Semiconductor
SRC1203S
NPN Silicon Transistor
Descriptions
•
Switching application
•
Interface circuit and driver circuit application
Features
•
•
•
•
With built-in bias resistors
Simplify circuit design
Reduce a quantity of parts and manufacturing process
High packing density
Ordering Information
Type NO.
SRC1203S
Marking
RC3
Package Code
SOT-23
Outline Dimensions
2.4±0.1
1.30±0.1
unit :
mm
•
Equivalent Circuit
C(OUT)
1
1.90 Typ.
3
2
2.9±0.1
B(IN)
R
1
R
2
0.4 Typ.
0.45~0.60
E(COMMON)
0.2 Min.
1.12 Max.
0~0.1
0.124
PIN Connections
1. Base
2. Emitter
3. Collector
R
1
22KΩ
Ω
R
2
22KΩ
Ω
0.38
-0.03
+0.05
KSR-2019-000
