POWER THIN FILM ATTENUATORS
MSAT-5
TOP CONTACT W/ GOLD BACK
MSAT MSAT MSAT
MSAT-5, MSAT-6, MSAT-7 SERIES
The MSAT series Thin Film Power chip attenuators provide attenuation accuracy for frequencies through
MSAT
20 GHz. They offer the low noise, low stray capacitance and tight tolerance of Thin Film in compact sizes that
make them ideal for smaller microwave and stripline applications at operating powers to 2 Watts.
DAT
MECHANICAL DATA
SIZE
SUBSTRATE
SUBSTRATE
BOND PADS
BACKSIDE SURFACE
MATERIAL
RESISTOR MATERIAL
INPUT
OUTPUT
0.148" x 0.122" (±0.003") x 0.025" (±0.003")
99.6% ALUMINA
25K Å MIN. GOLD; WIRE OR RIBBON BONDABLE, OR SOLDERABLE.
GOLD
ANTALUM
TANTALUM NITRIDE
DAT
ELECTRICAL DATA
GROUND
MSAT-6
TOP CONTACT W/ WRAPAROUND GROUND
TTENUATION
ATTENUATION RANGE
TTENUATION
ATTENUATION ACCURACY
FREQUENCY RANGE
IMPEDANCE
VSWR
-1dB THROUGH -24dB; ( 0.5dB STEPS AVAILABLE )
±0.2dB
DC THROUGH 20 GHz
50Ω
50
Ω
1.5:1 MAX.
DAT
COMMON SERIES DATA
CURRENT NOISE
POWER RATING
RATING
T.C.R.
HIGH TEMP EXPOSURE
THERMAL SHOCK
STABILITY
STABILITY
OPERATING
OPERATING TEMP RANGE
STRAY DISTRIBUTED
STRAY
CAPACIT
ACITANCE
CAPACITANCE
ALUMINA
-20dB TYPICAL
2 WATTS, (70°C DERATED LINEARLY TO 150°C) P = E
2
/R
WA
DERATED LINEARLY
±150ppm/°C
±0.25%
0.03
03%
150°C, 100 HRS., ±0.25% MAX.
∆
R/R: ±0.03% MSI TYPICAL
MIL-STD 202, METHOD 107F, ±0.25% MAX.
∆
R/R: ±0.1% MSI TYPICAL
107F, ±0.25%
70°C,
POWER, ±0.5%
1000 HRS., 70°C, 100% POWER, ±0.5% MAX.
∆
R/R: ±0.1% MSI TYPICAL
-55
-55°C TO +150°C
CHIP
TTENUATORS
ATTENUATORS
INPUT
OUTPUT
0.06pF
PART NUMBER DESIGNATION
DESIGNATION
GROUND
MSAT
MSAT
SERIES
XG
5
6
7
dB
MSAT-7
FULLY SURFACE MOUNTABLE
MSAT
(MSAT
EXAMPLE: MSAT 7G-03dB (MSAT 7 Series: -3dB)
INPUT
OUTPUT
GROUND
MINI-SYSTEMS, INC.
THIN FILM DIVISION
DAVID
ATTLEBORO,
20 DAVID ROAD, N. ATTLEBORO, MA 02760
508-695-0203 FAX: 508-695-6076
DCN TF 124-D-0306
