Product Brief
MegaRAID
®
SAS 9361-4i
High Performance 12Gb/s PCI Express SATA+SAS RAID Controller
Unmatched RAID Performance for Next-Generation Servers and Storage
Key Features
■■
The explosive growth of data in cloud and enterprise datacenters is driving the need for a higher
performance storage interface to speed the ability of critical applications to access data. Avago
first-to-market 12Gb/s SAS solutions are designed to deliver the performance and data protection
capabilities required for the most demanding next-generation server and storage platforms.
Offering up to double the data transfer rate of 6Gb/s SAS solutions, 12Gb/s SAS allows the SAS
infrastructure to deliver bandwidth that can fully utilize that of PCI Express
®
3.0 with a single
controller card. The MegaRAID SAS 9361-4i, with four internal ports, delivers two 1.2GHz PowerPC
®
processor cores and a 72-bit DDRIII interface that drives 1GB cache memory. Powered by the
LSI SAS 3108 dual-core ROC, the 9361-4i controller includes the latest PCI Express 3.0 and 12Gb/s
SAS technology and helps users to support increased scaling of hard disk drives (HDDs) and
maximize the performance benefits of solid state drives (SSDs).
High performance 12Gb/s data
transfer rates
Four internal 12Gb/s SATA+SAS ports
One mini-SAS SFF8643 internal
connector (horizontal mount)
LSI SAS 3108: 1.2GHz PowerPC
®
476
dual core 12Gb/s ROC
PCI Express 3.0 host interface
1GB DDRIII cache memory
RAID levels 0, 1, 5, 6, 10, 50, and 60
Support for CacheVault
®
flash cache
protection
■■
■■
■■
■■
■■
■■
■■
Key Advantages
■■
Enterprise Data Protection
Standard support for the most popular RAID levels and accessories, including RAID 5, RAID 6, and
CacheVault
®
Flash cache protection module, further strengthen the data protection capabilities
of the MegaRAID SAS 9361-4i. A new enterprise feature employed by the 12Gb/s MegaRAID SAS
controllers is advanced drive diagnostic technology. In the event of a physical drive failure, the drive
is placed in a shielded state and the MegaRAID controller starts drive diagnostics to determine if the
drive is indeed failed or can be restored. This saves customers time, money and lost compute time
associated with transient drive failures and unnecessary drive returns.
12Gb/s solutions accelerate
performance for next-generation
datacenters, web and cloud
Delivers enterprise-class data
protection and security
Preserves investment in 6Gb/s and
3Gb/s drives
Support for Advanced Software
options
Connect up to 128 3Gb/s, 6Gb/s, or
12Gb/s SATA and SAS devices
■■
■■
■■
■■
Support for Advanced Software Options
The family of 12Gb/s MegaRAID controllers are designed to support Avago advanced software
options that provide system integrators and VARs with enhanced performance and data protection
capabilities. These software options help enable end users to address key business challenges while
helping to deliver a higher return on their IT investments. MegaRAID CacheCade
™
Pro 2.0 software
(optional) and MegaRAID Fast Path software (included) boost transactional I/O performance of solid
state disk configurations, while SafeStore
™
software enables enhanced data protection and security
when used with encryption capable devices.
Product Brief
MegaRAID SAS 9361-4i
Solution Provided
Physical Dimensions
Connectors
Device Support
Host Bus Type
Data Transfer Rates
I/O Processor / SAS Controller
Cache Memory
Cache Protection
Key RAID Data Protection
Features
Four-port internal 12Gb dual core ROC-based SAS solution for data center, cloud, and performance-hungry applications
using up to 128 SAS or SATA devices
MD2 low profile (6.6” X 2.536”)
One mini-SAS SFF8643 internal connector (horizontal mount)
Up to 128 SAS and/or SATA devices
x8 lane PCI Express 3.0 compliant
Up to 12Gb/s per port
LSI SAS 3108 dual core RAID on Chip (ROC)
1GB 1866MHz DDRIII SDRAM
Optional CacheVault Flash Module (LSICVM02) – Includes CVFM04, CVPM02, mounting clip, and cable
• RAID levels 0, 1, 5, and 6
• RAID spans 10, 50, and 60
• Online Capacity Expansion (OCE)
• Online RAID Level Migration (RLM)
• Auto resume after loss of system power during array
rebuild or reconstruction (RLM)
• Single controller Multipathing
• Load Balancing
• Configurable stripe size up to 1MB
• Fast initialization for quick array setup
• Check Consistency for background data integrity
• SSD Support with SSD Guard
™
technology
• Patrol read for media scanning and repairing
+3.3V, +12V
1,343,187 hours
3 years, free 5x8 phone support, advanced replacement option
EN55022, EN55024, EN60950, EN 61000-3-2, EN 61000-3-3; FCC Class A, Class B; UL1950; UL; CSA C22.2; VCCI; RRL for MIC;
BSMI; C-tick
• MegaRAID Storage Manager
• StorCLI (command-line interface)
• CTRL-R (BIOS configuration utility)
• HII (UEFI Human Interface Infrastructure)
• 64 logical drive support
• DDF compliant Configuration on Disk (COD)
• S.M.A.R.T support
• Global and dedicated Hot Spare with Revertible Hot Spare
support
– Automatic rebuild
– Enclosure affinity
– Emergency SATA hot spare for SAS arrays
• Enclosure management – SES (inband)
– SGPIO (sideband)
• Databolt
™
bandwidth optimizer technology support for
compatible expander-based enclosures
• Shielded state drive diagnostic technology
Operating Temperature
Operating Voltage
MTBF (Calculated)
Hardware Warranty
Regulatory Certifications
MegaRAID Management Suite
SSD Optimization
Maximum ambient: Controller Card: 55°C, with optional CacheVault accessory (LSICVM02): 55°C
• MegaRAID CacheCade Pro 2.0 Software leverages SSDs in front of HDD volumes to create high-capacity, high-
performance controller cache pools (Optional Upgrade)
• MegaRAID Fast Path Software provides high-performance I/O acceleration for SSD arrays connected to 6Gb/s MegaRAID
SATA+SAS controllers (Included)
EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-3/02.04); Europe (EN55022/EN55024); Australia/New Zealand
(AS/NZS 3548); Safety: EN60950
Extensive support includes Microsoft
®
Windows
®
Server 2012/8 & 7/2008/Vista/2003, Linux
®
, Solaris
™
(x86), FreeBSD
®
,
VMware
®
and more.
Visit the download center for the most complete list of supported operating systems: www.lsi.com/support
Compliances
OS Support
Ordering Information
MegaRAID SAS 9361-4i
Single Pack: LSI00415
Kit: LSI00414
LSICVM02 CacheVault Kit
Kit: LSI00418
Visit the Avago Storage by LSI website at:
lsi.com
Avago, Avago Technologies, MegaRAID, and the Storage by LSI logo are trademarks of Avago Technologies. All other trademarks are the
property of their respective owners.
Copyright ©2014 Avago Technologies. All rights reserved. > 10.07.14 PB0082.02
