AXIAL LEADED HIGH
FREQUENCY INDUCTOR
This axial leaded series features one convenient small size
with 51 values of inductance, ranging from 3.9µH to
150000µH. Its size makes it easy to incorporate in any
design. RL-1295 high resistivity and low loss core is excel-
lent for high frequency applications. Also available taped &
reeled for auto insertion.
RL-1295
Typical Applications:
• Switching Regulators
• Power Supplies
• Filters
• Surge Suppression
• Radio Frequency
(B)
1.00”
(MIN)
(A)
0.525”
(MAX)
Ø0.400”
(MAX)
TERMINALLEADS .032” TYP
SIDE VIEW
END VIEW
Leads: .032 in. #20 AWG Tinned Copper Wire (Typ.)
NOTES:
1)
2)
3)
4)
5)
Inductance ±15% measured at 1kHz.
Saturation current lowers inductance 5%.
Coils finished sleeving VW1 rating.
Max. Temperature Range -55°C to +130°C.
10% and 5% tolerances optional for values above 10µH.
RENCO ELECTRONICS, INC.
SINCE 1955
595 International Place, Rockledge, FL 32955-4200 USA
(321) 637-1000 • Toll Free Engineering Hot Line 800-645-5828
Fax: (321) 637-1600
Web Site:www.rencousa.com
E-Mail:sales@rencousa.com
RL-1295
Renco Part No.
Inductance
at 0 DC
(µH)
Rdc
(Ohlms)
@ +20C
max.
Saturation
Current
(DC Amps)
Approx.
Suggested
Rated
Current
(Amps)
RL-1295-3.9
RL-1295-4.7
RL-1295-5.6
RL-1295-6.8
RL-1295-8.2
RL-1295-10
RL-1295-12
RL-1295-15
RL-1295-18
RL-1295-22
RL-1295-27
RL-1295-33
RL-1295-39
RL-1295-47
RL-1295-56
RL-1295-68
RL-1295-82
RL-1295-100
RL-1295-120
RL-1295-150
RL-1295-180
RL-1295-220
RL-1295-270
RL-1295-330
RL-1295-390
RL-1295-470
RL-1295-560
RL-1295-680
RL-1295-820
RL-1295-1000
RL-1295-1200
RL-1295-1500
RL-1295-1800
RL-1295-2200
RL-1295-2700
RL-1295-3300
RL-1295-3900
RL-1295-4700
RL-1295-5600
RL-1295-6800
RL-1295-8200
RL-1295-10000
RL-1295-12000
RL-1295-15000
RL-1295-18000
RL-1295-22000
RL-1295-27000
RL-1295-33000
RL-1295-39000
RL-1295-47000
RL-1295-56000
RL-1295-68000
RL-1295-82000
RL-1295-100000
RL-1295-120000
RL-1295-150000
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
27000
33000
39000
47000
56000
68000
82000
100000
120000
150000
0.012
0.014
0.015
0.018
0.020
0.020
0.021
0.022
0.025
0.030
0.040
0.042
0.046
0.055
0.070
0.080
0.100
0.115
0.135
0.180
0.205
0.240
0.310
0.340
0.390
0.460
0.550
0.790
0.900
1.100
1.25
1.50
1.65
2.65
3.10
3.6
4.6
5.1
5.8
8.5
9.5
10.5
13.5
17.0
19.5
22.5
30.0
35.0
46.0
67.0
76.0
85.0
96.0
108.0
135.0
180.0
5.0
5.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
2.5
2.25
2.25
2.0
2.0
1.8
1.7
1.4
1.4
1.1
1.00
1.00
0.84
0.76
0.76
0.60
0.60
0.50
0.50
0.40
0.40
0.30
0.30
0.25
0.25
0.24
0.22
0.20
0.18
0.13
0.120
0.120
0.110
0.100
0.100
0.100
0.080
0.080
0.075
0.070
0.060
0.060
0.050
0.050
0.045
0.042
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.3
1.0
1.0
1.0
1.0
0.80
0.80
0.65
0.65
0.65
0.50
0.50
0.50
0.40
0.40
0.40
0.40
0.32
0.26
0.26
0.20
0.20
0.20
0.20
0.13
0.13
0.13
0.10
0.10
0.10
0.08
0.08
0.08
0.065
0.05
0.05
0.05
0.04
0.04
0.03
0.025
0.025
0.025
0.025
0.025
0.020
0.016
