FR101G THRU FR107G
GLASS PASSIVATED FAST RECOVERY RECTIFIER
Reverse Voltage – 50 to 1000 V
Forward Current – 1 A
Features
• Fast switching for high efficiency
• High current capability
Mechanical Data
• Case: Molded plastic, DO-41
• Epoxy: UL 94V-0 rate flame retardant
• Lead: Axial leads, solderable per MIL-STD-202,
Method 208 guaranteed
• Polarity: Color band denotes cathode end
• Mounting Position: Any
Maximum Ratings and Electrical Characteristics
Ratings at 25
O
C ambient temperature unless otherwise specified. Single phase, half-wave, 60 Hz, resistive or
inductive load, for capacitive load, derate current by 20%.
Parameter
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current 0.375"
(9.5 mm) Lead Length at T
A
= 55
O
C
Peak Forward Surge Current 8.3 ms Single Half
Sine-Wave Superimposed on Rated Load (JEDEC
Method)
Maximum Forward Voltage at 1 A
Maximum Reverse Current
at Rated DC Blocking Voltage
Typical Junction Capacitance
1)
Typical Thermal Resistance
2)
Maximum Reverse Recovery Time
3)
Operating and Storage temperature range
1)
2)
Symbols
FR101G FR102G FR103G FR104G FR105G FR106G FR107G
Units
V
RRM
V
RMS
V
DC
I
F(AV)
50
35
50
100
70
100
200
140
200
400
280
400
1
600
420
600
800
560
800
1000
700
1000
V
V
V
A
I
FSM
V
F
30
1.3
5
50
12
50
150
250
- 55 to + 150
500
O
A
V
µA
pF
C/W
nS
O
T
A
= 25
O
C
T
A
= 100
O
C
I
R
C
J
R
θ
JA
t
rr
T
j
, T
stg
C
Measured at 1 MHz and applied reverse voltage of 4 V D.C.
Thermal resistance from junction to ambient 0.375"(9.5 mm) lead length P.C.B mounted.
3)
Reverse recovery test conditions: I
F
= 0.5 A, I
R
= 1 A, I
rr
= 0.25 A.
SEMTECH ELECTRONICS LTD.
(Subsidiary
of Sino-Tech International Holdings Limited, a company
listed on the Hong Kong Stock Exchange, Stock Code: 724)
®
Dated : 15/01/2007 H
