BI 6-005 ... BI 6-16 ...

Inline bridge

One-Phase Si-Bridge

Rectifiers

BI 6-005 ... BI 6-16

Forward Current: 6 A

Reverse Voltage: 50 to 1600 V

Absolute Maximum Ratings

Symbol Conditions

Values

Units

Publish Data

Features

Characteristics

Symbol Conditions

Values

Units

Mechanical Data

Dimensions in mm

15-10-2004 SCT

BI6-05 Related Products

	BI6-05	BI6-01	BI6-02	BI6-04	BI6-08	BI6-005	BI6-10	BI6-15	BI6-12	BI6-14
Description	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers	One-Phase Si-Bridge Rectifiers
Is it lead-free?	-	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	-	Lead free	Lead free
Is it Rohs certified?	-	conform to	conform to	conform to	conform to	conform to	conform to	-	conform to	conform to
Maker	-	SEMIKRON	SEMIKRON	SEMIKRON	SEMIKRON	SEMIKRON	SEMIKRON	-	SEMIKRON	SEMIKRON
package instruction	-	R-MSFM-W4	R-MSFM-W4	R-MSFM-W4	R-MSFM-W4	R-MSFM-W4	R-MSFM-W4	-	R-MSFM-W4	R-MSFM-W4
Contacts	-	4	4	4	4	4	4	-	4	4
Reach Compliance Code	-	compli	compli	compli	compli	compli	compli	-	compli	compli
Other features	-	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	-	UL RECOGNIZED	UL RECOGNIZED
Shell connection	-	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	-	ISOLATED	ISOLATED
Configuration	-	BRIDGE, 4 ELEMENTS	BRIDGE, 4 ELEMENTS	BRIDGE, 4 ELEMENTS	BRIDGE, 4 ELEMENTS	BRIDGE, 4 ELEMENTS	BRIDGE, 4 ELEMENTS	-	BRIDGE, 4 ELEMENTS	BRIDGE, 4 ELEMENTS
Diode component materials	-	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	-	SILICON	SILICON
Diode type	-	BRIDGE RECTIFIER DIODE	BRIDGE RECTIFIER DIODE	BRIDGE RECTIFIER DIODE	BRIDGE RECTIFIER DIODE	BRIDGE RECTIFIER DIODE	BRIDGE RECTIFIER DIODE	-	BRIDGE RECTIFIER DIODE	BRIDGE RECTIFIER DIODE
JESD-30 code	-	R-MSFM-W4	R-MSFM-W4	R-MSFM-W4	R-MSFM-W4	R-MSFM-W4	R-MSFM-W4	-	R-MSFM-W4	R-MSFM-W4
JESD-609 code	-	e2	e2	e2	e2	e2	e2	-	e2	e2
Maximum non-repetitive peak forward current	-	125 A	125 A	125 A	125 A	125 A	125 A	-	125 A	125 A
Number of components	-	4	4	4	4	4	4	-	4	4
Phase	-	1	1	1	1	1	1	-	1	1
Number of terminals	-	4	4	4	4	4	4	-	4	4
Maximum operating temperature	-	150 °C	150 °C	150 °C	150 °C	150 °C	150 °C	-	150 °C	150 °C
Minimum operating temperature	-	-50 °C	-50 °C	-50 °C	-50 °C	-50 °C	-50 °C	-	-50 °C	-50 °C
Maximum output current	-	2 A	2 A	2 A	2 A	2 A	2 A	-	2 A	2 A
Package body material	-	METAL	METAL	METAL	METAL	METAL	METAL	-	METAL	METAL
Package shape	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	-	RECTANGULAR	RECTANGULAR
Package form	-	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	-	FLANGE MOUNT	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED
Certification status	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	-	100 V	200 V	400 V	800 V	50 V	1000 V	-	1200 V	1400 V
surface mount	-	NO	NO	NO	NO	NO	NO	-	NO	NO
Terminal surface	-	Tin/Silver (Sn/Ag)	Tin/Silver (Sn/Ag)	Tin/Silver (Sn/Ag)	Tin/Silver (Sn/Ag)	Tin/Silver (Sn/Ag)	Tin/Silver (Sn/Ag)	-	Tin/Silver (Sn/Ag)	Tin/Silver (Sn/Ag)
Terminal form	-	WIRE	WIRE	WIRE	WIRE	WIRE	WIRE	-	WIRE	WIRE
Terminal location	-	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	-	SINGLE	SINGLE
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED
