5646188-2

Description
CONNECTOR, 80 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, PLUG, ROHS COMPLIANT
CategoryThe connector    The connector
File Size118KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

5646188-2 Overview

CONNECTOR, 80 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, PLUG, ROHS COMPLIANT

5646188-2 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTE Connectivity
package instructionROHS COMPLIANT
Reach Compliance Codeunknow
Body/casing typePLUG
Connector typeBOARD CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderMALE
Contact materialPHOSPHOR BRONZE
DIN complianceNO
Filter functionNO
IEC complianceNO
MIL complianceNO
Manufacturer's serial number5646188
Mixed contactsNO
Installation methodSTRAIGHT
Installation typeBOARD
OptionsGENERAL PURPOSE
Terminal pitch2.54 mm
Total number of contacts80
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Backplane/Midplane
>
Product Feature Selector
> Product Details
5646188-2 Product Details
Live Product Chat
.100 Centerline Stripline Connectors (Z-PACK SL 100)
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5646188-2
T E I nternal N umber: 5 6 4 6 1 8 8 - 2
Product Highlights:
l
C onnector Type = Plug
l
PC B Mount Angle = Vertical
l
Body Style = Modular
l
Module Type = C enter
l
80 Positions/Module
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
C onnector Type = Plug
l
PC B Mount Angle = Vertical
l
Body Style
= Modular
l
PC B Retention Feature
= No
l
For Use With = High Performance C able Assemblies
Mechanical Attachment:
l
Module Type
= C enter
l
Number of Positions/Module
= 80
l
Lead Length (mm [in])
= 13.59 [0.535]
l
Power/Ground Blade Length (mm [in]) = 6.02 [0.237]
l
Signal Pin Post Length (mm [in]) = 4.45 [0.175]
l
Stiffener Material = Aluminum
Termination Related Features:
l
Solder Tail C ontact Plating = Nickel
Contact Related Features:
l
C ontact Plating, Mating Area, Material = Gold (50)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Liquid C rystal Polymer (LC P)
l
Housing C olor = Black
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
