JR12D12-420 Overview

Single and Dual Outputs 10 Watt DC/DC Converter 2:1 Wide Input Voltage Range

DATASHEET
Rev. D
JR SERIES
2:1 Wide Input Voltage Ranges
Standard 2.0” x 1.0” x 0.4” Package
Single and Dual Outputs
10 Watt DC/DC Power Converters
FEATURES
10 Watts Maximum Output Power
Single and Dual Outputs
Standard 2.0” x 1.0” x 0.4” Package
2:1 Wide Input Voltage Ranges
High Efficiency up to 87%
No Minimum Load Requirement
1600VDC I/O Isolation
APPLICATIONS
Wireless Networks
Telecom / Datacom
Measurement Equipment
Industry Control Systems
Semiconductor Equipment
Positive or Negative Remote ON/OFF Control Option
Fixed Switching Frequency: 300KHz
Over Voltage, Over Load, and Short Circuit Protected
Extended Operating Temperature Range Available
Six-Sided Continuous Shielding
CE Mark Meets 2006/95/EC, 93/68/EEC, and 2004/108/EC
UL60950-1, EN60950-1, and IEC60950-1 Safety Approvals
Compliant to RoHS EU Directive 2002/95/EC
UL94V-0 Compliant
OPTIONS
Positive Remote ON/OFF (Suffix “P”)
Negative Remote ON/OFF (Suffix “R”)
Extended Operating Temperature Range (Suffix “-I”)
Heatsink (Suffix “HS”)
DESCRIPTION
The JR series of DC/DC power converters provides 10 watts of output power in a 2.0 x 1.0 x 0.4 inch industry standard
package and footprint. This series has single and dual output models with 2:1 wide input voltage ranges of 9-18VDC, 18-
36VDC, and 36-75VDC. Some features include high efficiency up to 87%, 1600VDC I/O isolation, and six-sided
shielding. All models are also protected against over voltage, over load, and short circuit conditions. This series is RoHS
and UL94V-0 compliant and has UL60950-1, EN60950-1, and IEC60950-1 safety approvals.
04/20/2012
Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833
603-778-2300 www.wallindustries.com Fax 603-778-9797
Page 1 of 5
