SW-207: DescriptionGaAs SPDT Switch 5 - 3000 MHz; CategoryWireless rf/communication Radio frequency and microwave; File Size74KB，2 Pages; ManufacturerMACOM; Websitehttp://www.macom.com

Download Datasheet Parametric Compare View All

SW-207 Overview

GaAs SPDT Switch 5 - 3000 MHz

SW-207 Parametric

Parameter Name	Attribute value
Maker	MACOM
Reach Compliance Code	unknow
Characteristic impedance	50 Ω
structure	COMPONENT
Maximum insertion loss	2.3 dB
Maximum operating frequency	4000 MHz
Minimum operating frequency	5 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	SPDT
Maximum voltage standing wave ratio	2.5

Preview

Download Datasheet

View All

GaAs SPDT Switch

5 - 3000 MHz

Features

q

SW-207

V2.00

DI-1

CTL

0.87

(22.1 0.5)

RF IN

Low Insertion Loss: 1.0 dB Typ.

Fast Switching Speed

Low DC Power Consumption

Integral TTL

MIL-STD-883 Screening Available

(From -55°C to +85°C)

5 - 3000 MHz

5 - 2000 MHz

5 - 1000 MHz

2.3 dB Max.

1.4 dB Max.

1.0 dB Max.

2.5:1 Max.

1.7:1 Max.

1.5:1 Max.

18 dB Min.

28 dB Min.

38 dB Min.

0.018

±0.005

(0.46

±0.13)

DIA.

14 PINS

–

+

RF1

RF2

Guaranteed Speciﬁcations*

Frequency Range

Insertion Loss

0.200

(5.1) MAX

0.100

(2.5) TYP

0.120

(3.0) MIN

VSWR

5 - 3000 MHz

5 - 2000 MHz

5 - 1000 MHz

Isolation

5 - 3000 MHz

5 - 2000 MHz

5 - 1000 MHz

0.300

(7.6)

0.50

(12.7 0.5)

0.10

(2.5 0.5)

0.13

(3.3 0.5)

Operating Characteristics

Impedance

Switching Characteristics

t

RISE,

t

FALL

t

ON,

t

OFF (50% CTL to 90/10% RF)

Transients (In-Band)

Input Power for 1 dB Compression

0.5 - 3 GHz

0.05 GHz

Intermodulation Intercept Point

(for two-tone input power up to +13 dBm)

Intercept Points

0.5 - 3 GHz

0.05 GHz

Bias Power

IP2

+ 68 dBm Typ.

+ 60 dBm Typ.

IP3

+ 46

+40

+5 VDC @ 1 mA Max.

50 Ohms Nominal

7 ns Typ.

20 ns Typ.

70 mV Typ.

+ 27 dBm Typ.

+ 21 dBm Typ.

Dimensions in ( ) are in mm.

Unless Otherwise Noted: .xxx = ±0.010 (.xx = ±0.25)

.xx = ±0.02 (.x = ±0.5)

(POSITIVE VOLTAGES ONLY)

WEIGHT (APPROX.) : 0.14 OUNCES 4 GRAMS

* All speciﬁcations apply when operated with bias voltages

of + 5 VDC and 50 ohm impedance at all RF ports.

Ordering Information

Part No.

SW-207 PIN

Package

Dual Inline

Speciﬁcations Subject to Change Without Notice.

M/A-COM, Inc.

North America:

Tel. (800) 366-2266

Fax (800) 618-8883

s

1

Asia/Paciﬁc: Tel. +81 (03) 3226-1671

Fax +81 (03) 3226-1451

s

Europe: Tel. +44 (1344) 869 595

Fax +44 (1344) 300 020
