SERIES:
PBK-5
│
DESCRIPTION:
AC-DC POWER SUPPLY
FEATURES
• up to 5 W continuous output
• ultra compact SIP package
• universal input voltage: (85~264 Vac / 100~400 Vdc)
• single regulated outputs from 3.3~24 Vdc
• 3,000 Vac isolation
• over current, short circuit, and over voltage protections
• UL 60950-1 safety approval
• efficiency up to 75%
MODEL
PBK-5-3
PBK-5-5
PBK-5-9
PBK-5-12
PBK-5-15
PBK-5-24
Note:
output
voltage
(Vdc)
output
current
max
(A)
output
power
max
(W)
ripple
and noise
1
max
(mVp-p)
efficiency
typ
(%)
3.3
5
9
12
15
24
1
1
0.56
0.42
0.34
0.21
3.3
5
5
5
5
5
150
120
120
120
120
150
65
70
72
74
75
75
1. Measured at 20 MHz bandwidth, see Test Configuration section.
PART NUMBER KEY
PBK-5-
XX - X
Base Number
Output Voltage
Orientation
“blank” = vertical
B = right-angle
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
PBK-5
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
06/07/2016
│
page
2 of 7
INPUT
parameter
voltage
frequency
current
inrush current
leakage current
no load power consumption
input fuse
1 A/250 V, slow-blow type (external, recommended)
at 115 Vac
at 230 Vac
at 115 Vac
at 230 Vac
CY0 is 1nF/400Vac
20
30
0.25
0.5
conditions/description
min
85
100
47
typ
max
264
400
440
200
100
units
Vac
Vdc
Hz
mA
mA
A
A
mA
W
OUTPUT
parameter
output current
3.3 Vdc output models
5 Vdc output models
9 Vdc output models
12 Vdc output models
15 Vdc output models
24 Vdc output models
at full load
at 10%~100% load
PBK-5-3
all other models
at 115 Vac
at 230 Vac
20
80
100
±0.02
±0.1
±1.0
±2
±1
conditions/description
min
10
2200
1500
680
470
330
100
±0.5
±1.5
±3
±2
typ
max
units
%
μF
μF
μF
μF
μF
μF
%
%
%
%
ms
ms
kHz
%/°C
capacitive load
line regulation
load regulation
voltage set accuracy
hold-up time
switching frequency
temperature coefficient
PROTECTIONS
parameter
short circuit protection
over current protection
over voltage protection
conditions/description
continuous, auto restart
auto restart
zener diode clamp
110
%
min
typ
max
units
SAFETY & COMPLIANCE
parameter
isolation voltage
isolation resistance
safety approvals
safety standards
safety class
conducted emissions
radiated emissions
ESD
radiated immunity
EFT/burst
UL 60950-1
UL 60950-1
class II
CISPR22/EN55022 external circuit required, Class A (see figure 2); Class B (see figure 3)
CISPR22/EN55022 external circuit required, Class B (see figures 2 or 3)
IEC/EN61000-4-2 Class B, contact ±4 kV
IEC/EN61000-4-3 Class A, 10V/m
IEC/EN61000-4-4 Class B, ±2 kV (external circuit required, see figure 2)
IEC/EN61000-4-4 Class B, ±4 kV (external circuit required, see figure 3)
conditions/description
input to output for 1 minute at 5mA
min
3,000
100
typ
max
units
Vac
MΩ
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
PBK-5
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
06/07/2016
│
page
3 of 7
SAFETY & COMPLIANCE (CONTINUED)
parameter
surge
conducted immunity
PFM
voltage dips & interruptions
MTBF
RoHS
conditions/description
min
typ
max
units
IEC/EN61000-4-5 Class B, ±1 kV/±2 kV (external circuit required, see figure 3)
IEC/EN61000-4-6 Class A, 3 Vr.m.s (external circuit required, see figure 3)
IEC/EN61000-4-8 Class A, 10 A/m
IEC/EN61000-4-11 Class B, 0%-70%
at 25°C, max. load
2011/65/EU
300,000
hours
ENVIRONMENTAL
parameter
operating temperature
storage temperature
case temperature
humidity
non-condensing
conditions/description
see derating curves
min
-25
-40
typ
max
85
105
100
85
units
°C
°C
°C
%
DERATING CURVES
load vs. ambient temperature
(at 110~240 Vac input voltage)
100
80
60
40
20
100
80
60
40
20
load vs. input voltage (Vac)
(at 25°C)
100
80
60
40
20
load vs. input voltage (Vdc)
(at 25°C)
~
~
Safe operating area
135
~
~
~
~
Load (%)
Safe operating area
Load (%)
Safe operating area
Load (%)
~
~
~
~
-25
-15
-5
0
5
45
55
65
75
85
95
85
95
105 110 115
125
235 240 245
255
264
100
~
~
320
353
Ambient Temperature (°C)
Input Voltage (Vac)
Input Voltage (Vdc)
EFFICIENCY CURVES
efficiency vs. load
PBK-5-12
85 VAC
efficiency vs. input voltage (Vac)
Efficency (%)
120 VAC
220 VAC
230 VAC
240 VAC
264 VAC
Efficiency (%)
110 VAC
PBK-5-3
PBK-5-5
PBK-5-9
PBK-5-12
PBK-5-15
PBK-5-24
Load (%)
Input Voltage (VAC)
efficiency vs. load
PBK-5-12
100 VDC
200 VDC
300 VDC
400 VDC
efficiency vs. input voltage (Vdc)
Efficency (%)
PBK-5-3
PBK-5-5
PBK-5-9
PBK-5-12
PBK-5-15
PBK-5-24
Load (%)
Input Voltage (VDC)
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
PBK-5
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
06/07/2016
│
page
4 of 7
SOLDERABILITY
parameter
hand soldering
wave soldering
conditions/description
for 3~5 seconds
for 5~10 seconds
min
350
255
typ
360
260
max
370
265
units
°C
°C
MECHANICAL
parameter
dimensions
material
weight
conditions/description
vertical models: 42 x 11 x 27
right-angle models: 42 x 25 x 13
UL94V-0
10
g
min
typ
max
units
mm
mm
MECHANICAL DRAWING
VERTICAL ORIENTATION
units: mm[inch]
tolerance: ±0.5[±0.020]
pin tolerance: ±0.1[±0.004]
PIN CONNECTIONS
PIN
1
3
5
7
12
14
FUNCTION
-Vin (N)
+Vin (L)
+V(CAP)
-V(CAP)
-Vo
+Vo
Note: 1. It is required to add C1 between
pins 5 & 7 (see application circuits).
Front View
Top View
PCB Layout
Bottom View
cui.com
For more information, please visit the
product page.
CUI Inc
│
SERIES:
PBK-5
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
06/07/2016
│
page
5 of 7
MECHANICAL DRAWING (CONTINUED)
RIGHT-ANGLE ORIENTATION
units: mm[inch]
tolerance: ±0.5[±0.020]
pin tolerance: ±0.1[±0.004]
PIN CONNECTIONS
PIN
1
3
5
7
12
14
FUNCTION
-Vin (N)
+Vin (L)
+V(CAP)
-V(CAP)
-Vo
+Vo
Note: 1. It is required to add C1 between
pins 5 & 7 (see application circuits).
Front View
Side View
Top View
PCB Layout
Bottom View
TEST CONFIGURATION
Table 1
C on n e c t Os c illo g r ap h Pro b e
C o pp e r s h e e t
F U SE
+Vo
C2
L1
Recommended External Circuit Components
V
OUT
(Vdc)
3.3
C1
1
22μF/400V
22μF/400V
22μF/400V
22μF/400V
22μF/400V
22μF/400V
C2
1
470μF/10V
470μF/16V
330μF/25V
330μF/25V
330μF/25V
100μF/35V
L1
1
0.47μH
0.47μH
1μH
1μH
1μH
4.7μH
C3
1
150μF/35V
150μF/35V
150μF/35V
150μF/35V
150μF/35V
47μF/35V
C4
100nF/50V
100nF/50V
100nF/50V
100nF/50V
100nF/50V
100nF/50V
CY0
(Y1
capacitor)
1nF/400Vac
1nF/400Vac
1nF/400Vac
1nF/400Vac
1nF/400Vac
1nF/400Vac
Figure 1
C1
AC -D C
C3
C4
L oa d
5
9
12
15
24
Note:
-Vo
C Y0
1. Required components.
2. 1 A/250 V fuse required.
