MATP/MATL SERIES
PAGE ONE OF THREE
%2$5'0281762&.(7
FEATURES
Mates with itself for thru-board stacking without headers
Standard and TAILORED heights availble
Accepts 0.025" (0,64mm) square posts
Low Insertion Force (LIF) contacts available
Mates with Crane’s PEG, MPEG, DPEG, LPEG, TPEG Headers
SINGLE ROW (1 to 36 Positions)
STANDARD PART DIMENSIONS
INSULATOR BODY
(TOP)
W1
H1
WIDTH
HEIGHT
Single Row
Dual Row
Triple Row
0.100" / 2,54mm
0.325" / 8,25mm
0.200" / 5,08mm
0.325" / 8,25mm
0.300" / 7,62mm
0.325" / 8,25mm
DUAL ROW (2 to 72 Positions)
INSULATOR BODY
(BOTTOM)
W2
H2
S
WIDTH
HEIGHT
STANDOFF
Single Row
Dual Row
Triple Row
0.096" / 2,44mm
0.098" / 2,49mm
0.015" / 0,38mm
Single Row
0.198" / 5,03mm
0.098" / 2,49mm
0.015" / 0,38mm
Dual Row
0.295" / 7,49mm
0.098" / 2,49mm
0.015" / 0,38mm
Triple Row
OVERALL HEIGHT
TH
IH
TOTAL
Please refer to the chart on the next page
INSTALLED
MATERIALS
INSULATOR
CONTACT
Glass Filled Polyester (UL94V-O)
Phosphor Bronze
TRIPLE ROW (9 to 108 Positions)
See SPECIFICATIONS and PERFORMANCE DATA for more information.
Elevated
Sockets available in
a SOLID STACK
option as well.
SAMPLE HOTLINE: 1-800-676-7644
CRANE CONNECTORS
• 4700 Smith Road • Cincinnati, Ohio 45212 USA • E-mail Address: info@craneconnectors.com
Phone: (513) 631-4700 • Fax (513) 631-5700 • Toll Free US (800) 676-7644 • Canada (800) 420-7310
MATP/MATL SERIES
0.100" (2,54mm) Centers
To Mate With 0.025" (0,64mm)
Square Mating Posts
PAGE TWO OF THREE
HOW TO ORDER CRANE’S MATP/MATL SERIES
STANDARD PART NUMBER
--
--
PRODUCT SERIES
HIGH TEMP OPTION
MAT
GMAT
CONTACT
LIF is not available with tin plating on mating area.
STANDARD
LIF
FORCE
P
L
NUMBER OF POSITIONS
SINGLE
DUAL
TRIPLE
01-36
02-72
09-108
NUMBER OF ROWS
SINGLE
DUAL
TRIPLE
S
D
T
TYPE OF SOCKET
STRAIGHT
S
CONTACT PLATING (See Plating Specs Below)
CHOOSE G, T or M,H,L,F
NOTE: Some platings may be subject to minimums
TAIL
SQUARE
0.025" / 2,54mm
KINKED
Q
K
INSULATOR SPACERS
SOLID STACK
SINGLE INSULATOR AT BOTTOM
A
B
SELECTED OPTIONS
Many other sizes are available. Please contact the factory and
give us your EXACT requirements.
INSTALLED HEIGHT “B”
0.400" = B
0.435" = C
0.435" = C
0.435" = C
0.500" = G
0.535" = H
0.535" = H
0.600" = L
0.635" = M
0.635" = M
0.700" = Q
TOTAL HEIGHT “D”
0.525" = F
0.525" = F
0.725" = N
0.915" = T
0.725" = N
0.725" = N
0.915" = T
0.725" = N
0.725" = N
0.915" = T
0.915" = T
B
C
C
C
G
H
H
L
M
M
Q
F
F
N
T
N
N
T
N
N
T
T
0.735" = R
0.915" = T
0.915" = T
0.915" = T
R
V
W
T
T
T
Crane’s MATP Series can be used with our MPEG Series for
ULTRA-HIGH board stacking needs.
0.800" = V
0.835" = W
CRANE CONNECTORS - PLATING SPECIFICATIONS
PLATING OPTIONS
CONTACT AREA
Inches (Millimeters)
15
” (0,,00038) Gold
100
” (0,00254) Tin / Lead
50
” (0,00127) Gold
30
” (0,00076) Gold
10
” (0,00025) Gold
3
” (0,00008) Gold
PC TAIL
Inches (Millimeters)
100
” (0,00254) Tin/Lead - Min
100
” (0,00254) Tin/Lead - Min
100
” (0,00254) Tin/Lead - Min
100
” (0,00254) Tin/Lead - Min
100
” (0,00254) Tin/Lead - Min
100
” (0,00254) Tin/Lead - Min
UNDERPLATE
Inches (Millimeters)
50
” (0,00127) Nickel - Min.
50
” (0,00127) Nickel - Min.
50
” (0,00127) Nickel - Min.
50
” (0,00127) Nickel - Min.
50
” (0,00127) Nickel - Min.
50
” (0,00127) Nickel - Min.
G
T
M
H
L
F
Selective
Tin / Lead
Selective
Selective
Selective
Selective
STANDARDS
ISO9001
UL File No. E120111 (N)
Crane Connectors
File No. A-3620
Recognized to U.S. and
Canadian requirements
under the Component
Recognition Program of
Underwriters Laboratories
Inc.
Registered by UL to ISO9001
under UL’s accreditation by
Raad voor de Certificatie
(RvC), the Dutch Council for
Certification.
ENGINEERING NOTE: The information presented in this catalog page is accurate to the best of our knowledge. Due to ongoing efforts to advance
design and material performance, the information is subject to change without notice.
SAMPLE HOTLINE: 1-800-676-7644
CRANE CONNECTORS
• 4700 Smith Road • Cincinnati, Ohio 45212 USA • E-mail Address: info@craneconnectors.com
Phone: (513) 631-4700 • Fax (513) 631-5700 • Toll Free US (800) 676-7644 • Canada (800) 420-7310
