LPH
SPECIFICATIONS
Electrical Ratings
Electrical Life
Contact Resistance
Actuation Force
Actuator Travel
Dielectric Strength
Insulation Resistance
Operating Temperature
Storage Temperature
300mA @ 30VDC
20,000 cycles typical
< 50 mΩ initial
300 +/- 100gF
3.3 +/- .25mm
1000Vrms min
> 100MΩ min
-40°C to 85°C
-40°C to 85°C
MATERIALS
←
RoHS COMPLIANT
Actuator
Housing
Base
Spring
Contacts
Terminals
PC – Polycarbonate
6/6 Nylon
PBT – Polybutylene Terephthalate
Stainless Steel
Phosphor Bronze, Silver Plated
Brass, Silver Plated
ORDERING INFORMATION
1. Series:
LPH
4
LPH
2. Switch Function:
2 = DPDT
4 = 4PDT
3. Latching Options:
N = Non-Latching (Momentary)
L = Latching
4. LED Color:
R = Red
G = Green
Y = Yellow
B = Blue
5. Cap Options:
C150
C170
6. Cap Finishes:
Blank = No Cap Finish
MS = Misty Silver
L
RG
C170
MS04
**For a bi-color LED, chose two color designators (Example: RG)
Laser Etching Options:
**Only available with MS cap finish
01, 02, 03, 04, 05
06, 07, 08, 09, 10
DIMENSIONS
SCHEMATIC & PC LAYOUT
(BOTTOM VIEWS)
2 POLE
www.citswitch.com
page
17
phone – 763.535.2339 fax – 763.535.2194
LPH
DIMENSIONS
SCHEMATIC & PC LAYOUT
(BOTTOM VIEWS)
4 POLE
LED SPECIFICATIONS
LED Ratings
Reverse Voltage
Forward Current (avg)
Forward Current (peak)
Reverse Current V
R
= 5V
Power Dissipation
Operating & Storage Temperature
Forward Voltage (typ.), I
F
= 20mA
Forward Voltage (max.), I
F
= 20mA
Wavelength at Peak Emmission, I
F
= 20mA
Spectral Line Half-Width, I
F
= 20mA
Luminous Intensity, I
F
= 20mA
Viewing Angle
V
R
I
F
I
FS
I
R
P
T
T
V
F
V
F
λ
P
∆λ
LI
Θ
R
5
15
60
10
40
1.7
2.6
697
90
7.6
44
Value
G
Y
5
5
30
20
120
80
10
10
100
60
-40~ +85
1.7
1.7
2.6
2.6
565 585
30
35
26
26
44
44
Units
B
5
30
100
10
120
3.5
4.0
470
25
450
30
V
mA
mA
µA
mW
°C
V
V
nm
nm
mcd
Deg
CAP OPTIONS
C150
C170
LASER ETCHING OPTIONS
01
02
03
04
05
06
07
08
page
18
09
10
www.citswitch.com
phone – 763.535.2339 fax – 763.535.2194
