SRC1219S Overview

NPN Silicon Transistor

Semiconductor
SRC1219S
NPN Silicon Transistor
Descriptions
Switching application
Interface circuit and driver circuit application
Features
With built-in bias resistors
Simplify circuit design
Reduce a quantity of parts and manufacturing process
High packing density
Ordering Information
Type NO.
SRC1219S
Marking
RCC
Package Code
SOT-23
Outline Dimensions
2.4±0.1
1.30±0.1
unit :
mm
Equivalent Circuit
C(OUT)
1
1.90 Typ.
3
2
2.9±0.1
B(IN)
R
1
R
2
0.4 Typ.
0.45~0.60
E(COMMON)
0.2 Min.
1.12 Max.
0~0.1
0.124
PIN Connections
1. Base
2. Emitter
3. Collector
R
1
4.7KΩ
R
2
10KΩ
0.38
-0.03
+0.05
KSR-2024-000
