ESQ–110–44–T–D
F-209-1
ESQ–132–14–G–D
Through
ESW–115–12–G–S
T/H
Hole
ELEVATED SOCKETS
ESW & ESQ SERIES
TYPE
STRIP
Mates with:
TSW, MTSW, EW, MTLW,
TSS, ZSS,
TSM, DW, ZW, HW
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?ESW
or www.samtec.com?ESQ
Insulator Material:
Black Glass Filled
Polyester
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27µm) Ni
Current Rating:
3A continuous
Voltage Rating:
550 VAC mated with
TSW or ESQ
Operating Temp Range:
-55°C to +125°C with Gold
-55°C to +105°C with Tin
Contact Resistance:
10 mΩ max
Insertion Depth:
(3,68mm) .145" to
(6,35mm) .250"
Insertion Force:
(Single contact only)
(–S plating)
Standard = 6oz (1,67N) avg.
((0,64mm) .025" SQ pin);
ESW Low Inser tion Force=
3oz (0,83N) avg.
ESQ Low Insertion Force=
3.3oz (0,92N) avg.
Normal Force:
Standard = 125 grams (4,4N)
Withdrawal Force:
(Single contact only)
(–S plating)
Standard = 5oz (1,39N) avg.
((0,64mm) .025" SQ pin);
ESW Low Inser tion Force=
2.6oz (0,72N) avg.
ESQ Low Insertion Force=
2.9oz (0,81N) avg.
Max Cycles:
100 with 10µ" (0,25µm) Au
RoHS Compliant:
Yes
Lead-Free Solderable:
Wave only
ESW
= Solder Tail
–L
= 10µ" (0,25µm)
Gold contact,
Matte Tin on tail (ESQ only)
–S
= Single
Row
–LL
= Locking
Lead
ESQ
= Square Tail
–G
= 20µ" (0.51µm)
Gold contact,
Gold Flash on Balance
–D
= Double
Row
01 thru 36
(2,54) .100 X No. of Positions + (0,51) .020
–T
= Triple
Row
(ESQ only)
–S
= 30µ" (0,76µm)
Gold contact,
Matte Tin on Tail
(2,41)
.095
Two leads per
strip crimped.
N/A with single
row 1 or 2
positions.
–S
01
72
–T
= Matte Tin
(N/A w/LIF contact)
–“XXX”
= Polarized
(2,54)
.100
36
02
–D
(2,54)
.100
71
(4,95)
.195
(2,54)
.100
01
Specify LEAD STYLE
from chart below.
LOW
STANDARD
INSERTION FORCE INSERTION FORCE
A
(2,29)
.090
(7,36)
.290
(4,83)
.190
(2,29)
.090
(12,19)
.480
(9,65)
.380
(7,11)
.280
(4,57)
.180
B
(11,05)
.435
(13,59)
.535
(16,13)
.635
(11,05)
.435
(13,59)
.535
(16,13)
.635
(18,67)
.735
108
03
– 12
(7,49)
.295
– 37
– 38
– 48
– 58
– 39
– 49
– 59
– 69
(5,08)
.200 (2,54)
.100
– 13
– 23
– 33
– 14
– 24
– 34
– 44
B
(ESQ
only)
–T
106
01
A
APPLICATIONS
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(2,54)
.100
TYP
ESW
(0,41) x (0,79)
.016 .031
ESQ
(0,64)
.025
SQ
Self g
Nestints
Socke
(ESQ Series)
PC/104 J1/P1 “Stackthrough” Connectors
Standard Insertion Force
ESQ-132-14-G-D
Low Insertion Force
ESQ-132-39-G-D
PC/104 J1 “Non-Stackthrough” Connectors
Standard Insertion Force
ESQ-132-12-G-D
Low Insertion Force
ESQ-132-37-G-D
PC/104 J2/P2 “Stackthrough” Connectors
Standard Insertion Force
ESQ-120-14-G-D
Low Insertion Force
ESQ-120-39-G-D
PC/104 is a trademark of the PC/104 Consortium.
