DR362 SERIES, HIGH CURRENT, HIGH TEMPERATURE INDUCTORS
Features
Low EMI
High Current Capacity
Operating Temp. -55°C to +200°C
Horizontal or Vertical mount
(Note 5)
Tinned Leads with Leaded Solder is Available
(note 7)
Dim.
A
Nom.
0.34
0.34
0.34
0.34
0.34
0.34
0.34
0.34
0.34
0.34
0.33
0.33
0.33
0.33
0.32
0.32
0.35
0.35
0.35
0.35
0.35
0.35
0.35
0.34
0.34
0.34
0.35
0.35
0.35
0.33
0.35
0.35
0.35
0.37
0.37
Dim.
B
Nom.
0.77
0.77
0.77
0.77
0.77
0.77
0.77
0.77
0.77
0.77
0.76
0.76
0.76
0.76
0.75
0.75
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.77
0.77
0.77
0.79
0.79
0.79
0.76
0.79
0.79
0.79
0.81
0.81
Dim.
C
Nom.
0.053
0.053
0.053
0.053
0.053
0.053
0.053
0.053
0.053
0.053
0.042
0.042
0.042
0.042
0.034
0.034
0.034
0.034
0.034
0.034
0.034
0.034
0.034
0.027
0.027
0.027
0.027
0.027
0.027
0.022
0.022
0.022
0.022
0.022
0.022
Part
Number
DR362-X-102
DR362-X-152
DR362-X-222
DR362-X-272
DR362-X-332
DR362-X-392
DR362-X-472
DR362-X-562
DR362-X-682
DR362-X-822
DR362-X-103
DR362-X-123
DR362-X-153
DR362-X-183
DR362-X-223
DR362-X-273
DR362-X-333
DR362-X-393
DR362-X-473
DR362-X-563
DR362-X-683
DR362-X-823
DR362-X-104
DR362-X-124
DR362-X-154
DR362-X-184
DR362-X-224
DR362-X-274
DR362-X-334
DR362-X-394
DR362-X-474
DR362-X-564
DR362-X-684
DR362-X-824
DR362-X-105
L(µH)
±15% (1)
1.0
1.5
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
L(µH)±15%
@ I rated
(2)
0.8
1.2
1.8
2.1
2.6
3.0
3.5
4.1
4.9
5.9
7.6
9.0
11.0
13.0
16.6
20.1
24.0
28.0
33.1
38.5
46.0
54.0
64.5
84.4
102.8
120.7
144.2
172.6
206.0
266.7
314.4
366.9
435.1
512.0
608.2
Idc
(A)
21.7
19.8
18.3
17.1
16.1
15.3
14.9
14.3
13.7
13.2
9.9
9.6
9.1
8.6
6.7
6.4
6.1
5.9
5.6
5.3
5.1
4.8
4.6
3.5
3.3
3.1
3.0
2.8
2.7
2.1
2.0
1.9
1.8
1.7
1.6
NOTES
(1)
OCL measured at .25VRMS, 1kHz.
(2)
Rated Current tested at .25VRMS, 1kHz
(3)
All materials are rated at 200ºC
(4)
Electrical Specifications at 25°C
(5)
DR362-2-XXX denotes vertical design.
DR362-1-XXX denotes horizontal design
(6)
All dimensions are shown in inches “in”. General
tolerance is ±0.010in, unless otherwise specified.
(7)
For non-RoHS parts replace DR prefix
with 42- (e.g. DR362 becomes 42-362)
(8)
Terminal finish is compliant to RoHS
requirements
.
DCR (Ω)
(MAX)
0.003
0.003
0.004
0.004
0.005
0.005
0.006
0.006
0.006
0.007
0.012
0.013
0.014
0.016
0.026
0.028
0.031
0.033
0.036
0.040
0.044
0.049
0.053
0.094
0.11
0.12
0.13
0.14
0.16
0.27
0.29
0.32
0.35
0.39
0.43
1
0.86
MAX
B
C
0.45
MAX
0.86
MAX
2
Schematic
C
Vertical
DR362-2-XXX
DATATRONIC
:
0.45
MAX
A
Horizontal
DR362-1-XXX
