FPC Connector
CIC
Type (H=2.4mm)
1.0mm Spacing (SMT)
CFP24
-01
F
No. of Pins
B
A
●
Upper Contact Type
××
01
02
11
12
Hold Down Packing Style
With
Without
With
Without
(2.0)
Embossed Taping
Embossed Taping
Pack in Bulk
Pack in Bulk
1.0(Spacing)
C
3.4
1. FPC connector usable with CIC (Carbon in
Circuit) printing.
2. Either upper or lower contact location available.
3. Of the ZIF structure.
4. Supplied in emboss-tape packaging for
automatic mounting.
5. A lead-free product.
0.3
2.4
1.0
D
2.4
●
Lower Contact Type
B
A
CFP25
1.7
■
Features
1.5
5.2
-01
××
01
02
11
12
F
Hold Down Packing Style
With
Without
With
Without
(2.0)
Embossed Taping
Embossed Taping
Pack in Bulk
Pack in Bulk
No. of Pins
■
Specifications
1. Rating : 0.5A, 100V AC/DC
2. Contact Resistance : 30mΩ, max.
3. Insulation Resistance : 500MΩ, min. at 500V DC
4. Withstanding Voltage : 500V AC for one minute
5. Operating Temperature Range : –25˚C to +70˚C
1.0(Spacing)
C
3.4
●
Housing : Polyphenylene Sulfide (PPS),
Natural Color, 94V-0
●
Cover : Polyphenylene Sulfide (PPS),
Natural Color, 94V-0
●
Contact : Phosphor Bronze, Sn Plating
●
Frame : Phosphor Bronze, Sn Plating
1.5
■
Material and Plating
0.3
2.4
1.0
D
1.7
5.2
2.4
No. of Pins
04
05
06
07
08
09
10
11
12
13
14
15
A
3.0
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
14.0
B
5.1
6.1
7.1
8.1
9.1
10.1
11.1
12.1
13.1
14.1
15.1
16.1
C
9.7
10.7
11.7
12.7
13.7
14.7
15.7
16.7
17.7
18.7
19.7
20.7
D
4.5
5.5
6.5
7.5
8.5
9.5
10.5
11.5
12.5
13.5
14.5
15.5
No. of Pins
16
17
18
19
20
21
22
24
26
28
29
30
A
15.0
16.0
17.0
18.0
19.0
20.0
21.0
23.0
25.0
27.0
28.0
29.0
B
17.1
18.1
19.1
20.1
21.1
22.1
23.1
25.1
27.1
29.1
30.1
31.1
C
21.7
22.7
23.7
24.7
25.7
26.7
27.7
29.7
31.7
33.7
34.7
35.7
D
16.5
17.5
18.5
19.5
20.5
21.5
22.5
24.5
26.5
28.5
29.5
30.5
■ P.C. Board Dimension
2.4
0.5
0.25
■ Applicable FPC Dimension
（t＝0.3±0.05）
Silver ink/carbon paste : 10µm min.
2.0
2.6
1.0
±
0.05
A
±
0.05
+
0.1
(D 0.6)
0
0.5
+
0.1
0
4.0min.
3.0
R
4
0.
1.0
±
0.05
A
±
0.05
(A 2)
±
0.1
●
FPC plating to recommend : Sn plating
0.7
±
0.08
1.0
±
0.15
18
