Photoelectrics
Fibre Optics, Glass
Types FGT, FGD
• Fibre diameter
∅1
mm (400 x 50
µm)
• Temperature range from -25°C up to 200°C
• Bending radius 10, 20 or 30 mm
• Sheath material PVC/thermo polyolefine, metallic
spiral/polyolefine or flexible INOX
Type Selection
Length Distance
1)
[cm]
[mm]
60
100
150
200
60
100
150
200
60
100
200
200
200
200
80
80
80
80
200
200
20
M4
Dimensions
[mm]
9
10
Standard glass
Ordering no.
FGT 01 SCM 060
FGT 01 SCM 100
FGT 01 SCM 150
FGT 01 SCM 200
FGD 02 SCM 060
FGD 02 SCM 100
FGD 02 SCM 150
FGD 02 SCM 200
FGT 03 SCM 060
Reinforced metal
Ordering no.
FGT 01 MCM 060
FGT 01 MCM 100
FGT 01 MCM 150
FGT 01 MCM 200
FGD 02 MCM 060
FGD 02 MCM 100
FGD 02 MCM 150
FGD 02 MCM 200
High temperature
Ordering no.
FGT 01 TCM 060
FGT 01 TCM 100
FGT 01 TCM 150
FGT 01 TCM 200
FGD 02 TCM 060
FGD 02 TCM 100
FGD 02 TCM 150
FGD 02 TCM 200
Ø5
9
10
M4
9
Ø6.5
10
FGT 03 TCM 100
Ø2.5
M4
Ø5
60
100
150
200
60
80
80
80
80
200
20
9
12
FGD 04 SCM 060
FGD 04 SCM 100
FGD 04 SCM 150
FGD 04 MCM 060
FGD 04 MCM 100
FGD 04 MCM 150
FGD 04 TCM 060
FGD 04 TCM 100
FGD 04 TCM 200
Ø2.5
90
M4
9
Ø6.5
10
FGT 05 SCM 060
Ø2.5
90
M4
9
Ø5
12
60
100
200
80
80
80
FGD 06 SCM 060
FGD 06 SCM 100
FGD 06 SCM 200
FGD 06 MCM 060
FGD 06 MCM 100
FGD 06 TCM 100
FGD 06 TCM 200
Ø2.5
6
M4
8
Ø6.5
12
60
100
150
200
60
100
150
200
1)
80
80
80
80
200
200
200
200
M4
Ø3.5
Ø6.5
FGD 07 SCM 060
FGD 07 SCM 100
FGD 07 SCM 150
FGD 07 SCM 200
FGT 07 SCM 060
FGT 07 SCM 100
FGT 07 SCM 150
FGD 07 MCM 060
FGD 07 MCM 100
FGD 07 MCM 150
FGT 07 MCM 060
FGT 07 MCM 100
FGT 07 MCM 150
FGT 07 MCM 200
FGD 07 TCM 060
FGD 07 TCM 100
FGD 07 TCM 150
FGD 07 TCM 200
FGT 07 TCM 060
FGT 07 TCM 100
FGT 07 TCM 200
Sensing distance given for a fibre length up to 1 m.
Specifications are subject to change without notice (13.05.02)
1
FGT, FGD
General Specifications
Bending radius
FG...SCM...:
FG...MCM...:
FG...TCM...:
Temperature range
FG...SCM...:
FG...MCM...:
FG...TCM...:
10 mm
20 mm
30 mm
-25 to +60ºC (-13 to +140ºF)
-25 to +120ºC (-13 to +248ºF)
-25 to +200ºC (-13 to +392ºF)
Sheath material
FG...SCM...:
FG...MCM...:
FG...TCM...:
Fibre
Diameter
Attenuation vs. length (@ 4 m)
PVD and thermo polyolefine
Metallic spiral and polyolefine
Flexible INOX
∅1
mm, 400 x 50
µm
Through beam:
≤
20%
Diffuse:
≤
35%
Attenuation vs. bending radius r = 15 mm:
≤
3%
r = 10 mm:
≤
15%
Accessories - Lenses for FGT 01.. Fibre Optic
AFGT 03
Sensing range: 800 mm
18
Ø5
AFGT 04
Sensing range: 800 mm
17
Ø 6.5
11
AFGD 05
Focus point: 10 mm
Ø6.5
25
AFGT 06
Sensing range: 3000 mm
15
13
13x12
AFGT 07
Sensing range: 3000 mm
20
Ø8.5
AFGD 08
Focus point: 30 mm
35
Ø8.5
Ordering Key
FGT 01 SCS 200
Optic Fibre
Fibre material
G Glass
Fibre type
D
Diffuse
T
Through-beam
Sensor head 01-99
Forthrunning type number
Sheath material
S
Standard glass, PVC and thermo polyolefine
M Metallic spiral and polyolefine
T
Flexible INOX
Fibre diameter
C
1.0 mm
Core condition
M Multicore
Fibre length 001-999
cm 1 cm to 9.9 m
2
8x8
Specifications are subject to change without notice (13.05.02)
Ø8
