Semiconductor
SRA2202EF
PNP Silicon Transistor
Descriptions
•
Switching application
•
Interface circuit and driver circuit application
Features
•
•
•
•
With built-in bias resistors
Simplify circuit design
Reduce a quantity of parts and manufacturing process
High packing density
Ordering Information
Type NO.
SRA2202EF
Marking
2R
Package Code
SOT-523F
Outline Dimensions
unit :
mm
•
Equivalent Circuit
1.60±0.1
.
0.88±0.1
.
C(OUT)
1
1.60±0.1
1.00±0.1
B(IN)
R
1
3
2
0.25~0.30
R
2
E(COMMON)
0.68
-0.05
0~0.1
1.11±0.05
PIN Connections
1. Base
2. Emitter
3. Collector
+0.1
R
1
10KΩ
Ω
R
2
10KΩ
Ω
KSR-4010-000
1
