This document was generated on 09/05/2013
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
76020-3106
Active
GbX I-Trac™ Backplane Connector System
GbX I-Trac™ Right Angle Receptacle Module, 1.85mm by 3.70mm Pitch, Left Guide 7
Row, 6 Columns, 84 Circuits, Polarization Key A, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-75710-999 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
E29179
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
China RoHS
Agency Certification
UL
General
Product Family
Series
Application
Component Type
Overview
Product Name
Style
UPC
Backplane Connectors
76020
Coplanar, Daughtercard
PCB Receptacle
GbX I-Trac™ Backplane Connector System
GbX I-Trac™
N/A
883906173623
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
84
84
Black
200
No
94V-0
Yes
Yes
High Performance Alloy (HPA)
Gold
Tin
High Temperature Thermoplastic
12.811/g
6
4, Open Pin Field
7
Right Angle
2.00mm
Yes
Yes
1.60mm
Tray
1.85mm, 3.70mm
1.00mm, 2.70mm
0.762µm
0.762µm
Yes
No
Yes
-55°C to +80°C
Through Hole - Compliant Pin
Search Parts in this Series
76020Series
Mates With
76015 GbX I-Trac™ Vertical Header
Module. 76011 GbX I-Trac™ Right Angle
Header Module
Use With
78234 GbX I-Trac™ Right Angle Power
Header. 76153 Pirate Cannon Wide Guide
Module
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Press-In Tool
0622018611
for Right Angle
Receptacle and
