IDC Systems
Headers
SINGLE ROW PIN STRIP
HEADERS (STRAIGHT)
.100" CENTERS
LR49571
E60980
P
HYSICAL
P
ROPERTIES
I
NSULATION
M
ATERIAL
:
Glass reinforced thermoplastic,
rated 94V-0
C
OLOR
:
Black
O
XYGEN
I
NDEX
:
32
C
ONTACT
M
ATERIAL
:
Copper alloy, gold or tin/lead
plating over nickel
W
G
H
INTERFACE PLATING
10 µ" gold over nickel
30µ" gold over nickel
E
LECTRICAL
P
ROPERTIES
C
URRENT
R
ATING
:
3 Amps/pin
I
NSULATION
R
ESISTANCE
:
>1 x 10
9
Ohms
D
IELECTRIC
S
TRENGTH
:
>1000 VAC
Ordering Information
NUMBER OF CATALOG NO.
POSITIONS
SPECIFY W, X
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
PS-01SS-WXA
PS-02SS-WXA
PS-03SS-WXA
PS-04SS-WXA
PS-05SS-WXA
PS-06SS-WXA
PS-07SS-WXA
PS-08SS-WXA
PS-09SS-WXA
PS-10SS-WXA
A
—
2.54 (.100)
5.08 (.200)
7.62 (.300)
10.16 (.400)
12.70 (.500)
15.24 (.600)
17.78 (.700)
20.32 (.800)
22.86 (.900)
B
2.54 (.100)
5.01 (.200)
7.62 (.300)
10.16 (.400)
12.70 (.500)
15.24 (.600)
17.78 (.700)
20.32 (.800)
22.86 (.900)
25.40 (1.000)
T 100µ" tin/lead over nickel
X
A
B
MATING LENGTH
8.1 (.318)
5.8 (.230)
E
NVIRONMENTAL
P
ROPERTIES
T
EMPERATURE
R
ATING
:
-55˚C to 125˚C
PS-11SS-WXA 25.40 (1.000) 27.94 (1.100)
PS-12SS-WXA 27.94 (1.100) 30.48 (1.200)
PS-13SS-WXA 30.48 (1.200) 33.02 (1.300)
PS-14SS-WXA
33.02 (1300) 35.56 (1.400)
PS-15SS-WXA 35.56 (1.400) 38.10 (1.500)
PS-16SS-WXA 38.10 (1.500) 40.64 (1.600)
PS-17SS-WXA 40.64 (1.600) 43.18 (1.700)
PS-18SS-WXA 43.18 (1.700) 45.72 (1.800)
PS-19SS-WXA 45.72 (1.800) 48.26 (1.900)
PS-20SS-WXA 48.26 (1.900) 50.80 (2.000)
PS-21SS-WXA 50.80 (2.000) 53.34 (2.100)
PS-22SS-WXA 53.34 (2.100) 55.88 (2.200)
PS-23SS-WXA 55.88 (2.200) 58.42 (2.300)
PS-24SS-WXA 58.4212.300) 60.96 (2.400)
PS-25SS-WXA 60.96 (2.400) 63.50 i2.500)
PS-26SS-WXA 63;50 (2.500) 66.04 (2.600)
PS-27SS-WXA 66.04 (2.600) 68.58 (2.700)
PS-28SS-WXA 68.58 (2.700) 71.12 (2.800)
PS-29SS-WXA 71.12 (2.800) 73.66 (2.900)
PS-30SS-WXA 73.66 (2.900) 76.20 (3.000)
PS-31SS-WXA 76.20 (3.000) 78.74 (3.100)
PS-32SS-WXA 78.74 (3.100) 81.28 (3.200)
PS-33SS-WXA 81.28 (3.2001 83.82 (3.300)
PS-34SS-WXA 83.82 (3.300) 86.36 (3.400)
PS-35SS-WXA 86.36 (3.400) 88.90 (3.500)
PS-36SS-WXA 88.90 (3.500) 91.44 (3.600)
PS-37SS-WXA 91.44 (3.600) 93.98 (3.700)
PS-38SS-WXA 93.98 (3.700) 96.52 (3.800)
PS-39SS-WXA 96.52 (3.800) 99.06 (3.900)
PS-40SS-WXA 99.06 (3.900) 101.6 (4.000)
eg. PS-40SS-TBA
Thomas & Betts Electronics/OEM Division Tel: 901-252-5000 Fax: 901-252-1312
Dimensions shown are for reference only. Dimensions are in millimeters (inches).
41
