Metre - Handset - Sine - CORNING - Year - Cable type +
Fibre count + Fibre type
Temperature Range
Installation and Assembly
Operation
Storage
-5 °C to 50 °C
-30 °C to 70 °C
-40 °C to 70 °C
Family Spec Sheet 0070_EMEA_BEN
Page 2 | Revision date 2014-07-18
Outdoor stranded loose-tube cables
(minibundle), corrugated steel armouring
A-DQ(ZN)(SR)2Y 12-144, 2.25 mm tubes
Mechanical Characteristics Cable
Fibre Count
Fibres per
Tube
6
12
12
12
12
12
12
Weight
Nominal
Outer Dia-
meter
11.6 mm
11.6 mm
13 mm
14.5 mm
16 mm
16.2 mm
18.3 mm
Min. Bend
Min. Bend
Radius Instal- Radius Ope-
lation
ration
230 mm
230 mm
260 mm
290 mm
320 mm
355 mm
405 mm
175 mm
175 mm
195 mm
215 mm
240 mm
240 mm
275 mm
Max. Tensile
Strength for
Installation
2700 N
2700 N
2700 N
2700 N
2700 N
2700 N
2700 N
Crush Resistance
(reversible)
3000 N/10cm
3000 N/10cm
3000 N/10cm
3000 N/10cm
3000 N/10cm
3000 N/10cm
3000 N/10cm
12 - 24
24 - 72
96
120
144
192 - 216
288
127 kg/km
127 kg/km
156 kg/km
193 kg/km
232 kg/km
230 kg/km
295 kg/km
* Fibre count per tube, colour coding of fibres and/or buffer tubes, hybrid construction, jacket colour and/or printings deviating from standard design have no influ-
ence whatsoever on mechanical and optical characteristics.
Chemical characteristics
RoHS
Free of hazardous substances according to RoHS 2002/95/
EG
Transmission Performance
Multimode
Fibre Name
Fibre Core Diameter
(
µm
)
Fibre Category
Fibre Code
Wavelengths
(
nm
)
Maximum Attenuation
(
dB/km
)
Typical attenuation
(
dB/km
)
Serial 1 Gigabit Ethernet
(
m
)
Serial 10 Gigabit Ethernet
(
m
)
Min. Overfilled Launch (OFL)
Bandwidth
(
MHz*km
)
Minimum Effective Modal
Bandwidth (EMB)
(
MHz*km
)
Induced attenuation @ 7.5 mm
radius
(
dB
)
Cable cutoff wavelength
(
nm
)
G62.5L/125
InfiniCor
®
300
62.5
OM1
A
850/1300
3.1/0.8
2.9/0.7
300/550
33/-
200/600
220/-
-
-
G50/125 ULTRA-
BEND 7.5
50
OM2
G
850/1300
2.8/1.0
2.4/0.8
750/600
150/-
700/500
950/-
<0.2/-
-
G50/125 ULTRA-
BEND 7.5
50
OM3
H
850/1300
2.8/1.0
2.4/0.8
1000/600
300/333
1500/500
2000/-
<0.2/-
-
G50/125 ULTRA-
BEND 7.5
50
OM4
K
850/1300
2.8/1.0
2.4/0.8
1100/600
550/-
3500/500
4700/-
<0.2/-
-
E9/125 SMF28e+
8.2
OS2
U
1310/1383/1550
0.36/0.36/0.22
-
5000/-/-
10000/-/40000
-
-
-
1260
Family Spec Sheet 0070_EMEA_BEN
Page 3 | Revision date 2014-07-18
Outdoor stranded loose-tube cables
(minibundle), corrugated steel armouring
A-DQ(ZN)(SR)2Y 12-144, 2.25 mm tubes
Ordering Information |
Note: Contact Customer Service at 00800 2676 4641 for other options.
*Maximum delivery length per drum is 4000 metres +3/-2% for Multimode fibres and 6000 metres +3/-2% for Single-mode fibres.
*Please notice that in the hybrid cables construction (different fibre types) the Multimode fibres are in sequence from the higher to the lower performance fol-
lowed by the Single-mode fibres.
*For ordering information regarding non-standard design cables, please contact our Customer Service Centre. (See bottom of page for contact information.)
