Datasheet> All Categories > Discrete semiconductor> diode> SR860

Preview

SR860: Description8 A, 40 V, SILICON, RECTIFIER DIODE, TO-220AA; CategoryDiscrete semiconductor diode; File Size26KB，2 Pages; ManufacturerRectron Semiconductor; Websitehttp://www.rectron.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

SR860 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SR860	-	-	View	Buy Now

SR860 Overview

8 A, 40 V, SILICON, RECTIFIER DIODE, TO-220AA

SR860 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Rectron Semiconductor
Parts packaging code	TO-220AC
package instruction	ROHS COMPLIANT, PLASTIC, TO-220A, 2 PIN
Contacts	3
Reach Compliance Code	compli
ECCN code	EAR99
Other features	HIGH RELIABILITY, LOW NOISE
application	GENERAL PURPOSE
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.75 V
JEDEC-95 code	TO-220AC
JESD-30 code	R-PSFM-T2
JESD-609 code	e3
Humidity sensitivity level	1
Maximum non-repetitive peak forward current	150 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Maximum output current	8 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	265
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	60 V
Maximum reverse current	5000 µA
surface mount	NO
technology	SCHOTTKY
Terminal surface	MATTE TIN
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

RECTRON

SEMICONDUCTOR

TECHNICAL SPECIFICATION

SR820

THRU

SR860

SCHOTTKY BARRIER RECTIFIER

VOLTAGE RANGE 20 to 60 Volts CURRENT 8.0 Amperes

FEATURES

*

Low switching noise

Low forward voltage drop

Low thermal resistance

High current capability

High surge capabitity

High reliability

TO-220A

.413 (10.5)

.374 (9.5)

.187 (4.7)

( )

(3.9) .148 3.8

.153

.146 (3.7)

.270 (6.9)

.230 (5.8)

.610 (15.5)

.583 (14.8)

.04MAX.

(1.0)

.157

(4.0)

.051

(1.3)

.043 (1.1)

.035 (0.9)

.102 (2.6)

.091 (2.3)

.583 (14.8)

.531 (13.5)

.053 (1.3)

.047 (1.2)

MECHANICAL DATA

*

Case: To-220A molded plastic

Epoxy: Device has UL flammability classification 94V-O

Lead: MIL-STD-202E method 208C guaranteed

Mounting position: Any

Weight: 2.24 grams

.108

(2.75)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25 C ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

o

.022 (0.56)

.014 (0.36)

.126

(3.2)

Dimensions in inches and (millimeters)

MAXIMUM RATINGS

(At T

A

= 25

o

C unless otherwise noted)

RATINGS

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current

at Derating Case Temperature

Peak Forward Surge Current 8.3 ms single half sine-wave

superimposed on rated load (JEDEC method)

Typical Thermal Resistance (Note 1)

Typical Junction Capacitance (Note 3)

Operating Temperature Range

Storage Temperature Range

SYMBOL

V

RRM

V

RMS

V

DC

I

O

I

FSM

R

θ

JC

C

J

T

J

T

STG

700

-65 to + 125

-65 to + 150

SR820

20

14

20

SR830

30

21

30

SR835

35

25

35

SR840

40

28

40

8.0

150

2.5

450

-65 to + 150

SR845

45

32

45

SR850

50

35

50

SR860

60

42

60

UNITS

Volts

Amps

0

C/ W

pF

0

C

ELECTRICAL CHARACTERISTICS

(At T

A

= 25 C unless otherwise noted)

CHARACTERISTICS

Maximum Instantaneous Forward Voltage at 8.0A DC

Maximum Average Reverse Current

at Rated DC Blocking Voltage

@T

C

= 25 C

@T

C

= 100

o

C

o

SYMBOL

V

F

I

R

SR820

SR830

SR835

.65

SR840

5.0

50

SR845

SR850

.75

SR860

UNITS

Volts

mAmps

2001-4

NOTES : 1. Thermal Resistance Junction to Case.

2. Suffix “R” for Reverse Polarity.

2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
