10/100BASE-T
VOICE IP MAGNETICS MODULES
Networking Components
9
LF
30
6
ELECTRICAL CHARACTERISTICS @25 C
Rise Time & Fall Time @5.0ns (Max), Hi-Pot Test @60Sec, 1500Vrms, OCL @8mA DC Bias 350uH (Min)
o
Model
Insertion
Loss
(dB Max)
1-100
MHz
1-30
Return Loss
(dB Min)
40
MHz
50
60-80
Cross Talk
(dB Min)
60
MHz
100
30
Diff. To Com.
Mode Rejection
(dB Min)
60
MHz
100
Turns Ratio
TX/RX
( 5%)
1
MHz
LF9306
-1.2
-16
-14
-13
-12
-40
-35
-43
-37
-33
1:1 / 1:1
MECHANICAL
CONSTRUCTION
A
SCHEMATICS
1
2
3
48
46
47
44
45
43
42
40
41
38
39
37
36
34
35
32
33
31
30
28
29
26
27
25
48
25
B
D
LF9306
1
24
5
4
6
7
9
8
10
11
12
E
K
F
DATE CODE
H
13
14
15
C
I
G
J
1.02
UNIT : mm / inch
A = 27.81 0.254 / 1.095 0.010
B = 12.20 0.254 / 0.480 0.010
C = 7.24 0.254 / 0.285 0.010
D = 15.24 0.254 / 0.600 0.010
E = 1.02 / 0.040 (TYP)
F = 0.41 0.127 / 0.016 0.005
G = 0.254 0.127 / 0.010 0.005
H = 0.254 / 0.010 (TYP)
I = 0.69 0.254 / 0.027 0.010
J = 0
o
~8
o
K = 23.46 / 0.924 (TYP)
17
16
18
19
21
20
22
23
24
2.54
16.76
0.64
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
252, SAN YING ROAD, KUEI SAN INDUSTRIAL ZONE, TAOYUAN SHIEN, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
Http://www.deltaww.com/products/networking
A-36
