ILD223T
Vishay Semiconductors
Optocoupler, Photodarlington Output, Dual Channel,
SOIC-8 Package
FEATURES
• Two channel optocoupler
• High current transfer ratio at I
F
= 1.0 mA,
500 % minimum
A 1
C 2
A 3
C 4
8
C
7E
6C
5E
• Isolation test voltage, 4000 V
RMS
• Electrical specifications similar to standard 6-pin
coupler
• Compatible with dual wave, vapor phase and IR reflow
soldering
• SOIC-8 surface mountable package
• Standard lead spacing, 0.05"
• Available only on tape and reel (conforms to EIA
standard 481-2)
i179042
DESCRIPTION
The ILD233T is a high current transfer ratio (CTR)
optocoupler. It has a gallium arsenide infrared LED emitter
and silicon NPN photodarlington transistor detector.
This device has CTRs tested at an LED current of 1.0 mA.
This low drive current permits easy interfacing from CMOS to
LSTTL or TTL.
The ILD223T is constructed in a standard SOIC-8 foot print
which makes it ideally suited for high density applications. In
addition to eliminating through hole requirements, this
package conforms to standards for surface mounted
devices.
• Lead (Pb)-free component
• Component in accordance to RoHS 2002/95/EC and
WEEE 2002/96/EC
AGENCY APPROVALS
• UL1577, file no. E52744 system code Y
• CUL - file no. E52744, equivalent to CSA bulletin 5A
• DIN EN 60747-5-2 (VDE 0884) available with option 1
ORDER INFORMATION
PART
ILD223T
REMARKS
CTR > 500 %, SOIC-8
(1)
ABSOLUTE MAXIMUM RATINGS
PARAMETER
INPUT
Peak reverse voltage
Peak pulsed current
Continuous forward current per channel
Power dissipation
Derate linearly from 25 °C
OUTPUT
Collector emitter breakdown voltage
Emitter collector breakdown voltage
Power dissipation per channel
Derate linearly from 25 °C
TEST CONDITION
SYMBOL
V
R
VALUE
6.0
3.0
30
45
0.4
30
5.0
75
3.1
UNIT
V
A
mA
mW
mW/°C
V
V
mW
mW/°C
1.0 µs, 300 pps
P
diss
BV
CEO
BV
ECO
P
diss
Document Number: 83648
Rev. 1.6, 20-Apr-07
For technical questions, contact: optocoupler.answers@vishay.com
www.vishay.com
1
ILD223T
Vishay Semiconductors
Optocoupler, Photodarlington Output,
Dual Channel,
SOIC-8 Package
(1)
ABSOLUTE MAXIMUM RATINGS
PARAMETER
COUPLER
Isolation test voltage
Total package dissipation
(2 LEDs and 2 detectors, 2 channels)
Derate linearly from 25 °C
Storage temperature
Operating temperature
Soldering
temperature
(2)
TEST CONDITION
t = 1.0 s
SYMBOL
V
ISO
P
tot
VALUE
4000
250
2.0
- 55 to + 150
- 55 to + 100
260
UNIT
V
RMS
mW
mW/°C
°C
°C
°C
T
stg
T
amb
T
sld
Notes
(1)
T
amb
= 25 °C, unless otherwise specified
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. Functional operation of the device is not
implied at these or any other conditions in excess of those given in the operational sections of this document. Exposure to absolute maximum
ratings for extended periods of the time can adversely affect reliability.
(2)
Refer to reflow profile for soldering conditions for surface mounted devices (SOP/SOIC).
ELECTRICAL CHARACTERISTICS
PARAMETER
INPUT
Forward voltage
Reverse current
Capacitance
OUTPUT
Collector emitter breakdown voltage
Emitter collector breakdown voltage
Collector emitter leakage current
Collector emitter capacitance
COUPLER
Capacitance (input to output)
Saturation voltage, collector emitter
Resistance, input to output
I
F
= 1.0 mA, I
CE
= 0.5 mA
ILD223T
ILD223T
ILD223T
C
IO
V
CEsat
C
IO
100
0.5
1.0
pF
V
GΩ
I
C
= 10 µA
I
C
= 10 µA
V
CE
= 50 V, I
F
= 0 A
V
CE
= 5.0 V
BV
CEO
BV
CEO
I
CEO
C
CE
3.4
30
5.0
50
V
V
nA
pF
I
F
= 10 mA
V
R
= 6.0 V
V
F
= 0 V, f = 1.0 MHz
V
F
I
R
C
O
0.1
25
1.3
100
V
µA
pF
TEST CONDITION
PART
SYMBOL
MIN.
TYP.
MAX.
UNIT
Note
T
amb
= 25 °C, unless otherwise specified
Minimum and maximum values are testing requirements. Typical values are characteristics of the device and are the result of engineering
evaluation. Typical values are for information only and are not part of the testing requirements.
CURRENT TRANSFER RATIO
PARAMETER
DC current transfer ratio
TEST CONDITION
I
F
= 1.0 mA, V
CE
= 5.0 V
SYMBOL
CTR
DC
MIN.
500
TYP.
MAX.
UNIT
%
SWITCHING CHARACTERISTICS
PARAMETER
Turn-on time
Turn-off time
TEST CONDITION
V
CC
= 10 V, R
L
= 100
Ω,
I
F
= 5.0 mA
V
CC
= 10 V, R
L
= 100
Ω,
I
F
= 5.0 mA
PART
ILD223T
ILD223T
SYMBOL
t
on
t
off
MIN.
15
30
TYP.
MAX.
UNIT
µs
µs
www.vishay.com
2
For technical questions, contact: optocoupler.answers@vishay.com
Document Number: 83648
Rev. 1.6, 20-Apr-07
ILD223T
Optocoupler, Photodarlington Output,
Dual Channel,
SOIC-8 Package
SAFETY AND INSULATION RATINGS
PARAMETER
Climatic classification (according to IEC 68 part 1)
Comparative tracking index
V
IOTM
V
IORM
P
SO
I
SI
T
SI
Creepage distance
Clearance distance
Insulation thickness, reinforced rated
per IEC 60950 2.10.5.1
4
4
0.2
CTI
175
6000
560
350
150
165
TEST CONDITION
SYMBOL
MIN.
TYP.
55/100/21
399
V
V
mW
mA
°C
mm
mm
mm
MAX.
UNIT
Vishay Semiconductors
Note
As per IEC 60747-5-2, §7.4.3.8.1, this optocoupler is suitable for “safe electrical insulation” only within the safety ratings. Compliance with the
safety ratings shall be ensured by means of prodective circuits.
TYPICAL CHARACTERISTICS
T
amb
= 25 °C, unless otherwise specified
100
T
amb
20 °C
Ta = - = - 20 °C
Ta = 25 25 °C
T
amb
= °C
T
amb
= °C
Ta = 50 50 °C
Ta = 70 70 °C
T
amb
= °C
1.4
V
F - Forward
Voltage
(V)
1.3
1.2
1.1
1.0
0.9
0.8
0.7
.1
TA = - 55 °C
Normalized
CTR
ce
CT
10
TA = 25 °C
1
TA = 100 °C
Normalized
to:
I
F
= 1 mA,
V
CE
= 5
V
If = 1 mA,
V
CE
= 5
V
T
amb
25 25 °C
Ta = = °C
1
10
I F - Forward Current (mA)
100
0.1
0.1
iild223t_03
1
10
100
iild223t_01
I
F
- LED Current (mA)
Fig. 3 - Forward Voltage vs. Forward Current
Fig. 5 - Normalized CTR
CE
vs. LED Current
2000
10000
If(pk) - Peak LED Current (mA)
Duty Factor
1000
CTR
ce
- Current Transfer Ratio (%)
τ
100
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1500
t
DF =
τ
/t
T
amb
= - 20 °C
T
amb
= 25 °C
T
amb
= 50 °C
T
amb
= 70 °C
V
CE
= 5 V
1000
500
10
10-6
10-5
10-4 10 -3 10 -2 10-1 10 0
t - LED Pulse Duration (s)
101
0
0.1
1
10
100
iild223t_02
iild223t_04
I
F
- LED Current (mA)
Fig. 4 - Peak LED Current vs. Duty Factor,
τ
Fig. 6 - CTR vs. LED Current
Document Number: 83648
Rev. 1.6, 20-Apr-07
For technical questions, contact: optocoupler.answers@vishay.com
www.vishay.com
3
ILD223T
Vishay Semiconductors
Optocoupler, Photodarlington Output,
Dual Channel,
SOIC-8 Package
100
I
ce
- Collector Current (mA)
10
T
amb
= - 20 °C
T
amb
= 25°C
T
amb
= 50°C
T
amb
= 70 °C
V
CE
= 5 V
I
F
V
O
1
t
D
t
R
t
PLH
V
TH
=1.5
V
0.1
t
PHL
0.1
1
10
100
iild223t_07
t
S
t
F
iild223t_05
I
F
- LED Current (mA)
Fig. 7 - Collector Current vs. LED Current
Fig. 9 - Switching Timing
V
CC
= 10
V
F = 10 kHz,
DF = 50
%
R
L
V
O
I
F
= 5 mA
iild223t_06
Fig. 8 - Switching Schematic
PACKAGE DIMENSIONS
in inches (millimeters)
0.120 ± 0.002
(3.05 ± 0.05)
0.050 (1.27)
0.240
(6.10)
C 0.154 ± 0.002
L
(3.91 ± 0.05)
0.170 (4.32)
0.260 (6.6)
Pin One I.D.
0.230 ± 0.002
ISO Method A
0.004 (0.10)
0.008 (0.20)
(5.84 ± 0.05)
0.016 (0.41)
7°
0.015 ± 0.002
(0.38 ± 0.05)
40 °
0.0585 ± 0.002
(1.49 ± 0.05)
0.014 (0.36)
0.036 (0.91)
0.045 (1.14)
R 0.010 (0.13)
0.008 (0.20)
5° Max.
R0.010
(0.25) max.
0.125 ± 0.002
(3.18 ± 0.05)
0.050 (1.27) typ.
0.040 (1.02)
i178020
0.020 ± 0.004
(0.51 ± 0.10)
2 plcs.
Lead coplanarity
± 0.001 max.
www.vishay.com
4
For technical questions, contact: optocoupler.answers@vishay.com
Document Number: 83648
Rev. 1.6, 20-Apr-07
ILD223T
Optocoupler, Photodarlington Output,
Dual Channel,
SOIC-8 Package
OZONE DEPLETING SUBSTANCES POLICY STATEMENT
It is the policy of Vishay Semiconductor GmbH to
1. Meet all present and future national and international statutory requirements.
2. Regularly and continuously improve the performance of our products, processes, distribution and operating systems with
respect to their impact on the health and safety of our employees and the public, as well as their impact on the environment.
It is particular concern to control or eliminate releases of those substances into the atmosphere which are known as ozone
depleting substances (ODSs).
The Montreal Protocol (1987) and its London Amendments (1990) intend to severely restrict the use of ODSs and forbid their use
within the next ten years. Various national and international initiatives are pressing for an earlier ban on these substances.
Vishay Semiconductor GmbH has been able to use its policy of continuous improvements to eliminate the use of ODSs listed in
the following documents.
1. Annex A, B and list of transitional substances of the Montreal Protocol and the London Amendments respectively.
2. Class I and II ozone depleting substances in the Clean Air Act Amendments of 1990 by the Environmental Protection Agency
(EPA) in the USA
3. Council Decision 88/540/EEC and 91/690/EEC Annex A, B and C (transitional substances) respectively.
Vishay Semiconductor GmbH can certify that our semiconductors are not manufactured with ozone depleting substances and do
not contain such substances.
Vishay Semiconductors
We reserve the right to make changes to improve technical design
and may do so without further notice.
Parameters can vary in different applications. All operating parameters must be validated for each customer application by the
customer. Should the buyer use Vishay Semiconductors products for any unintended or unauthorized application, the buyer shall
indemnify Vishay Semiconductors against all claims, costs, damages, and expenses, arising out of, directly or indirectly, any
claim of personal damage, injury or death associated with such unintended or unauthorized use.
Vishay Semiconductor GmbH, P.O.B. 3535, D-74025 Heilbronn, Germany
Document Number: 83648
Rev. 1.6, 20-Apr-07
For technical questions, contact: optocoupler.answers@vishay.com
www.vishay.com
5
