Multilayer Ceramic Chip Capacitors
FEATURES
• X7R, X5R AND Y5V DIELECTRICS
• HIGH CAPACITANCE DENSITY
• ULTRA LOW ESR & ESL
• EXCELLENT MECHANICAL STRENGTH
• NICKEL BARRIER TERMINATIONS
• RoHS COMPLIANT
• SAC SOLDER COMPATIBLE*
Temperature Coefficient
Capacitance Range
Capacitance Tolerance
Operating Temperature Range
Temperature Characteristics
Rated Voltages
Dissipation Factor
insulation Resistance
Dielectric Withstanding Voltage
X7R
1.0μF ~ 10μF
10% (K) & 20% (M)
-55°C ~ +125°C
±15%
Δ
Cap.
NMC High CV Series
RoHS
Compliant
Includes all homogeneous materials
*See Part Number System for Details
X5R
Y5V
1.0μF ~ 100μF
1.0μF ~ 100μF
10% (K) & 20% (M)
+80%/-20% (Z)
-55°C ~ +85°C
-30°C ~ +85°C
±15%
Δ
Cap.
+22%, -82%
Δ
Cap.
4Vdc, 6.3Vdc, 16Vdc, 25Vdc, 50Vdc & 100Vdc
See Sizes & Values Tables
100Megohm/μF minimum @ +25°C
250% of Rated Voltage for 5 ± 1 sec., 50mA max.
150% of Rated Voltage for 5 ± 1 sec., 50mA max.
C < 10μF 1KHz, 1.0V ±0.2Vrms (ALC on)
1KHz, 1.0V ±0.1Vrms (ALC on)
Test Conditions (EIA-198-2E)
C > 10μF 120Hz, 0.5V ±0.2Vrms (ALC on)
*Reflow soldering is recommended. Contact NIC regarding the use of other soldering methods.
PART NUMBER SYSTEM
NMC 0603 Y5V 105 Z 25 TRP or TRPLP 3K F
RoHS Compliant
Optional Reel Qty (3K = 3,000pcs)
Tape & Reel (Embossed Plastic Carrier)
Tape & Reel (Paper carrier)
Voltage (Vdc)
Capacitance Tolerance Code (see chart)
Capacitance Code, expressed in pF, first 2 digits are
significant, 3rd digit is no. of zeros
Temperature Characteristic (X7R, X5R OR Y5V)
Size Code (see chart)
Series
Typical ESR versus Frequency
Typical Capacitance versus Bias Voltage
®
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
13
Multilayer Ceramic Chip Capacitors
X7R HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0μF
1.5μF
2.2μF
3.3μF
4.7μF
10μF
6.3V
0603
1.6 ± 0.15
0.8 ± 0.15
1.0
0.1 ~ 0.65
10
5%
16
5%
6.3
0805
2.0 ± 0.2
1.25 ± 0.2
1.35
0.25 ~ 0.75
Working Voltage (Vdc)
10
16
25
6.3
5%
3.5%
5%
NMC High CV Series
1206
3.2±0.2
1.6±0.2
1.90
0.25 ~ 0.85
10
5%
16
5%
25
3.5%
3.5%
3.5%
3.5%
35
50
3%
10%
10%*
5%*
5%*
5%
5%
10%*
5%
5%
10%*
5%
5%
15%*
10%
5%
3.5%**
* 1.45mm maximum thickness, **2.20mm maximum thickness
Percentages in the table represent the dissipation factor for that value.
X7R HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0μF
1.5μF
2.2μF
3.3μF
4.7μF
10μF
10
5%
16
3.5%
1210
3.2±0.2
2.5±0.2
2.20
0.25 ~ 1.00
25
3.5%
35
50
3.5%
1812
4.5±0.4
3.2±0.3
1.8
0.25 ~ 1.5
Working Voltage (Vdc)
100
10
16
25
50
2.5%**
5%
3.5%
3.5% 2.5%*
2225
5.7±0.4
6.35±0.25
2.20
0.25 ~ 1.02
100
2.5%*
25
2.5%
2.5%
2.5%
50
2.5%
100
2.5%
5%
3.5%
3.5%
3.5%
5%
2.5%**
3.5%
5%**
*2.20mm maximum thickness, **2.80mm maximum thickness
Percentages in the table represent the dissipation factor for that value.
(CONSULT FACTORY
FOR CAPACITANCE
VALUES NOT LISTED)
W
H
P
L
100% Sn over Ni barrier
P
®
14
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
Multilayer Ceramic Chip Capacitors
X5R HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0μF
1.5μF
2.2μF
3.3μF
4.7μF
6.8μF
10μF
22μF
47μF
4
0402
1.0 ± 0.05
0.5 ± 0.05
0.6
0.1 ~ 0.3
6.3
10%
10%
12.5%*
10%
12.5%
10
15%
16
10%
4
0603
1.6 ± 0.15
0.8 ± 0.15
1.0
0.1 ~ 0.65
Working Voltage (Vdc)
6.3
10
16
25
10%
10%
5%
5%
10%
10%
10%
10%
10%
10%
5%
3.5%
NMC High CV Series
0805
2.0 ± 0.2
1.25 ± 0.2
1.45
0.20 ~ 0.75
4
6.3
10%
10%
10%
10%
10%
15%
10
7.5%
10%
10%
10%
10%
16
5%
5%
5%
5%
25
5%
5%
10%
10%
10%
*T max. 0.65mm, L & W tolerance -0/+0.15mm
Percentages in the table represent the dissipation factor for that value.
X5R HIGH CV CAPACITOR VALUES AND SIZES (mm)
EIA Case Size
Length (L)
Width (W)
Thickness max. (T)
Termination Width (P)
Capacitance
1.0μF
1.5μF
2.2μF
3.3μF
4.7μF
6.8μF
10μF
22μF
47μF
100μF
4
6.3
1206
3.2±0.2
1.6±0.2
1.90
0.25 ~ 0.85
10
16
5%
5%
5%
5%
5%
3.5%
Working Voltage (Vdc)
25
6.3
10
1210
3.2±0.3
2.5±0.2
2.2
0.25 ~ 1.0
16
25
35
10%
5%
10%* 10%*
10%
10%* 10%*
15%*
*Length 3.2mm ± 0.4mm, 2.8mm maximum thickness
10%
10%
10%
10%
10%
10%
10%
7.5%
7.5%
7.5%
10%
10%
3.5%
3.5%
5%
5%
3.5%
10%
5%
3.5%
5%
5%*
3.5%*
5%*
2.5%*
10%
(CONSULT FACTORY
FOR CAPACITANCE
VALUES NOT LISTED)
Percentages in the table represent the dissipation factor for that value.
W
H
P
L
100% Sn over Ni barrier
®
P
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
15
