DWWC-13-A-EVEN-E-S-B-A: DescriptionSplitter/Coupler, 1X3 Port, 33/34 Ratio, FC/UPC Connector; CategoryWireless rf/communication Optical fiber; File Size196KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

DWWC-13-A-EVEN-E-S-B-A Overview

Splitter/Coupler, 1X3 Port, 33/34 Ratio, FC/UPC Connector

DWWC-13-A-EVEN-E-S-B-A Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknown
Other features	IT ALSO HAVE COUPLING RATIO 33/33
Connection Type	FC/UPC CONNECTOR
Fiber optic equipment types	SPLITTER/COUPLER
Fiber type	SMF-28
Maximum insertion loss	5.9 dB
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Nominal operating wavelength	1310 nm
Port configuration	1X3
minimum return loss	50 dB
Split ratio/coupling ratio	33/34

Preview

Download Datasheet

View All

FBT COUPLER

1 x 3 Single Fused Dual Window Wideband Coupler

Parameter

Operating Wavelength Range

Insertion Loss (Max)

Uniformity (Typical)

Return Loss

PDL

TDL

Operating & Storage Temperature

Package Dimensions

Light Duty ( B )

Medium Duty ( L )

Premium

A Grade

1311 & 1550 ± 40 nm

≤ 5.6 dB

≤ 1.2 dB

≥ 50

≤ 0.1 dB

≤ 0.2dB (- 10° C ~ + 75° C)

≤ 0.15 dB

≤ 0.4dB (- 40° C ~ + 85° C)

≤ 5.9 dB

≤ 1.6 dB

- 40° C ~ + 85° C

3.0mm (Φ) x 55.0mm (L)

3.0mm (Φ) x 70.0mm (L)

Note1: All values specified are without connectors.

Note3: Fiber type Corning SMF-28e.

D W WC - 1 3

Port Number

13: 1 x 3

-

Grade

P: Premium

A: A Grade

EVEN

Coupling Ratio

EVEN: 33/33/34

-

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

Wavelength

E: 1310 nm

F: 1480 nm

G: 1510 nm

H: 1550 nm

L: 1625 nm

Fiber Length

Pigtail Style

1: 1 meter

(=Package style)

2: 2 meter

B: bare fiber

S: Special

L: 900

µm

loose tube

www.lighteltech.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
