TIGER ELECTRONIC CO.,LTD
LM2901N/D
Low Power Low Offset Voltage Quad Comparators
DESCRIPTION：
The
LM2901
consists of four independent precision
voltage comparators.These were designed specifically to
operate from a signal power supply over a wide range of
voltage.Operation from split power supplies is also possible
and the low power supply current drain is independent of the
magnitude of the power supply voltage.The
LM2901
also have
a unique characteristic in that the input common-mode voltage
range includes ground,even though operated from a single
power supply voltage.
Outline Drawing
LM2901
LM2901N
FEATURE：
Low input biasing current：25nA（TYP.）.
Low input offset current：±5.0nA（TYP.）.
Low output saturation voltage：130mV.
Output voltage compatible with TTL,CMOS.
LM2901D
DIP14
SOP14
PIN CONFIGURATION
BLOCK DIAGRAM
1/4
LM2901N/D
PIN DESCRIPTIONS
No
1
2
3
4
5
6
7
Description
Output 2
Output 1
Supply Voltage
-Input1
+Input1
-Input2
+Input2
Symbol
OUT2
OUT1
Vcc
IN1（-）
IN1（+）
IN2（-）
IN2（+）
No
8
9
10
11
12
13
14
Description
-Input3
+Input3
-Input4
+Input4
Ground
Output 4
Output 3
Symbol
IN3（-）
IN3（+）
IN4（-）
IN4（+）
GND
OUT4
OUT3
ABSOLUTE MAXIMUM RATINGS
Characteristics
Symbol
Supply Voltage
Vcc
Differential Input Voltage
V
IDR
Input Voltage
V
ICMR
Input Current
I
SC
P
D
Power Dissipation（*）
Operating Temperature Range
Tamb
Storage Temperature Range
Tstg
Note（*）
：Power
dissipation reduces 8 mW/°C for using above Ta=25°C。
Value
36 or
±18
36
-0.3~Vcc
50
1.0
-20~+85
-65~150
Unit
V
V
V
W
℃
℃
ELECTRICAL CHARACTERISTICS
（Unless
otherwise specified :Vcc=5V，Tamb=25℃）
Characteristics
Input Offset Voltage
Input Offset Current
Input Bias Current
Input
Common-mode
Voltage Range
Supply Current
Voltage Gain
Large Signal Response
Time
Response Time
Input Differential Voltage
Output Sink Current
output saturation voltage
Output Leakage Current
Test conditions
0℃
≤
Ta
≤
70℃
0℃
≤
Ta
≤
70℃
0℃
≤
Ta
≤
70℃
0℃
≤
Ta
≤
70℃
R
L
=∞
R
L
=∞，Vcc=30V
R
L
≥
15KΩ，Vcc=15V
V
IN
=TTL Logic Swing，V
REF
=1.4V，
V
RL
=5.0V， R
L
=5.1KΩ
V
RL
=5.0V， R
L
=5.1KΩ
V
IN
（-）
≥
1.0V，
IN
（+）
=0V，
≤
1.5V
V
Vo
V
IN
≥
1.0V，
IN
=0V，
SINK
≤
4.0mA
（-）
V
（+）
I
V
IN（-）
≥
1.0V，V
IN（+）
=0V，I
SINK
≤
V
IN（+）
≥
1.0V，
IN（-）
=0V，
V
Vo=5.0V
V
IN（+）
≥
1.0V，V
IN（-）
=0V，Vo=30V
0℃
≤
Ta
≤
70℃
Symbol
V
IO
I
IO
I
IB
V
ICR
Icc
Gv
t
RES
t
RES
V
ID
I
SINK
V
SAT
I
OL
1000
2/4
Mi
Typ.
±2.0
Max
Unit
mV
nA
nA
V
mA
V/mV
ns
ns
V
mA
mV
nA
0
0
50
±5.0
±9.0
±5.0
±50
±150
25
250
400
Vcc-1.5
Vcc-2.0
0.8
2.0
1.0
2.5
200
300
1.3
Vcc
6.0
16
130
0.1
400
700
