELECTRONICS RESERVES THE RIGHT TO CHANGE PRODUCTS, INFORMATION AND

SPECIFICATIONS WITHOUT NOTICE.

Products and specifications discussed herein are for reference purposes only. All information discussed

herein is provided on an "AS IS" basis, without warranties of any kind.

This document and all information discussed herein remain the sole and exclusive property of Samsung

Electronics. No license of any patent, copyright, mask work, trademark or any other intellectual property

right is granted by one party to the other party under this document, by implication, estoppel or other-

wise.

Samsung products are not intended for use in life support, critical care, medical, safety equipment, or

similar applications where product failure could result in loss of life or personal or physical harm, or any

military or defense application, or any governmental procurement to which special terms or provisions

may apply.

For updates or additional information about Samsung products, contact your nearest Samsung office.

All brand names, trademarks and registered trademarks belong to their respective owners.

ⓒ

-1-

K4B4G0446A

K4B4G0846A

datasheet

Rev. 1.11

DDR3L SDRAM

Table Of Contents

4Gb A-die DDR3L SDRAM

1. Ordering Information ..................................................................................................................................................... 5

2. Key Features................................................................................................................................................................. 5

3. Package pinout/Mechanical Dimension & Addressing.................................................................................................. 6

3.1 x4 Package Pinout (Top view) : 78ball FBGA Package .......................................................................................... 6

3.2 x8 Package Pinout (Top view) : 78ball FBGA Package .......................................................................................... 7

3.3 FBGA Package Dimension (x4/x8) .......................................................................................................................... 8

4. Input/Output Functional Description.............................................................................................................................. 9

5. DDR3 SDRAM Addressing ........................................................................................................................................... 10

6. Absolute Maximum Ratings .......................................................................................................................................... 11

6.1 Absolute Maximum DC Ratings............................................................................................................................... 11

6.2 DRAM Component Operating Temperature Range ................................................................................................ 11

7. AC & DC Operating Conditions..................................................................................................................................... 11

7.1 Recommended DC operating Conditions ................................................................................................................ 11

8. AC & DC Input Measurement Levels ............................................................................................................................ 12

8.1 AC & DC Logic input levels for single-ended signals .............................................................................................. 12

8.2 V

REF

Tolerances...................................................................................................................................................... 14

8.3 AC & DC Logic Input Levels for Differential Signals ................................................................................................ 15

8.3.1. Differential signals definition ............................................................................................................................ 15

8.3.2. Differential swing requirement for clock (CK - CK) and strobe (DQS - DQS) .................................................. 15

8.3.3. Single-ended requirements for differential signals ........................................................................................... 17

8.4 Differential Input Cross Point Voltage...................................................................................................................... 18

8.5 Slew rate definition for Differential Input Signals ..................................................................................................... 19

8.6 Slew rate definitions for Differential Input Signals ................................................................................................... 19

9. AC & DC Output Measurement Levels ......................................................................................................................... 19

9.1 Single-ended AC & DC Output Levels..................................................................................................................... 19

9.2 Differential AC & DC Output Levels......................................................................................................................... 19

9.3 Single-ended Output Slew Rate .............................................................................................................................. 20

9.4 Differential Output Slew Rate .................................................................................................................................. 21

9.5 Reference Load for AC Timing and Output Slew Rate ............................................................................................ 21

9.6 Overshoot/Undershoot Specification ....................................................................................................................... 22

9.6.1. Address and Control Overshoot and Undershoot specifications...................................................................... 22

9.6.2. Clock, Data, Strobe and Mask Overshoot and Undershoot Specifications ...................................................... 23

9.7 34ohm Output Driver DC Electrical Characteristics................................................................................................. 23

9.7.1. Output Drive Temperature and Voltage Sensitivity .......................................................................................... 25

9.8 On-Die Termination (ODT) Levels and I-V Characteristics ..................................................................................... 25

9.8.1. ODT DC Electrical Characteristics ................................................................................................................... 26

9.8.2. ODT Temperature and Voltage sensitivity ....................................................................................................... 28

9.9 ODT Timing Definitions ........................................................................................................................................... 29

9.9.1. Test Load for ODT Timings.............................................................................................................................. 29

9.9.2. ODT Timing Definitions .................................................................................................................................... 29

10. IDD Current Measure Method..................................................................................................................................... 32

10.1 IDD Measurement Conditions ............................................................................................................................... 32

11. 4Gb DDR3 SDRAM A-die IDD Specification Table .................................................................................................... 41

12. Input/Output Capacitance ........................................................................................................................................... 42

13. Electrical Characteristics and AC timing for DDR3-800 to DDR3-1600 ...................................................................... 43

13.1 Clock Specification ................................................................................................................................................ 43

13.1.1. Definition for tCK(avg).................................................................................................................................... 43

13.1.2. Definition for tCK(abs).................................................................................................................................... 43

13.1.3. Definition for tCH(avg) and tCL(avg) .............................................................................................................. 43

13.1.4. Definition for note for tJIT(per), tJIT(per, Ick) ................................................................................................. 43

13.1.5. Definition for tJIT(cc), tJIT(cc, Ick) ................................................................................................................. 43

13.1.6. Definition for tERR(nper) ................................................................................................................................ 43

13.2 Refresh Parameters by Device Density................................................................................................................. 44

13.3 Speed Bins and CL, tRCD, tRP, tRC and tRAS for corresponding Bin ................................................................. 44

13.3.1. Speed Bin Table Notes .................................................................................................................................. 47

-3-

K4B4G0446A-HYF80 Related Products

	K4B4G0446A-HYF80	K4B4G0446A-HYK00	K4B4G0846A-HYK00	K4B4G0846A-HYF80	AH1NBGGB12	K4B4G0846A-HYH90
Description	DDR DRAM, 1GX4, 0.3ns, CMOS, PBGA78, HALOGEN FREE AND ROHS COMPLIANT, FBGA-78	DDR DRAM, 1GX4, 0.25ns, CMOS, PBGA78, HALOGEN FREE AND ROHS COMPLIANT, FBGA-78	DDR DRAM, 512MX8, 0.25ns, CMOS, PBGA78, HALOGEN FREE AND ROHS COMPLIANT, FBGA-78	DDR DRAM, 512MX8, 0.3ns, CMOS, PBGA78, HALOGEN FREE AND ROHS COMPLIANT, FBGA-78	Illuminated Pushbutton - 19mm	DDR DRAM, 512MX8, 0.3ns, CMOS, PBGA78, HALOGEN FREE AND ROHS COMPLIANT, FBGA-78
Is it Rohs certified?	conform to	conform to	conform to	conform to	-	conform to
Maker	SAMSUNG	SAMSUNG	SAMSUNG	SAMSUNG	-	SAMSUNG
package instruction	TFBGA, BGA78,9X13,32	TFBGA, BGA78,9X13,32	TFBGA, BGA78,9X13,32	TFBGA, BGA78,9X13,32	-	TFBGA, BGA78,9X13,32
Reach Compliance Code	unknow	compliant	compliant	unknown	-	compliant
ECCN code	EAR99	EAR99	EAR99	-	-	EAR99
access mode	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	MULTI BANK PAGE BURST	-	MULTI BANK PAGE BURST
Maximum access time	0.3 ns	0.25 ns	0.25 ns	0.3 ns	-	0.3 ns
Other features	AUTO/SELF REFRESH; ALSO OPERATES AT 1.5V NOMINAL SUPPLY	AUTO/SELF REFRESH	AUTO/SELF REFRESH	AUTO/SELF REFRESH; ALSO OPERATES AT 1.5V NOMINAL SUPPLY	-	AUTO/SELF REFRESH
Maximum clock frequency (fCLK)	533 MHz	800 MHz	800 MHz	533 MHz	-	667 MHz
I/O type	COMMON	COMMON	COMMON	COMMON	-	COMMON
interleaved burst length	8	8	8	8	-	8
JESD-30 code	R-PBGA-B78	R-PBGA-B78	R-PBGA-B78	R-PBGA-B78	-	R-PBGA-B78
length	12.5 mm	12.5 mm	12.5 mm	12.5 mm	-	12.5 mm
memory density	4294967296 bi	4294967296 bit	4294967296 bit	4294967296 bit	-	4294967296 bit
Memory IC Type	DDR DRAM	DDR DRAM	DDR DRAM	DDR DRAM	-	DDR DRAM
memory width	4	4	8	8	-	8
Number of functions	1	1	1	1	-	1
Number of ports	1	1	1	1	-	1
Number of terminals	78	78	78	78	-	78
word count	1073741824 words	1073741824 words	536870912 words	536870912 words	-	536870912 words
character code	1000000000	1000000000	512000000	512000000	-	512000000
Operating mode	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	SYNCHRONOUS	-	SYNCHRONOUS
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	-	85 °C
organize	1GX4	1GX4	512MX8	512MX8	-	512MX8
Output characteristics	3-STATE	3-STATE	3-STATE	3-STATE	-	3-STATE
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	-	PLASTIC/EPOXY
encapsulated code	TFBGA	TFBGA	TFBGA	TFBGA	-	TFBGA
Encapsulate equivalent code	BGA78,9X13,32	BGA78,9X13,32	BGA78,9X13,32	BGA78,9X13,32	-	BGA78,9X13,32
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	-	RECTANGULAR
Package form	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	GRID ARRAY, THIN PROFILE, FINE PITCH	-	GRID ARRAY, THIN PROFILE, FINE PITCH
power supply	1.35 V	1.35 V	1.35 V	1.35 V	-	1.35 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	-	Not Qualified
refresh cycle	8192	8192	8192	8192	-	8192
Maximum seat height	1.2 mm	1.2 mm	1.2 mm	1.2 mm	-	1.2 mm
self refresh	YES	YES	YES	YES	-	YES
Continuous burst length	8	8	8	8	-	8
Maximum standby current	0.015 A	0.015 A	0.015 A	0.015 A	-	0.015 A
Maximum slew rate	0.145 mA	0.185 mA	0.195 mA	0.15 mA	-	0.19 mA
Maximum supply voltage (Vsup)	1.45 V	1.45 V	1.45 V	1.45 V	-	1.45 V
Minimum supply voltage (Vsup)	1.283 V	1.283 V	1.283 V	1.283 V	-	1.283 V
Nominal supply voltage (Vsup)	1.35 V	1.35 V	1.35 V	1.35 V	-	1.35 V
surface mount	YES	YES	YES	YES	-	YES
technology	CMOS	CMOS	CMOS	CMOS	-	CMOS
Temperature level	OTHER	OTHER	OTHER	OTHER	-	OTHER
Terminal form	BALL	BALL	BALL	BALL	-	BALL
Terminal pitch	0.8 mm	0.8 mm	0.8 mm	0.8 mm	-	0.8 mm
Terminal location	BOTTOM	BOTTOM	BOTTOM	BOTTOM	-	BOTTOM
width	10 mm	10 mm	10 mm	10 mm	-	10 mm
