PDL03-24S05H

Description
Analog Circuit,
CategoryAnalog mixed-signal IC    The signal circuit
File Size387KB，3 Pages
ManufacturerPower Mate Tech
Environmental Compliance
Download Datasheet Parametric Compare View All

PDL03-24S05H Overview

Analog Circuit,

PDL03-24S05H Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerPower Mate Tech
Reach Compliance Codecompli
Maximum input voltage36 V
Minimum input voltage18 V
Number of terminals6
Maximum operating temperature100 °C
Minimum operating temperature-40 °C
Maximum output current0.6 A
Nominal output voltage5 V
Package body materialPLASTIC/EPOXY
Encapsulate equivalent codeSIP6/8,.23
Certification statusNot Qualified
surface mountNO
Temperature levelINDUSTRIAL
Terminal pitch2.54 mm
Terminal locationSINGLE

Preview

Download Datasheet
APPLICATIONS
Wireless Network
Telecom/Datacom
Industry Control System
Measurement Equipment
Semiconductor Equipment
FEATURES
•
3 WATTS MAXIMUM OUTPUT POWER
•
OUTPUT CURRENT UP TO 700mA
•
SIP PACKAGE, 0.86 x 0.36x 0.44 INCH
•
HIGH EFFICIENCY UP TO 85%
•
2:1 WIDE INPUT VOLTAGE RANGE
•
SWITCHING FREQUENCY (100KHz, MIN)
•
NO EXTERNAL INPUT AND OUTPUT CAPACITOR NEEDED
•
LOW RIPPLE & NOISE
•
UL94-V0 CASE POTTING MATERIALS
•
INPUT TO OUTPUT ISOLATION: 1600VDC
•
CONTINUOUS SHORT CIRCUIT PROTECTION
•
EXTERNAL ON/OFF CONTROL
•
CE MARK MEETS 2006/95/EC, 93/68/EEC AND 2004/108/EC
•
UL60950-1, EN60950-1 AND IEC60950-1 LICENSED
•
ISO9001 CERTIFIED MANUFACTURING FACILITIES
•
COMPLIANT TO RoHS EU DIRECTIVE 2002/95/EC
OPTIONS
3000VDC ISOLATION
DESCRIPTION
The PDL03 series offer 3 watts of output power from a 0.86 x 0.36 x 0.44 inch package
without derating to 71ºC. The PDL03 series have 2:1 wide input voltage of 4.5~9, 9~18,
18~36 and 36~75VDC and features 1600VDC of isolation, short-circuit protection.
T E C H N I C A L S P E C I F I C AT I O N
OUTPUT SPECIFICATIONS
Output power
Voltage accuracy
Minimum load
Line regulation
Load regulation
Dual
Cross regulation
(Dual)
Ripple and noise
LL to HL at Full Load
Single
No load to Full load
5% load to 100% load
No Load to Full Load
All specifications are typical at nominal input, full load and 25ºC otherwise noted
INPUT SPECIFICATIONS
3 Watts, max.
± 1%
0%
± 0.2%
Input voltage range
Input filter
5VDC input
12VDC input
24VDC input
48VDC input
5VDC input
Input reflected ripple
12VDC input
current
24VDC input
48VDC input
Nominal input and
Start up time
constant resistive load
DC-DC ON
Remote ON/OFF
DC-DC OFF
Remote off state input current
Application circuit
5VDC nominal input
12VDC nominal input
24VDC nominal input
48VDC nominal input
4.5 ~ 9VDC
9 ~ 18VDC
18 ~ 36VDC
36 ~ 75VDC
Capacitor type
15VDC 100mS, max.
36VDC 100mS, max.
50VDC 100mS, max.
100VDC 100mS, max.
400mAp-p, max.
150mAp-p, max.
380mAp-p, max.
170mAp-p, max.
Power up
30mS
Remote ON/OFF
30mS
Open or high impedance
Control pin applied current
2 ~ 4mA max(via 1KΩ)
2.5mA, max.
± 1% Input surge voltage
± 0.5%
± 1%
±5%
See table
±0.02%
/ ºC, max.
Asymmetrical load 25%/100% FL
20MHz bandwidth
Temperature coefficient
Transient response recovery time
Short circuit protection
25% load step change
500μS
Continuous, automatics recovery
See table
Standard
Suffix ”H”
Standard
Suffix ”H”
Full load to minimum load
1600VDC, min. 1minute
3000VDC, min. 1minute
10 ohms, min.
200pF, max.
40pF, max.
100KHz, min.
9
GENERAL SPECIFICATIONS
Efficiency
Isolation voltage
Isolation resistance
Isolation capacitance
Switching frequency
Approvals and standard
Case material
Base material
Potting material
Dimensions
Weight
MTBF(Note 1)
BELLCORE TR-NWT-000332
MIL-HDBK-217F
Nominal input
IEC60950-1, UL60950-1, EN60950-1
Non-conductive black plastic
None
Silicon (UL94-V0)
ENVIRONMENTAL SPECIFICATIONS
Operating ambient temperature
Storage temperature range
-40ºC ~ +71ºC (without derating)
+71ºC ~ +100ºC (with derating)
-55ºC ~ +105ºC
MIL-STD-810F
MIL-STD-810F
5% to 95% RH
Class A
Air
Contact
±
8KV
±
6KV
10 V/m
±
2KV
±
1KV
10 Vr.m.s
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Perf. Criteria A
Thermal shock
0.86 X 0.36 X 0.44 Inch
(21.8 X 9.1 X 11.2 mm) Vibration
4.8g (0.17oz) Relative humidity
6
4.386 x 10 hrs
EMC CHARACTERISTICS
6
2.401 x 10 hrs
EMI (Note 6)
EN55022
ESD
Radiated immunity
Fast transient (Note 7)
Surge (Note 7)
Conducted immunity
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
Page 1 of 3
Issued Date：2011/08/09
