ILSB-0805
Vishay Dale
Monolithic Chip Inductors
FEATURES
•
•
•
•
High reliability
Surface mountable
Magnetically self shielded
Nickel barrier plating virtually eliminates silver
migration
•
100 % Lead (Pb)-free and RoHS compliant
RoHS
COMPLIANT
MECHANICAL SPECIFICATIONS
Solderability:
90 % coverage after 5 second dip in 235 °C
solder following 60 second preheat at 120 °C to 150 °C
and type R flux dip
Resistance To Solder Heat:
10 seconds in 260 °C solder
after preheat and flux per above
Termination:
90/10 Sn/Pb
Terminal Strength:
0.6 kg for 30 seconds
Beam Strength:
1.0 kg
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature:
- 55 °C to + 125 °C
Thermal Shock:
- 40 °C to + 85 °C
Humidity:
90 % RH at 40 °C, 1000 hours at full rated
current
Load Life:
85 °C for 1000 hours full rated current
STANDARD ELECTRICAL SPECIFICATIONS
INDUCTANCE
(µH)
± 10 %
TOLERANCE
± 20 %
0.047
± 20 %
0.056
± 20 %
0.068
± 20 %
0.082
± 10 %
0.10
± 10 %
0.12
± 10 %
0.15
± 10 %
0.18
± 10 %
0.22
± 10 %
0.27
± 10 %
0.33
± 10 %
0.39
± 10 %
0.47
± 10 %
0.56
± 10 %
0.68
± 10 %
0.82
± 10 %
1.0
± 10 %
1.2
± 10 %
1.5
1.8
± 10 %
2.2
± 10 %
2.7
± 10 %
3.3
± 10 %
3.9
± 10 %
4.7
± 10 %
5.6
± 10 %
6.8
± 10 %
8.2
± 10 %
10.0
± 10 %
12.0
± 10 %
15.0
± 10 %
18.0
± 10 %
22.0
± 10 %
27.0
± 10 %
33.0
± 10 %
MINIMUM
TEST FREQUENCY SELF- RESONANT
FREQUENCY
Q
MAXIMUM DCR
THICKNESS “D”
L&Q
(MHz)
(Min.)
(Ohms)
Inches [mm]
(MHz)
0.20
50
320
15
0.035 ± 0.008 [0.90 ± 0.2]
0.20
50
15
300
0.035 ± 0.008 [0.90 ± 0.2]
0.20
50
280
15
0.035 ± 0.008 [0.90 ± 0.2]
0.20
50
255
15
0.035 ± 0.008 [0.90 ± 0.2]
0.035 ± 0.008 [0.90 ± 0.2]
0.30
25
20
279
0.035 ± 0.008 [0.90 ± 0.2]
0.30
25
253
20
0.035 ± 0.008 [0.90 ± 0.2]
0.40
25
230
20
0.035 ± 0.008 [0.90 ± 0.2]
0.40
25
213
20
0.035 ± 0.008 [0.90 ± 0.2]
0.50
25
196
20
0.035 ± 0.008 [0.90 ± 0.2]
0.50
25
173
20
0.035 ± 0.008 [0.90 ± 0.2]
0.55
25
167
20
0.035 ± 0.008 [0.90 ± 0.2]
0.65
25
25
156
0.049 ± 0.008 [1.25 ± 0.2]
0.65
25
144
25
0.049 ± 0.008 [1.25 ± 0.2]
0.75
25
133
25
0.049 ± 0.008 [1.25 ± 0.2]
0.80
25
25
121
0.049 ± 0.008 [1.25 ± 0.2]
1.00
25
25
115
0.035 ± 0.008 [0.90 ± 0.2]
0.40
10
45
87
0.035 ± 0.008 [0.90 ± 0.2]
10
75
0.50
45
0.035 ± 0.008 [0.90 ± 0.2]
0.50
10
45
69
0.035 ± 0.008 [0.90 ± 0.2]
0.60
10
45
64
0.035 ± 0.008 [0.90 ± 0.2]
0.65
10
58
45
0.049 ± 0.008 [1.25 ± 0.2]
0.75
10
52
45
0.049 ± 0.008 [1.25 ± 0.2]
0.80
10
48
45
0.049 ± 0.008 [1.25 ± 0.2]
10
0.90
45
44
0.049 ± 0.008 [1.25 ± 0.2]
1.00
10
41
45
0.049 ± 0.008 [1.25 ± 0.2]
0.90
4
37
45
0.049 ± 0.008 [1.25 ± 0.2]
1.00
4
45
34
0.049 ± 0.008 [1.25 ± 0.2]
1.10
4
30
45
0.049 ± 0.008 [1.25 ± 0.2]
1.15
2
50
28
0.049 ± 0.008 [1.25 ± 0.2]
1.25
2
26
50
0.049 ± 0.008 [1.25 ± 0.2]
0.80
1
30
22
0.049 ± 0.008 [1.25 ± 0.2]
0.90
1
21
30
0.049 ± 0.008 [1.25 ± 0.2]
1.10
1
19
30
0.049 ± 0.008 [1.25 ± 0.2]
1.15
1
17
30
0.049 ± 0.008 [1.25 ± 0.2]
1.25
0.4
13
30
RATED
DC CURRENT
(mA)
300
300
300
300
250
250
250
250
250
250
250
200
200
150
150
150
50
50
50
50
30
30
30
30
30
15
15
15
15
15
5
5
5
5
5
µH
%
0
www.vishay.com
70
For technical questions, contact Magnetics@vishay.com
Document Number 34028
Revision 17-Jan-06
ILSB-0805
Monolithic Chip Inductors
DIMENSIONS
in inches [millimeters]
100 % Sn Termination
Vishay Dale
B
G
A
Ferrite Body
F
D
E
C
Dimensional Outline
H
Suggested Pad Layout
A
0.079 ± 0.008
[2.0 ± 0.2]
B
0.049 ± 0.008
[1.25 ± 0.2]
C
0.020 ± 0.12
[0.5 ± 0.3]
D
See Electrical
Specs
E
0.120
[3.0]
F
0.051
[1.3]
G
0.040
[1.0]
H
0.040
[1.0]
TAPE AND REEL SPECIFICATIONS 0805 SIZE PER EIA-481-1
in inches [millimeters]
P
2
P
0
Ø D
0
E
1
F
W
T
A
0
B
0
D
0
D
1
E
1
F
K
0
P
0
P
1
P
2
W
T
A
N
C
W
1
B
0
Ø D
1
A
0
T
1
ØC
ØN
P
1
K
0
ØA
W
1
Empty Tape
T
1
0.059 ± .004 [1.50 ± 0.1]
0.092 ± .004 [2.34 ± 0.1]
0.059 + .005/- 0.000
[1.5 + 0.127]
0.039 Min. [1.0 Min.]
0.069 ± .004 [1.75 ± 0.1]
0.138 ± .002 [3.50 ± 0.05]
0.049 ± .002 [1.24 ± 0.05]
0.157 ± .004 [4.00 ± 0.1]
0.157 ± .004 [4.00 ± 0.1]
0.079 ± .002 [2.00 ± 0.05]
0.327 Max. [8.3 Max.]
0.008 ± .002 [0.2 ± 0.05]
7.000 ± .078 [178 ± 2.0]
2.500 [63.5]
0.512 ± .020
[13.00 + 0.50]
0.315 + 0.059/- 0.00
[8.00 + 1.50]
0.079 ± .002 [2.00 ± 0.05]
Empty Trailer
Components
Cover Tape Leader
Unreel
Direction
160 mm Minimum
160 mm Minimum
390 mm Minimum
Document Number 34028
Revision 17-Jan-06
For technical questions, contact Magnetics@vishay.com
www.vishay.com
71
