Pin strip |
Spacing 3.81 mm
STLZ1570/..F-3.81-H-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
-
-
-
-
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
1.2 mm
Brass
Copper Alloy
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PBT
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
18.01
21.82
25.63
29.44
33.25
37.06
40.87
44.68
48.49
52.30
56.11
59.92
63.73
67.54
71.35
75.16
78.97
82.78
86.59
Article Designation
STLZ1570/2F-3.81-H-GREEN
STLZ1570/3F-3.81-H-GREEN
STLZ1570/4F-3.81-H-GREEN
STLZ1570/5F-3.81-H-GREEN
STLZ1570/6F-3.81-H-GREEN
STLZ1570/7F-3.81-H-GREEN
STLZ1570/8F-3.81-H-GREEN
STLZ1570/9F-3.81-H-GREEN
STLZ1570/10F-3.81-H-GREEN
STLZ1570/11F-3.81-H-GREEN
STLZ1570/12F-3.81-H-GREEN
STLZ1570/13F-3.81-H-GREEN
STLZ1570/14F-3.81-H-GREEN
STLZ1570/15F-3.81-H-GREEN
STLZ1570/16F-3.81-H-GREEN
STLZ1570/17F-3.81-H-GREEN
STLZ1570/18F-3.81-H-GREEN
STLZ1570/19F-3.81-H-GREEN
STLZ1570/20F-3.81-H-GREEN
Article Number
51570026021D
51570036021D
51570046021D
51570056021D
51570066021D
51570076021D
51570086021D
51570096021D
51570106021D
51570116021D
51570126021D
51570136021D
51570146021D
51570156021D
51570166021D
51570176021D
51570186021D
51570196021D
51570206021D
PU
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule -
min
Stranded with Ferrule -
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Flansch
Gewindeeinsatz
Contact Pin
Colours
GREEN
LIGHT GREEN
RAL6018
similar RAL 6018
RAL6018
similar RAL 6018
Accessories
Figure
Designation
Coding star CS1-3.5/3.81-RED
Article Number
50000000023
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Counterparts (Spacing 3.81 mm)
Pin Strip/Terminal Blocks
AKZ1550
AKZ4551
AKZ1710
AKZ1700
Ratings
Usegroup
Rated Voltage
Rated Current
Overvoltage Category
Test Voltage
Pollution Degree
B
300 V
8A
1.6 kV
C
-
-
-
D
300 V
8A
1.6 kV
160 V
9A
III
2.5 kV
3
