ISM89-6358AH-156.250 Overview

3.2 mm x 5.0 mm Ceramic Package SMD Oscillator, LVDS

Preview

Download Datasheet

View All

3.2 mm x 5.0 mm Ceramic Package SMD Oscillator, LVDS

ISM89 Series

Product Features:

Surface Mount Package

Low Jitter

Reflow Compatible

Compatible with Leadfree Processing

Applications:

Test Equipment

Server & Storage

Sonet /SDH

Frequency

Output Level

Duty Cycle

Rise / Fall Time

Output Load

Frequency Stability

Enable Phase Delay

Disable Phase

Delay

Supply Voltage

Current

Operating

Storage

80 MHz to 250.000 MHz

V

OH

= 1.43 typ.

50% ±5%

0.7 nS Max.

100



(offset 1.25V typ.)

±25ppm

2 mS Max.

200 nS Max.

Recommended Pad Layout

V

OL

= 1.10 typ.

See Input Voltage Table, Tolerance ±5 %

55 mA Typical

-40

C to +85



C

-50



C to +125



C

Pin Connection

1

Enable

2

N.C.

3

V

SS

4

Output

5

Comp. Output

6

V

DD

Dimension Units: mm

Integrated Jitter

RMS

0.3 typ. (12 KHz to 20 MHz Band)

Part Number Guide

Package

Input

Voltage

3 = 3.3 V

6 = 2.5 V

ISM89 -

Sample Part Number:

Operating

Temperature

1 = 0 C to +70 C

6 = -10 C to +70 C

3 = -20 C to +70 C

2 = -40 C to +85 C

I

SM89 – 3258AH - 156.250

Output

8 = LVDS

Symmetry

(Duty Cycle)

5 = 45 / 55 Max.

Stability

(in ppm)

A =

25

Enable /

Disable

H = Enable

Frequency

- 156.250 MHz

NOTE: A 0.01 µF bypass capacitor is recommended between Vcc (pin 6) and GND (pin 3) to minimize power supply noise.

ILSI

America

Phone: 775-851-8880 • Fax: 775-851-8882• e-mail: e-mail@ilsiamerica.com • www.ilsiamerica.com

12/10_A

Specifications subject to change without notice

Page 1
