Tantalum Through-Hole Capacitors – Hermetically Sealed
T262 Series Axial MIL–PRF–39003 (CSR21 Style)
Overview
KEMET’s T262 Series (CSR21 Style) hermetically sealed
solid tantalum capacitors are qualified to MIL–C–39003/09.
This series is similar to KEMET's popular T212 (CSR13 per
MIL–PRF–39003/01) capacitors, but offer higher ripple
current handling capability and exhibit exceptionally low
equivalent series resistance (ESR). The T262 Series is ideal
for filtering applications and in military power supplies
where low ESR is essential. These capacitors are 100% surge
current tested and their dissipation factor is screened at 1
kHz.
Benefits
• Taped and reeled per EIA Specification RS–296
• Marking per MIL–STD–1285
• Qualified to MIL–PRF–39003 (CSR21 Style)
• Failure rate options: Graded – B, C, D, and G
Exponential - M, P, R, and S*
• Capacitance values of 5.6 μF to 330 μF
• Tolerances of ±5%, ±10%, and ±20%
• Voltage rating of 6 – 50 VDC
• Operating temperature range of −55˚C to +125˚C
• 100% surge current test available on all case sizes
• Dissipation factor is screened at 1 kHz
• Case sizes: C, D
*Failure rates apply to military products only
Click image above for interactive 3D content
Open PDF in Adobe Reader for full functionality
Applications
The T262 Series is ideal for filtering applications and in defense power supplies where low ESR is essential.
One world. One KEMET
© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
T2036_T262_AXIAL • 10/19/2018
1
Tantalum Through-Hole Capacitors – Hermetically Sealed
T262 Series Axial MIL–PRF–39003 (CSR21 Style)
Ordering Information
T
Capacitor
Class
T=
Tantalum
262
Series
Hermetically
sealed axial
capacitor
C
Case
Size
C
D
106
Capacitance
Code (pF)
First two digits
represent
significant
figures. Third digit
specifies number
of zeros.
K
J = ±5%
K = ±10%
M = ±20%
050
006 = 6
010 = 10
015 = 15
020 = 20
035 = 35
050 = 50
C
Failure Rate
S
Termination
Finish
Specification
Blank = Sleeved/Bulk
0100 = Without sleeve
7200 = Tape & Reel
7293 & 7443 = Ammo
4251 = 10 cycles, −55 &
85°C after Weibull
4252 = 10 cycles, −55 &
85°C before Weibull
All capacitors are sleeved
unless specified.
Capacitance
Rated Voltage
Tolerance
(VDC)
Graded:
S = Standard
B = 0.1%/k hours
(Solder-
C = 0.01%/k hours
coated
D = 0.001%/k hours
nickel)
Exponential:
M = 1%/k hours
P = 0.1%/k hours
R = 0.01%/k hours
S = 0.001%/k hours
Ordering Information – T262 (CSR21 Style)
MIL product
M39003
Capacitor Class
Military
specification
number
/09
Slash
Specification
sheet number
3074
Dash Number
Failure rate
level
B
Surge Option
B = C-4251
C = C-4252
Orders should be entered by the military specification number, including the dash number and surge option letter (B or C).
Performance Characteristics
Item
Operating Temperature
Rated Capacitance Range
Capacitance Tolerance
Rated Voltage Range
DF (120 Hz at 25°C)
ESR and Impedance (100 kHz at 25°C)
Leakage Current
Failure Rate (MIL–39003, CSR13 capacitors
only)
−55°C to 125°C
5.6 – 330 μF at 120 Hz/25°C
J Tolerance (5%), K Tolerance (10%), M Tolerance (20%)
6 – 50 V
Refer to Part Number Electrical Specification Table
Refer to Part Number Electrical Specification Table
Refer to Part Number Electrical Specification Table (at rated voltage up to +85°C and 2/3 of
rated voltage applied at 125°C)
Approved failure rate: S (0.001%/k hours) - Exponential, D (0.001%/k hours) – Graded
