DD285N8K datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> DD285N8K

DD285N8K: DescriptionRectifier Diode, 1 Phase, 2 Element, 285A, 800V V(RRM), Silicon,; CategoryDiscrete semiconductor diode; File Size243KB，10 Pages; ManufacturerEUPEC [eupec GmbH]

Download Datasheet Parametric Compare View All

DD285N8K Overview

Rectifier Diode, 1 Phase, 2 Element, 285A, 800V V(RRM), Silicon,

DD285N8K Parametric

Parameter Name	Attribute value
Maker	EUPEC [eupec GmbH]
Reach Compliance Code	unknow
application	GENERAL PURPOSE
Shell connection	ISOLATED
Configuration	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	R-XUFM-X3
Maximum non-repetitive peak forward current	8300 A
Number of components	2
Phase	1
Number of terminals	3
Maximum operating temperature	150 °C
Maximum output current	285 A
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	800 V
surface mount	NO
Terminal form	UNSPECIFIED
Terminal location	UPPER

Preview

Download Datasheet

View All

Netz-Dioden-Modul

Rectifier Diode Module

Datenblatt / Data sheet

DD285N

Elektrische Eigenschaften / Electrical properties

Kenndaten

Höchstzulässige Werte / Maximum rated values

Periodische Spitzensperrspannung

repetitive peak reverse voltages

Stoßspitzensperrspannung

non-repetitive peak reverse voltage

Durchlaßstrom-Grenzeffektivwert

maximum RMS on-state current

Dauergrenzstrom

average on-state current

Stoßstrom-Grenzwert

surge current

Grenzlastintegral

I²t-value

Charakteristische Werte / Characteristic values

Durchlaßspannung

on-state voltage

Schleusenspannung

threshold voltage

Ersatzwiderstand

slope resistance

Sperrstrom

reverse current

Isolations-Prüfspannung

insulation test voltage

Elektrische Eigenschaften

Thermische Eigenschaften

= -40°C... T

vj max

RRM

RSM

FRMSM

400

600 V

800 V

700 V

900 V

450 A

285 A

9.500 A

8.300 A

451.000 A²s

344.000 A²s

= +25°C... T

vj max

500

= 100°C

= 25 °C, t

= 10 ms

= T

vj max

, t

= 10 ms

= 25 °C, t

= 10 ms

= T

vj max

, t

= 10 ms

FAVM

FSM

I²t

= T

vj max

, i

= 800 A

= T

vj max

= T

vj max

= T

vj max

, v

= V

RRM

RMS, f = 50 Hz, t = 1 sec

RMS, f = 50 Hz, t = 1 min

(TO)

ISOL

max.

1,15 V

0,75 V

0,4 mΩ

max.

20 mA

3,6 kV

3,0 kV

Thermische Eigenschaften / Thermal properties

Innerer Wärmewiderstand

thermal resistance, junction to case

pro Modul / per Module,

= 180° sin R

thJC

pro Zweig / per arm,

= 180° sin

pro Modul / per Module, DC

pro Zweig / per arm, DC

pro Modul / per Module

pro Zweig / per arm

thCH

vj max

c op

stg

max.

0,085

0,170

0,082

0,164

°C/W

Übergangs-Wärmewiderstand

thermal resistance, case to heatsink

Höchstzulässige Sperrschichttemperatur

maximum junction temperature

Betriebstemperatur

operating temperature

Lagertemperatur

storage temperature

prepared by: C. Drilling

approved by: M. Leifeld

date of publication:

revision:

0,02 °C/W

0,04 °C/W

150 °C

- 40...+150 °C

30.04.03

MA2-BE / 87-08-20, K.Spec

A20/87

Seite/page

1/9
