SURFACE MOUNT
NETWORKS
OSOP
Vishay Thin Film
SURFACE MOUNT
Molded, 25 Mil Pitch, Dual-In-Line Resistor Network
FEATURES
• 0.068" (1.73mm) maximum seated height
• Rugged molded case construction with no internal solder
• Highly stable thin film
Actual Size
• JEDEC MO #137 Package AD
OSOP Series resistor networks feature a space saving 25
Mil lead pitch versus the current 50 Mil pitch standard. This
allows users to reduce board space more than 50% over
current standards. The OSOP Series feature 10 isolated
resistors in a 20 lead style available for immediate delivery
in the standard values listed.
TYPICAL PERFORMANCE
q
TCR
TOL
ABS
25
ABS
0.1
TRACKING
5
RATIO
0.05
SCHEMATIC
20
19
18
17
16
15
14
13
12
11
STANDARD RESISTANCE OFFERING
(R
1
= )
500 ohms
1K ohms
2K ohms
10K ohms
20K ohms
50K ohms
100K ohms
1
2
3
4
5
6
7
8
9
10
5K ohms
Consult factory for additional values.
STANDARD ELECTRICAL SPECIFICATIONS
TEST
MATERIAL
TCR:
Tolerance:
Power Rating:
Stability
Voltage Coefficient
Working Voltage
Operating Temperature Range
Storage Temperature Range
Noise
Thermal EMF
Shelf Life Stability: Absolute
Ratio
Tracking
Absolute
Ratio
Absolute
Resistor
Package
SPECIFICATIONS
TAMELOX®
±
5ppm/°C
±
25ppm/°C
±
0.5%,
±
0.1%,
±
0.05%
±
1%,
±
0.5%,
±
0.25%,
±
0.1%
100mW
400mW
500ppm
150ppm
< 0.1ppm/Volt typical
100 Volts Max.
- 55°C to + 125°C
- 55°C to + 150°C
< - 30dB
0.08µV/°C
100ppm
20ppm
1 year @ + 25°C
1 year @ + 25°C
- 55°C to + 125°C
- 55°C to + 125°C
+ 25°C
+ 25°C
Max. @ + 70°C
Max. @ + 70°C
2000 hrs @ + 70°C
2000 hrs @ + 70°C
CONDITIONS
∆
R Absolute
∆
R Ratio
VISHAY THIN FILM • FRANCE +33.4.93.37.28.24 FAX: +33.4.93.37.27.31 • GERMANY +49.9287.710 FAX: +49 9287.70435 • ISRAEL +972.3.557.0945 FAX: +972.3.558.9121
• ITALY + 39.2.300.11919 FAX: +39.2.300.11999 • JAPAN +81.42.729.0661 FAX: +81.42.729.3400 • SINGAPORE +65.788.6668 FAX: +65.788.0988
• SWEDEN +46.8.594.70590 FAX: +46.8.594.70581 • UK +44 191 514 8237 FAX: +44 1953 457 722 • USA: (610) 407-4800 FAX: (610) 640-9081
www.vishay.com
16
Document Number: 60002
Revision 03-May-01
SURFACE MOUNT
SURFACE MOUNT
SURFACE MOUNT
NETWORKS
OSOP
Molded, 25 Mil Pitch, Dual-In-Line Resistor Network
Vishay Thin Film
DIMENSIONS AND IMPRINTING
in inches and millimeters
DIMENSION
A
INCHES
0.344
0.154
0.237
0.025
0.010
±0.002
0.062
0.068
0.010
±0.002
0.025
0.057
MILLIMETERS
8.74
3.91
6.02
0.635
0.25
±0.05
1.58
1.73
0.25
±0.05
0.64
1.47
A
Logo
D
J
Part
Number
Marking
B
E
C
F
G
C
D
E
F
PIN 1
Locator
H
B
Date
Code
I
G
H
I
J
MECHANICAL SPECIFICATIONS
Resistive Element
Substrate Material
Body
Terminal
Lead Coplanarity
Marking Resistance to Solvents
Tamelox®
Silicon
Molded Epoxy
Copper Alloy 194 Solderable
±
0.004” (± 0.50mm)
per MIL-PRF-83401
How to Order
Series
OSOP
=
20 leaded
SO style
Schematic
A
= 10 nominally equal
resistors with each
resistor isolated from
all others and wired
directly across
Resistance Value
The first 3 digits are significant
figures and the last digit specifies
the number of zeros to follow.
eg.
1001
= 1K
1002
= 10K
Tolerance and Ratio Tolerance
Abs. Tol.
*A
=
±0.1%
B
=
±0.1%
C
=
±0.25%
D
=
±0.5%
F
=
±1.0%
Ratio
±0.05%
±0.1%
±0.1%
±0.1%
±0.5%
*Tolerance available on
1K ohm and up only.
Example: OSOPA5000B
is a 20 lead small outline molded network with 10 resistors, 500 ohms each resistor, 0.1% absolute
tolerance, 0.1% ratio to R1.
All parts are shipped in tubes unless tape and reel packaging is requested.
VISHAY THIN FILM • FRANCE +33.4.93.37.28.24 FAX: +33.4.93.37.27.31 • GERMANY +49.9287.710 FAX: +49 9287.70435 • ISRAEL +972.3.557.0945 FAX: +972.3.558.9121
• ITALY + 39.2.300.11919 FAX: +39.2.300.11999 • JAPAN +81.42.729.0661 FAX: +81.42.729.3400 • SINGAPORE +65.788.6668 FAX: +65.788.0988
• SWEDEN +46.8.594.70590 FAX: +46.8.594.70581 • UK +44 191 514 8237 FAX: +44 1953 457 722 • USA: (610) 407-4800 FAX: (610) 640-9081
Document Number: 60002
Revision 03-May-01
www.vishay.com
17
