0805N180K201CG

Description
Ceramic Capacitor, Multilayer, Ceramic, 200V, 10% +Tol, 10% -Tol, C0G, 30ppm/Cel TC, 0.000018uF, Surface Mount, 0805, CHIP, LEAD FREE
CategoryPassive components    capacitor
File Size574KB,10 Pages
ManufacturerWalsin Technology Corporation
Environmental Compliance
Download Datasheet Parametric View All

0805N180K201CG Overview

Ceramic Capacitor, Multilayer, Ceramic, 200V, 10% +Tol, 10% -Tol, C0G, 30ppm/Cel TC, 0.000018uF, Surface Mount, 0805, CHIP, LEAD FREE

0805N180K201CG Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerWalsin Technology Corporation
package instruction, 0805
Reach Compliance Codecompliant
ECCN codeEAR99
capacitance0.000018 µF
Capacitor typeCERAMIC CAPACITOR
dielectric materialsCERAMIC
high0.6 mm
JESD-609 codee2
length2 mm
Manufacturer's serial number0805
Installation featuresSURFACE MOUNT
multi-layerYes
negative tolerance10%
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package shapeRECTANGULAR PACKAGE
Package formSMT
method of packingTR, PAPER, 13 INCH
positive tolerance10%
Rated (DC) voltage (URdc)200 V
seriesSIZE(MID/HIGH VOLT)
size code0805
surface mountYES
Temperature characteristic codeC0G
Temperature Coefficient-/+30ppm/Cel ppm/°C
Terminal surfaceTin/Nickel/Copper (Sn/Ni/Cu)
Terminal shapeWRAPAROUND
width1.25 mm
MULTILAYER CERAMIC CAPACITORS
Middle and High Voltage Series (200V to 3kV)
1. INTRODUCTION
WTC middle and high voltage series MLCC is designed by a special internal electrode pattern, which can reduce
voltage concentrations by distributing voltage gradients throughout the entire capacitor. This special design also affords
increased capacitance values in a given case size and voltage rating.
Chips size 1206 and larger to use on reflow soldering process only. Capacitors with X7R dielectrics are not
intended for AC line filtering applications. Capacitors may require protective surface coating to prevent external
arcing.
2. FEATURES
a.
b.
High voltage in a given case size.
High stability and reliability.
3. APPLICATIONS
a.
b.
c.
d.
Snubbers in high frequency power converters.
High voltage coupling/DC blocking.
DC-DC converters.
Back-lighting inverters
4. HOW TO ORDER
1808
Size
Inch (mm)
0603
(1608)
0805
(2012)
1206
(3216)
1210
(3225)
1808
(4520)
1812
(4532)
N
Dielectric
N=NP0
(C0G)
B=X7R
F=Y5V
100
Capacitance
Two significant
digits followed by
no. of zeros. And R
is in place of
decimal point.
eg.:
0R5=0.5pF
1R0=1.0pF
100=10x10
0
=10pF
J
Tolerance
B=±0.1pF
C=±0.25pF
D=±0.5pF
G=±2%
J=±5%
K=±10%
M=±20%
Z=-20/+80%
202
Rated voltage
L
Termination
T
Packaging
Two significant digits
C=Cu/Ni/Sn
(for NP0,
T=7”
reeled
followed by no. of zeros. X7R, Y5V dielectric)
G=13”
reeled
And R is in place of
L=Ag/Ni/Sn
(for
decimal point.
partial NP0 items)
201=200
VDC
251=250
VDC
501=500
VDC
631=630
VDC
102=1000
VDC
202=2000
VDC
302=3000
VDC
* Partial NP0;X7R items are with Ag/Ni/Sn terminations, please ref to below product range of NP0;X7R dielectric for detail.
WALSIN TECHNOLOGY CORPORATION
566-1,Kao-Shi Road, 5 Lin, Yang-Mei, Tao-Yuan, Taiwan
www.passivecomponent.com
00-T003O-AS_HV
Revision O
1/10
Mar. 09 2010
