RECTRON
SEMICONDUCTOR
TECHNICAL SPECIFICATION
SR320
THRU
SR360
SCHOTTKY BARRIER RECTIFIER
VOLTAGE RANGE 20 to 60 Volts CURRENT 3.0 Amperes
FEATURES
*
*
*
*
*
*
*
Fast switching
Low switching noise
Low forward voltage drop
High current capability
High switching capability
High reliability
High surge capability
DO-201AD
MECHANICAL DATA
*
*
*
*
*
Case: Molded plastic
Epoxy: UL 94V-O rate flame retardant
Lead: MIL-STD-202E method 208C guaranteed
Mounting position: Any
Weight: 1.18 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
o
MAXIMUM RATINGS
(At T
A
= 25
o
C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
.375” (9.5mm) lead length
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Typical Thermal Resistance (Note 1)
Typical Junction Capacitance (Note 2)
Operating Temperature Range
Storage Temperature Range
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
R
θ
JA
C
J
T
J
T
STG
-65 to + 125
-65 to + 150
SR320
20
14
20
SR330
30
21
30
SR340
40
28
40
3.0
80
30
200
-65 to + 150
SR350
50
35
50
SR360
60
42
60
UNITS
Volts
Volts
Volts
Amps
Amps
0
C/ W
pF
0
0
C
C
ELECTRICAL CHARACTERISTICS
(At T
A
= 25 C unless otherwise noted)
CHARACTERISTICS
Maximum Instantaneous Forward Voltage at 3.0A DC
Maximum Average Reverse Current
at Rated DC Blocking Voltage
@T
A
= 25 C
@T
A
= 100
o
C
o
o
SYMBOL
V
F
I
R
SR320
SR330
.55
SR340
3.0
30
SR350
.75
SR360
UNITS
Volts
mAmps
mAmps
1998-8
NOTES : 1. Thermal Resistance (Junction to Ambient): Vertical PC Board Mounting, 0.5” (12.7mm) Lead Length.
2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
