DSF-A15SB-KJ-200 datasheet, PDF

Datasheet> All Categories > The connector> The connector> DSF-A15SB-KJ-200

DSF-A15SB-KJ-200: DescriptionD Type Connector, 15 Contact(s), Female, 0.108 inch Pitch, Solder Lug Terminal, #4-40, Plug; CategoryThe connector The connector; File Size244KB，4 Pages; ManufacturerSingatron Enterprises Co

Download Datasheet Parametric View All

DSF-A15SB-KJ-200 Overview

D Type Connector, 15 Contact(s), Female, 0.108 inch Pitch, Solder Lug Terminal, #4-40, Plug

DSF-A15SB-KJ-200 Parametric

Parameter Name	Attribute value
Maker	Singatron Enterprises Co
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	FERRITE FILTER
body width	0.494 inch
subject depth	0.315 inch
body length	1.541 inch
Body/casing type	PLUG
Contactor design	PREASSEM CONN
Contact to complete cooperation	AU ON NI
Contact completed and terminated	GOLD
Contact point gender	FEMALE
Contact material	BRASS
contact mode	STAGGERED
Contact resistance	8 mΩ
Contact style	RND PIN-SKT
Dielectric withstand voltage	1000VAC V
Filter function	YES
maximum insertion force	2.502 N
Insulation resistance	5000000000 Ω
Insulator color	BLACK
insulator material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Manufacturer's serial number	DSF
Plug contact pitch	0.108 inch
Match contact row spacing	0.112 inch
Installation option 1	#4-40
Installation option 2	CLINCH NUT JACKSCREW
Installation type	PANEL
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Plating thickness	5u inch
Rated current (signal)	5 A
Guideline	UL
reliability	COMMERCIAL
Shell surface	TIN
Shell material	STEEL
Terminal length	0.13 inch
Termination type	SOLDER LUG
Total number of contacts	15
Maximum wire diameter	20 AWG
Minimum wire diameter	20 AWG
Evacuation force-minimum value	1.112 N

Preview
